DBX AFS2 ANTI FEEDBACK PROCESSOR WITH LCD DISPLAY

PB Tech price

NZD $ 1,006 .09

$ 1,006 .09

DBX AFS2 ANTI FEEDBACK PROCESSOR WITH LCD DISPLAY

Brand: DBX
MPN: AFS2
Part #: AUDDBX1005
UPC:

NEW ARRIVAL

PB Tech price

NZD $ 1,006 .09

In stock at NZ Logistics Centre

Delivery: Order now and it ships on 12 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: DBX
MPN: AFS2
Part #: AUDDBX1005
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

Hear No Evil and See no Evil.

The AFS² Advanced Feedback Suppression processor has been completely re-designed to take the foundation of the best selling AFS224 and bring it to thte next level. The AFS² now offers the highly-intuitive Wizard function that takes all of the guesswork out of setting up any room. The AFS² also incorporates a completely re-designed Advanced Feeback Supression module. Best of all, the AFS² now provides the user with a full LCD display setup and monitoring.

With its powerful DSP module, the AFS² provides all the processing and control necessary for both installation and live use. Ten and twelve filter feedback elimination processors are the de facto standard, but the AFS² offers a dedicated feedback suppression processor that offers up to 24 filters per channel with filter Qs up to 1/80 of an octave. To achieve these staggering numbers dbx utilized their improved AFS technology that had previously only been available in the upper echelon line of products and made it available in this stand-alone processor. In addition to the plethora of feedback suppression filters available, the AFS² also offers selectable modes, live filter lift, and types of filtration, which are all readily available via the intuitive user interface front panel. With all of these state-of-the-art features in place, not only do you hear no evil, but you will now be able to see no evil.

- Wizard Setup Function
- Full LCD Display
- dbx's patented (Advanced Feedback Suppression) AFS™ technology
- 24 Programmable Filters per Channel
- Stereo or Dual Independent Channel Processing
- Live and Fixed Filter Modes
- Selectable Filter Lift Times
- Application-specific filter types include: Speech and Music Low, Med and High
- Input channel Metering
- 24 LED per Channel Filter Metering
- XLR and TRS Inputs and Outputs

Specifications

Number of Inputs

Input Connectors

Female XLR and 1/4" TRS

Input Type

Electronically balanced/unbalanced, RF filtered

Input Impedance

Balanced 50kohm, Unbalanced 25kohm

Max input line level

+20 dBu

CMRR

> 40dB, typically >55dB @ 1kHz

Number of Outputs

Output Connectors

Male XLR and 1/4" TRS

Output Type

Electronically balanced/unbalanced, RF filtered

Output Impedance

Balanced >120 ohm, Unbalanced >60 ohm

Max Output Level

+20 dBu

A/D Converter

dbx Type IV™ Conversion System

A/D Dynamic Range

>113 dB A-weighted, >110 dB unweighted, 22kHz BW

Type IV Dynamic Range

>119 dB, A-weighted, 22kHz BW; >117 dB, unweighted, 22kHz BW

A/D Conversion

24-bit

Sample Rate

48kHz

D/A Dynamic Range

112 dB A-weighted, 109 dB unweighted

D/A Conversion

24-bit

Dynamic Range

109 dB A-weighted, 106 dB unweighted, 22kHz BW

THD+Noise

0.003% typical at +4 dBu, 1 kHz

Frequency Response

20Hz - 20kHz, +/- 0.5dB

Interchannel Crosstalk

>80 dB typical

Crosstalk input to output

>80 dB

Operating Voltage

100-120VAC 50/60 Hz - EU: 220-240 VAC 50/60 Hz

Power Consumption

9 W

Unit Weight

4.5 lbs. (2.04 kg)

Dimensions

1.75" (H) x 5.75" (D) x 19" (W), 4.4cm (H) x 14.6cm (D) x 48.26cm (W)

Manufacturer Part No:

AFS2

Brand:

DBX

Product Type:

UPC

Product Family:

Shipping Weight:

0.2 kg

PB Part No:

AUDDBX1005

Product Model:

Warranty: 12 months *
