SOUNDCRAFT EPM8 8-MONO 2-STEREO MIXER (RW5735)

PB Tech price

NZD $ 663 .48

$ 663 .48

SOUNDCRAFT EPM8 8-MONO 2-STEREO MIXER (RW5735)

Brand: SOUNDCRAFT
MPN: EPM8
Part #: AUDSCF5085990
UPC:

NEW ARRIVAL

PB Tech price

NZD $ 663 .48

In stock at NZ Logistics Centre

Delivery: Order now and it ships on 12 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: SOUNDCRAFT
MPN: EPM8
Part #: AUDSCF5085990
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

The emphasis with the Soundcraft EPM is very firmly on quality build and audio performance, with an easy to understand control surface uncluttered by unnecessary facilities, and Soundcraft have brought new technologies and ideas to this very cost-effective range. Surface mount technology is used throughout, using close-tolerance components for high accuracy and repeatable settings for EQ and gain controls. The highly-transparent GB30 Mic amp (designed by Graham Blyth for the company's 30th anniversary, and also used on the larger LX7ii and GB Series consoles) features high-resolution adjustment over a wide gain range of 55dB, and provides a stunning +22dB headroom through the console. True professional 48-volt phantom power caters for condenser microphones of all types.

A unique feature of the signal monitoring is the PEAK led. This uses multipoint signal take-offs to watch for overload in several parts of the channel strip, and the led lights more brightly as the signal approaches the peak point. For smooth and accurate channel control, the EPM has 60mm high quality faders as used on other Soundcraft desks. The monitor output and headphone output work in parallel so that performers can still listen on phones while an engineer is listening on studio monitors.

- Frame size 8+2
- 2 configurable auxiliary buses
- XLR-type and quarter inch metal jack connector sockets
- RCA phono stereo playback inputs and record outputs
- 3-band EQ with a swept mid on mono inputs
- 2-band EQ on stereo inputs
- TRS insert sockets and inserts on all mono inputs and mix output
- Ten-segment LED output metering
- Intuitive and comprehensive solo system
- Headphone output
- Easily rack mountable

Specifications

Frequency Response

Mic / Line Input to any Output

20Hz to 20kHz +/-0.5dB

THD & Noise

-30dBu Input routed to Mix, Mic gain 30dB

<0.007%

Mic Input EIN

22Hz-22kHz unweighted

-128dBu (150ohm source)

Bus Noise

Measured RMS, 20Hz to 20kHz Bandwidth Line inputs selected at unity gain and terminated 150ohm Mix

Mix at Max, Faders down: <-85dBu

Crosstalk (@ 1kHz)

Channel Mute

> 96dB

Fader Cut-off (rel +10 mark)

> 96dB

Aux Send Pots Offness

> 86dB

Input & Output Impedances

Microphone Input

2.4kohm

Line Input

11kohm

Stereo Input

100kohm

Output

75ohm

Input & Output Levels

Mic/Line input Maximum Level

+17dBu

Line input Maximum Level

+30dBu

Stereo Input Maximum Level

+30dBu

Mix Output Maximum Level

+20dBu

Headphones (@ 200ohm)

300mW

EQ (Mono Inputs)

12kHz, ±15dB, shelving

Mid

150Hz - 3.5kHz, ±15dB, Q=1.5

60Hz, ±15dB, shelving

Metering

12-segment LED bargraphs for Mix L&R outputs

Operating Conditions

Temperature Range

-10°C to +30°C

Relative Humidity

0% to 80%

Power

Power Supply

Integral lightweight switched-mode PSU

AC mains supply

85V-270V AC, 50/60Hz universal input

Power Consumption

Less than 20W

Dimensions

Width

330mm (13")

Height

90.5mm (3.56")

Depth

362mm (14.25")

Weight

5.6 kg (12.34 lbs)

Manufacturer Part No:

EPM8

Brand:

SOUNDCRAFT

Product Type:

UPC

Product Family:

Shipping Weight:

0.2 kg

PB Part No:

AUDSCF5085990

Product Model:

Warranty: 12 months *
