- Max. Power Consumption 1W - Tested in Targeted Switches for Superior Performance, Quality, and Reliability - FC-PI-5 Compliance for 14.025/8.5/4.25Gb/s Operation - Provide In-order and Lossless Delivery of Raw Block Data - Used for Fibre Channel Storage Network in Data Centers - Hot-pluggable SFP+ MSA Form Factor - Digital Optical Monitoring Capability for Strong Diagnostic Capabilities - Class 1 Laser Safety and RoHS Compliant
Specifications
Form Factor
SFP+
Max Data Rate
16Gbps
Wavelength
850nm
Max Cable Distance
100m @ OM3 MMF
Connector
LC duplex
Optical Components
VCSEL 850nm
Media
MMF
DOM Support
Yes
TX Power
-7.8~-1.3dBm
Receiver Sensitivity
<0dBm
Commercial Temperature Range
0 to 70°C (32 to 158°F)
Protocols
FC-PI-5, SFF-8432, SFF-8472, SFF-8431
Manufacturer Part No:
XBR-000192
Brand:
Brocade
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1.8 kg
PB Part No:
BCD1013
Product Model:
-
Warranty:
12 months * * Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
