JimiLab LL301 LTE Asset GNSS Tracker, GPS & BDS & LBS & Wi-Fi Positioning, LTE & GSM Network, Remote Listen-in 10,000mAh Rechargeable Battery,Tamper Alert, Multiple Working Modes, Temperature/Humidity Sensor, Multiple Alerts

PB Tech price
PB Tech price
NZD $ 173 .77
$ 173 .77
$173.77  +GST
$173.77

JimiLab LL301 LTE Asset GNSS Tracker, GPS & BDS & LBS & Wi-Fi Positioning, LTE & GSM Network, Remote Listen-in 10,000mAh Rechargeable Battery,Tamper Alert, Multiple Working Modes, Temperature/Humidity Sensor, Multiple Alerts

  • Brand: JimiLab
  • MPN: LL301
  • Part #: IPCJIM0007
  • UPC:
3
PB Tech price
NZD $ 173 .77 $ 173 .77


Delivery: Order now and it ships today
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$173.77  +GST
$173.77
  • Brand: JimiLab
  • MPN: LL301
  • Part #: IPCJIM0007
  • UPC:

What PB Tech customers are saying about this product...

See More Reviews

"Ironed out all the issue's and PB Tech were great. They have even updated the product information from what I found out trying to resolve issues. I now have two of these in differe ...view more"

MC
By: MalcolmC881 25/03/24
Verified Owner

Features

The LL301 is a 4G Cat.1 Asset GNSS Tracker that allows for ultra-long standby time via 10,000mAh large-capacity battery and durable housing. Supporting GPS + BDS + LBS + Wi-Fi positioning, indoor & outdoor signal coverage, and supporting instant alerts of atypical events like device removal, vibration, etc. We also offer the users remote monitoring of the target through our cloud platform and mobile APP, which is suitable for such application scenarios as vehicle rental, fleet management, logistics transportation, etc.

Product is including the tracking platform of 10 years subscriptions. Contact [email protected], to register account for free softtware and APP.

Please Note: This requires 'TrackSolid Pro App'. The original TrackSolid no longer supports the import of new devices.
The following instructions were provided by a customer

1. Charge unit until all blue lights are solid.
2. Carefully remove the top cover, one corner has a recess in it. But be careful as it is really tight to remove so care needed.
3. Insert a SIM card with call, txt, data. The SIM holder is a bit fiddly.
4. Slide toggle switch which is located nearby SIM holder to on.
5. Carefully replace top cover.
6. In the area where the usb charger port is there is a small power button to the right of this hold for three seconds and device battery lights will turn on. Units now active.
7. Install Tracksolid Pro on your phone and create an account.
8. With App open and clicking on the + symbol scan the Scan code which is on the underside of the GPS cardboard box into the app. The scan code card inside the box is just for I-Phone users manual but does give some idea for what parts are what.
9. Tracksolid Pro app will then say bonded and device is up and running



Specifications

GNSS

Positioning system

GPS+BDS+LBS+WiFi

Frequency

L1

Positioning Accuracy

<2.5m CEP

Tracking sensitivity

-165dBm

Acquisition sensitivity

-148dBm

TTFF (open sky)

Avg. hot start =1sec
Avg. cold start =32sec

Cellular

Communication network

LTE/GSM

Frequency

LL301-E
FDD: B1/B3/B7/B8/B20/B28
GSM: 900/1800MHz

LL301-L
FDD: B1/B2/B3/B4/B5/B7/B8/B28/B66
GSM: 850/900/1800/1900MHz

Power

Battery

10,000mAh/3.7V industrial-grade Li-Polymer battery

Working modes

Mode 1: Regular GPS mode
Mode 2: Tracking mode
Mode 3: Power-saving mode

Standby time

Up to 2 years in power-saving mode

Interface

LED indication

1 status indicator (Red), 4 battery indicators (Blue)

SIM

Nano-SIM

Tamper proof

Pressure-sensitive button

Physical specification

Dimensions

108.5 x 61.1 x 30.0mm

Weight

260g

Operating environment

Operating temperature

-20C to +70C

Operating humidity

5%~95%, non-condensing

IP rating

IP65

Feature

Sensors

3-axis Accelerometer

Bluetooth

Supports Bluetooth 5.0

Scenarios

Low battery alert
Tamper alert
Vibrating Alert
Cover removal alert
Power off alert

Manufacturer Part No:
LL301
Brand:
JimiLab
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.4 kg
PB Part No:
IPCJIM0007
Product Model:
LL301
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews

3 out of 5 Stars Based on 3 reviews
5 Stars
0
4 Stars
1
3 Stars
1
2 Stars
1
1 Stars
0

Do you own this product?

Write a review and go into the monthly draw Win A $100 PB Tech Gift Card!

Sadly my unit appears faulty but PB Tech service excellent

Instructions for unit are poor to say the least. My units Bluetooth function did not work and item wouldn't get detected by the App using the IMEI number either. Over the phone support by PB Tech (Bryan) was exceptional and unit was diagonosed as faulty over phone. Will be going back to PB Tech and will try another unit.
Tips for anyone buying this unit.
Charge fully first, Once charged power off unit - tiny button to right of power mini usb socket.
Remove cover for installing SIM , covers a real sod to get off.
Install SIM card then slide nearby switch to on then replace cover. But then push little power button , the one mentioned next ...view more

MC
By: MalcolmC881 24/09/23
Verified Owner
1 out of 1 user found this review helpful
Did you find it helpful?

List of modes is a little wrong.

Try to change modes in the app or website and it says not supported with this device. You pretty much only get the default mode (smart mode) which tracks in real time and has about a month of battery. Can't for the life of me get it to work in timed mode as the website/app keeps saying not supported even though the user manual says it is.

JH
By: JeffH751 03/05/24
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?

Update since my earlier post

Ironed out all the issue's and PB Tech were great. They have even updated the product information from what I found out trying to resolve issues. I now have two of these in different vehicles. Pros is you can track where your vehicle is plus get a breakdown of journeys and speeds etc. Cons, battery life is a month at best but that maybe how it reports to me but settings are a little unclear. Sometimes when it links via LBS or wifi it shows it a street away but when on GPS its accurate however it chooses those settings not the user. Overall happy enough with product especially as no subscription required.

MC
By: MalcolmC881 25/03/24
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?
