Fanvil FAN-PA2S This all-in-one gateway enables to upgrade adigitalsolutionintoaSIP-basedvoice&videosecurity solution. It can be used for intercom, paging, amplify, video & more. With its HD voice quality, provides high quality & reliabilit

PB Tech price
PB Tech price
NZD $ 214 .78
$ 214 .78
$214.78  +GST
$214.78

Fanvil FAN-PA2S This all-in-one gateway enables to upgrade adigitalsolutionintoaSIP-basedvoice&videosecurity solution. It can be used for intercom, paging, amplify, video & more. With its HD voice quality, provides high quality & reliabilit

  • Brand: Fanvil
  • MPN: FAN-PA2S
  • Part #: IPHFAN1123
  • UPC:
PB Tech price
NZD $ 214 .78 $ 214 .78
In stock at NZ Logistics Centre
Delivery: Order now and it ships on 09 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$214.78  +GST
$214.78
Add To Compare
Stock Alerts
Click or hover over image to enlarge
  • Brand: Fanvil
  • MPN: FAN-PA2S
  • Part #: IPHFAN1123
  • UPC:

Colour

Black

Interface

Not Specified

Microphone

N/A

Microphone Noise Cancelling

N/A

Noise Cancelling

N/A

Sound Mode

N/A

Wireless Technology

N/A

View full specs
Returns & Warranty Bulk Quote Print Page

Features

Fanvil PA2S SIP Paging Gateway

This is a SIP paging gateway that uses the standard IP/RTP/RTSP protocol for media streaming. It sets a variety of functional interfaces in one: broadcast, recording, intercom, security. Through the connection of the external devices to achieve audio and video intercom, broadcast, security trigger and other practical functions, Fanvil PA2S can apply to multiple scenarios to deploy the equipment. The size of the device is small, which is suitable for DIY applications of various integrated solutions.

- Exquisite, can be embedded in other equipment for internal installation
- Emergency call button interface, active call
- NVR video recording, standard RJ45 interface
- Recording output, 3.5mm standard audio interface
- Audio line out port, expandable external active speaker.
- 10W ~ 30W mono channel power amplifier output, according to the input voltage to setting the output power.
- Adaptive 10/100 Mbps network port, integrated PoE

Specifications

Physical Specifications

Keypad: 3 keys, including

2 volume control keys (Up/Down)
1 reset key (soft reset)

RJ45 port x2: connect the network

WAN port: connect the network, support PoE
Camera port: connected to the original camera

Blue LED

x1: (SIP status and network status)

Recording output port x1: connect audio device

Out: mixed output of local microphone voice and call voicerecording
Port: 3.5mm standard audio port
Impedance: 15 Ohm

Ground screw

x1

Passive speaker port

x1: connect the speaker

Output power

4O, PoE/10W, 12V/10W, 18V/20W, 24V/30W; related to power supply voltage.
8O, PoE/5W, 12V/5W, 18V/10W, 24V/15W; related to power supply voltage.
Wire diameter: 18AWG or higher.
Port: terminal socket

Line out port x1: connect the active speaker

Out: adjustable by volume, max up to 1.2Vpp.
Port: terminal socket

DSS keys port x1: connect the external buttons (support LED)

LED: Output 5.0Vdc/5mA.
Port: terminal socket

MIC in / Line in port x1: connect the MIC or audio line in device

The multiplex port is microphone input by default, which be configured as audio line input function through software.
Electret condenser MIC is recommended
Sensitivity: - 38dB, impedance 2.2k ohm, bias voltage 2.54Vpp
Port: terminal socket

Short circuit input and output port x1 (built-in relay)

Relay: MAX DC30V / 2A, AC125V / 0.5A
Port: terminal socket

2 parallel power input DC port: DC power input

DC power input: DC12V~24V/2A
1 road for the 5.5mm DC power seat
1 road for the 2 Pin terminal socket

PoE level

Class 3

Power Consumption (PoE)

2.16W ~ 8.98W

Power Consumption (Adapter)

1.73W ~ 7.9W

Housing material

aluminum alloy

Installation

Desktop stand / Wall-mounted

Color

black

Working temperature

-40? ~ 70?

Storage temperature

-40? ~ 70?

Working humidity

10~95%

Device dimensions

113x83x28 mm

Audio

Narrowband codec

G.711A/U, G.729A/B,iLBC,G.723.1,G.726-32K

Wideband codec

G.722, Opus

DTMF

In-band, Out-of-Band (RFC2833/ SIP INFO)

General

Generic

2 SIP lines
Speed dial
Linkage with IP camera to realize video intercom
Oral announcement of the IP address(in English)
MP3 broadcasting
Support mono active speaker (audio line out)
Support audio line in
Talkback recording output
Switch signal input and output
Support programmable DSS key ports
PoE enabled

Functions

Device Functions

Auto-answering
Programmable DSS keys
Through button or web page volume adjustment
Network time synchronization
Time plan (task management)
Incoming call multicast
Dynamic multicast function
HTTP API
Action URL / Active URI

Call Functions

Call out / answer / reject
Call waiting
Intercom, Multicast
Speed dial
Anonymous call (Hide caller ID)

Network

Physical

10/100 Mbps Ethernet

IP mode

IPv4/IPv6/IPv4&IPv6

IP configuration

Static IP / DHCP / PPPoE

VPN

L2TP / OpenVPN

Protocols

SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS
RTP/RTCP/SRTP
STUN
DHCP
IPv6
PPPoE
L2TP
OpenVPN
SNTP
FTP/TFTP
HTTP/HTTPS
TR-069

Manufacturer Part No:
FAN-PA2S
Brand:
Fanvil
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.3 kg
PB Part No:
IPHFAN1123
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
