MINIX Fanless MiniPC NEO Z300-0dB Intel i3- N300 16G/512GB Win 11 Pro (64-bit)
- Brand: MINIX
- MPN: NEO Z300
- Part #: IPCMNXZ30001

Product URL: https://www.pbtech.com/pacific/product/IPCMNXZ30001/MINIX-Fanless-MiniPC-NEO-Z300-0dB-Intel-i3--N300-1?qr=popular_related_products
Features
- Intel® CoreTM i3-N300 Processor, up to 3.8GHz
- ZERO db Cooling System
- Dual Display Ready: 2 x HDMI® 2.0 (4K @ 60Hz)
- Memory: 16GB DDR4-3200, upgradeable to 32GB
- Storage: 512GB SSD (PCIe 3.0 x4), upgradeable to 4TB
- Intel® Dual Band Wi-Fi (2.4GHz/5GHz), BT
- RJ-45 2.5 Gigabit Fast Ethernet
- Housing Material: Aluminum, Galvanized Steel (SGCC)
- VESA Mount Included
- Wake On LAN, AC Power Loss, RTC Wake Up
- Windows 11 Pro (64-bit) Pre-installed
Performance Meets Serenity
Balances powerful performance with silent operation, perfect for demanding yet noise-sensitive tasks.
Fanless Silence
Adopts a passive cooling design for absolute quietness, ensuring a distraction-free environment.
Dust-Proof Performance
Maintains a clean interior, eliminating dust buildup and preserving long-term performance.
Intel® Alder Lake-N N300 Octa-Core
Powers the Z300-0dB with an efficient eight-core processor, delivering smooth performance across tasks.
Kimtigo Premium RAM
Equipped with top-quality RAM from Kimtigo, ensuring seamless multitasking and faster response times.
Wi-Fi 6 & Bluetooth 5.2 Connectivity
Stays ahead of the curve with the latest wireless standards, offering faster speeds and broader compatibility.
2.5G LAN Port
Provides ultra-fast wired networking, ideal for bandwidth-intensive applications and large file transfers.
Dual 4K @ 60Hz Display Support
Enables simultaneous dual 4K resolution displays at 60Hz, perfect for professionals seeking immersive visuals and enhanced productivity.
Specifications
System Hardware
BIOS
AMI EFI X64
Processor
Intel® Alder Lake-N Quad-Core N100 (Base Frequency 0.8GHz, Max Turbo Frequency 3.40GHz)
Graphics Engine
Intel® UHD Graphics
Memory Slot
1 x 260-pin DDR4 3200MHz SO-DIMM 16GB, upgradeable to 32GB Max
Storage
512GB M.2 PCIe 3.0 x4 NVMe SSD, upgradeable to 4TB Max.
Ethernet
1 x RTL8125BG-CG 2.5 Gigabit Ethernet
LED Indicators
LEDs for Power, LAN (Active, Status)
WIFI/BT
Intel® Wireless-AX101 / AX201 (Dual Band AX Wi-Fi)
I/O Interfaces
LAN Port
1 x RJ45, 10M/100M/1000M/2.5 Gigabit Fast Ethernet
USB Ports
1 x USB 3.2 Gen 2 Type-C (Data Only, up to 10Gbps), 2 x USB 3.2 Gen2 Type-A (10Gbps), 2 x USB 2.0
Audio Jack
3.5mm Audio Jack (Earphone+Micphone, 2-in-1)
Display Output
2 x HDMI® 2.0, 3840X2160@60Hz
Antenna
2 x External Wi-Fi Antennas
Power Button
1 x Power Button
Reset Button
1 x Clear CMOS Button (Reset BIOS)
Power Jack
1 x 12V-19V DC-IN Jack
Environment
Operating Temperature
0 ~ 50°C @ 5 ~ 85% RH
Storage Temperature
-20 ~ 70°C
Relative Humidity
10 ~ 95% RH @ 40 °C/104 °F, non-condensing
General
Certification
CE, FCC, RCM, RoHS
Dimensions (WxDxH)
123x120x46mm (4.84"x4.72"x1.81")
Form Factor
Mini PC
Encloser
Metal Housing
Weight (Net)
0.89 kg
Power Requirement
12V/3A DC-IN
Power Consumption
10-12W (Typical), 25-27W (Turbo)
