Ubiquiti Unifi USW-Mission-Critical 9-Port Gigabit L2 Managed PoE Switch (120W) with 368Wh Battery - 1GbE PoE+ x4, 1GbE PoE++ x4

PB Tech price
PB Tech price
NZD $ 2,035 .48
$ 2,035 .48
$2,035.48  +GST
$2,035.48

Ubiquiti Unifi USW-Mission-Critical 9-Port Gigabit L2 Managed PoE Switch (120W) with 368Wh Battery - 1GbE PoE+ x4, 1GbE PoE++ x4

  • Brand: Ubiquiti
  • MPN: USW-MISSION-CRITICAL
  • Part #: SWHUBI6323236
  • UPC:
PB Tech price
NZD $ 2,035 .48 $ 2,035 .48
In stock at NZ Logistics Centre
Delivery: Order now and it ships on 12 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$2,035.48  +GST
$2,035.48
Add To Compare
Stock Alerts
Click or hover over image to enlarge
  • Brand: Ubiquiti
  • MPN: USW-MISSION-CRITICAL
  • Part #: SWHUBI6323236
  • UPC:

Form Factor

1U Rackmount

10 Gigabit Ports

N/A

10 Gigabit

No

Management Level

Managed L2

Number of Ports

9 Ports

PoE

Yes

PoE Ports

8 Ports

PoE Budget

120 Watts

View full specs
Returns & Warranty Bulk Quote Print Page

Features

Ubiquiti Unifi USW-Mission-Critical 9-Port Gigabit L2 Managed PoE Switch (120W) with 368Wh Battery

A switch with an integrated 368Wh lithium-ion battery capable of providing uninterruptible PoE to 8 devices.

Deployment



Specifications

Overview

Dimensions

442 x 480 x 44 mm (17.4 x 18.9 x 1.7")

Port Layout

1 GbE RJ45
9 (4 PoE+; 4 PoE++) (1G/100M/10M)

Max. PoE Output

Up to PoE++

Total PoE Availability

120W

Redundancy

Battery Power Backup

Layer 3

Yes

Form Factor

Rack mount (1U)

Performance

Switching Capacity

18 Gbps

Total Non-Blocking Throughput

9 Gbps

Forwarding Rate

13 Mpps

Supported VLANs

1,000

MAC Address Table Size

8,000

Packet Buffer Size

0.5 MB

Access Lists

IPv4 128
MAC 128

Layer 2 Features

LACP Port Aggregation

Yes

STP & RSTP

Yes

Advanced IGMP Configuration (Querier, Fast Leave, Router Port)

Yes

IGMP Snooping

Yes

802.1X Control

Yes

MAC-Based ACLs & Device Isolation

Yes

DHCP Snooping & Guarding

Yes

Egress Rate Limit

Yes

Flow Control

Yes

Storm Control

Yes

Multicast & Broadcast Rate Limiting

Yes

MAC Address Blocking

Yes

IP-Based ACLs & Network Isolation

Yes

MAC-Based Port Restriction

Yes

Port Isolation

Yes

Port Mirroring

Yes

Jumbo Frames

Yes

LLDP-MED

Yes

Voice VLAN

Yes

Loop Protection

Yes

Hardware

PoE Ports

PoE+
4
PoE++
4

Max. PoE Wattage per Port by PSE

PoE+
32W
PoE++
64W

Max. Power Consumption

50W (Excluding PoE Output)
240W (Including PoE Output and AC Output)

Power Method

Universal input, 100-240V AC, 50/60 Hz
External battery input, 48V DC

Power Input Method

AC input
DC input (Backup)

Power Supply

AC/DC, internal, 240W

Supported Voltage Range

100-240V AC

Management

Ethernet
AR

Heat Dissipation (Excluding PoE Output)

170.6 BTU/hr

Weight

Without mount: 9 kg (19.9 lb)
With mount: 9.2 kg (20.3 lb)

Enclosure Material

SGCC steel

Mount Material

SGCC steel

Supported Rack Depth

482.6 mm (19") four-post racks
Posts depths ranging from 700 to 1,000 mm (27.6-39.4")

LCM Display

1.3" touchscreen

ESD Protection

Air/contact: ± 24kV

Ambient Operating Temperature

-5 to 40° C (23 to 104° F)

Ambient Operating Humidity

5 to 95% noncondensing

NDAA Compliant

Yes

Certifications

CE, FCC, IC

Software

Application Requirements

UniFi Network
Version 6.2.26 and later

Manufacturer Part No:
USW-MISSION-CRITICAL
Brand:
Ubiquiti
Product Type:
-
UPC
-
Product Family:
Unifi
Shipping Weight:
3 kg
PB Part No:
SWHUBI6323236
Product Model:
USW-Mission-Critical
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
