StarTech.com USB-C Multiport Adapter HDMI / VGA 100W PD
- Brand: StarTech.com
- MPN: DKT30CHVPD2
- Part #: ADPSTT5325682
- UPC:065030891752

Product URL: https://www.pbtech.com/pacific/product/ADPSTT5325682/StarTechcom-USB-C-Multiport-Adapter-HDMI--VGA-100W
Features
This USB-C multiport adapter turns your MacBook Pro, USB-C™ laptop, Chromebook, or Android (Samsung Galaxy S8, Note 9 and above) device into a workstation, anywhere you go. A USB Type-C adapter, ideal for travel, features everything from the essential HDMI or VGA video outputs, USB ports, and 100W PD including PD passthrough, and gigabit Ethernet. All through a single extended length 30 cm, Thunderbolt 3 or USB-C attached host cable, providing more flexibility for harder to reach laptop and tablet connections.
To ensure full adapter functionality, your laptop's USB-C port must support USB Power Delivery and DP Alt Mode.
Two Video Output Options with HDMI or VGA
This USB-C multiport adapter features both an HDMI and VGA port providing you with two single video output options for your boardroom presentations or your workstation setup including support for an ultra-wide monitor.
Power & Charge with 100W Power Delivery 3.0
With support for USB PD 3.0 (up to 100W), the USB Type-C multiport adapter lets you power and charge your laptop, and power your peripherals when connected to a USB-C power adapter. The USB-C hub features PD passthrough so you can use your laptop's own charger to power the hub (requires 12W) and power or charge your laptop simultaneously.
All the Essential Ports with USB
The USB-C to USB 3.0 hub gives you one USB-C port (power & data) and two USB-A ports to connect your latest and legacy USB devices; includes a gigabit Ethernet port for a direct LAN connections.
- Advanced Windows Layout Utility: To setup and save custom windows layouts.
- Mac Address Pass-Through Utility: To improve network security.
- USB Event Monitoring Utility: To track and log connected USB devices
- Wi-Fi Auto Switch Utility: Enabling users to quickly access faster network speeds via wired LAN.
- 6-IN-1 MULTIPORT ADAPTER: USB-C mini dock with HDMI 4K 30Hz or VGA 1080p video outputs, 2x USB-A (USB 3.1 Gen 1 5Gbps) with 1x BC 1.2 charging, 1x USB-C (100W PD 3.0 or 5Gbps data), Gigabit ethernet; works w/ HDMI ultra-wide monitors/displays (3440x1440)
- EXTRA LONG CABLE: USB C multiport adapter with 12" (30cm) attached cable for extended reach to reduce port/connector strain on 2-in-1 devices like Surface Pro 7, iPad Pro, HP Elite x2 & laptops on riser stands
- RELIABLE PERFORMANCE: USB bus powered or via external USB-C power adapter; 100W Power Delivery 3.0 pass through w/ 15W reserved for adapter to avoid video flickering, device dropouts or overdrawing power common in other hubs; up to 85W for laptop charging
Specifications
Connector(s)
1 - Internal Ports
USB 3.1 Gen 1 USB Type-A (9 pin, 5 Gbps)
USB 3.0 A (Fast-Charge, 9 pin)
USB Type-C (24 pin, 5Gbps)
Ethernet Gigabit
HDMI
VGA (14 pin, High Density D-Sub)
1 - Host Connectors
USB Type-C (24 pin, 5Gbps)
Environmental
Operating Temperature
0 to +45C
Storage Temperature
-10 to +70C
Humidity
10% to 85 % RH
Hardware
USB-C Host Connection
Yes
Displays Supported
1
4K Support
Yes
Fast-Charge Port(s)
Yes
Ports
6
Interface
USB 3.2 Gen 1
Bus Type
USB-C
USB Pass-Through
Yes
Chipset ID
AG6320
FL5001
FL7102
RTL8153
Packaging Information
Package Height
1.2 in [3.0 cm]
Package Length
6.7 in [17.0 cm]
Shipping (Package) Weight
4.8 oz [135.0 g]
Package Width
5.6 in [14.2 cm]
Performance
Maximum Digital Resolutions
3840x2160 (4K 30Hz)
Type and Rate
USB 3.1 Gen 1 - 5 Gbit/s
Physical Characteristics
Color
Black & Gray
Product Height
0.6 in [1.4 cm]
Product Length
2.0 in [5.2 cm]
Weight of Product
3.9 oz [110.0 g]
Product Width
12.2 in [31.0 cm]
Cable Length
11.8 in [30 cm]
Power
Power Source
Bus Powered and Host USB-C Power Adapter
Power Delivery
100W
Software
OS Compatibility
Windows® 8.1, 10, 11
macOS 10.10 to 10.15, 11, 12
Ubuntu 18.04, 20.04
Chrome OS™
Android 9.0
iPadOS
What's in the Box
1 - Included in Package
USB-C Multiport Adapter
Quick-Start Guide
