StarTech.com US100A20FXSC USB to Fiber Optic Converter - 100Mbps - USB 2.0 to Fiber Network Adapter - 100Base-FX SC Female Duplex Multimode Fiber/MMF Compatible - 2Km - Compact USB to Fiber LAN
- Brand: StarTech.com
- MPN: US100A20FXSC
- Part #: ADPSTT4145273

Product URL: https://www.pbtech.com/pacific/product/ADPSTT4145273/StarTechcom-US100A20FXSC-USB-to-Fiber-Optic-Conver
Features
This USB to fiber-optic converter lets you utilize the USB 2.0 (Type-A) port on your laptop or tablet to provide a secure fiber network connection. Windows® and Mac compatible, the network adapter provides a 100Mbps Ethernet network connection and 100BaseFX SC optical transceiver.
Fiber-optic SC port
With an optical transceiver for 100Base-FX networks, the USB to fiber converter delivers network connectivity with a maximum range of 2 km over multimode fiber.
Secure fiber-to-the-desk connectivity
For reliable fiber connectivity, this USB to fiber-optic converter protects your network from problems with electronic interference - a common issue with copper Ethernet networks. Fiber-to-the-desk connectivity (FTTD) maximizes network security, reducing the risk of data leaks of sensitive information, without compromising network speed and reliability.
Easy portability
Compact and portable, this USB 2.0 to fiber-optic converter is powered directly from the USB port, making it easy to connect when you're on the go.
Plug and play
Get up and running quickly. The USB fiber-optic converter supports certified drivers for Windows and Linux®. When you plug the adapter into a USB port, you simply install the drivers and the adapter is ready to transmit over a fiber network.
Applications
- Provides a portable network connectivity solution for mobile professionals, to access a fiber network through the USB port on their laptop or tablet
- Ideal for secure network connectivity - a direct fiber connection means no electronic interference, which can be a problem with RJ45 network cards
Specifications
HARDWARE
Bus Type
USB 2.0
Chipset ID
ASIX Electronics - AX88772C
Industry Standards
IEEE802.3x 100BASE-FX
IEEE 802.1Q VLAN tagging
Interface
Fiber Ethernet
Ports
1
PERFORMANCE
Compatible Networks
1000 Mbps (1 Gbps)
DDM
No
Max Distance
2 km (1.2 mi)
Maximum Data Transfer Rate
100 Mbps
Promiscuous Mode
Yes
Type
Multi Mode
Wavelength
1310nm
CONNECTOR(S)
Connector Type(s)
1 - USB Type-A (4 pin) USB 2.0 Female
1 - Fiber Optic SC Female
SOFTWARE
OS Compatibility
Windows® 7, 8, 8.1, 10
Windows® Server 2008, 2012, 2106
Mac OS X® 10.9 to 10.14
Linux® kernel 3.5 to 4.11.x, LTS versions only
INDICATORS
LED Indicators
1 - Power
1 - Link/Activity
POWER
Power Source
USB-Powered
ENVIRONMENTAL
Humidity
5% ~ 90% RH
Operating Temperature
0°C ~ 60°C (32° ~ 140°F)
Storage Temperature
-10° ~ 70°C (14° ~ 158°F)
PHYSICAL CHARACTERISTICS
Cable Length
7.7 in [195 mm]
Color
Black
Enclosure Type
Plastic
Product Height
0.8 in [20 mm]
Product Length
6.7 in [170 mm]
Product Weight
3.8 oz [108 g]
Product Width
5.5 in [140 mm]
WHAT'S IN THE BOX
Included in Package
1 - network adapter
1 - quick-start guide
Max Transfer Distance
2 km (1.2 mi)
