Advantech IPC-510 4U 19" Rack Case For ATX Motherboard - Black
Advantech IPC-510 4U 19" Rack Case For ATX Motherboard - Black
- Brand: Advantech
- MPN: IPC-510MB-00XCE
- Part #: CHAVH722140
- UPC:
- Brand: Advantech
- MPN: IPC-510MB-00XCE
- Part #: CHAVH722140
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Chassis





Advantech IPC-510 4U 19" Rack Case For ATX Motherboard - Black
- Brand: Advantech
- MPN: IPC-510MB-00XCE
- Part #: CHAVH722140

Product URL: https://www.pbtech.com/pacific/product/CHAVH722140/Advantech-IPC-510-4U-19-Rack-Case-For-ATX-Motherbo
Features
- The most cost-effective rackmount chassis
- Supports 250/300 W ATX PFC PS/2 power supply
- Easy to install front-accessible drive bays to hold three 5.25" and two 3.5" drives (one front-accessible & one internal)
- Front-accessible USB & PS/2 interfaces
- Designed to withstand environmental extremes, such as shock, vibration and high temperature
Specifications
4U
USB2.0
2
PS/2
1
System Fan
1 (12 cm / 77 CFM)
Operational Temperature
0 ~ 40° C (32 ~ 104° F)
Non-Operational Temperature
-20 ~ 60° C (-4 ~ 140° F)
Operating Shock
10 G (with 11 ms duration, half sine wave)
Operating Humidity
10 ~ 85% @ 40° C, non-condensing
Non-Operating Humidity
10 ~ 95% @ 40° C, non-condensing
Operating Vibration (5 ~ 500 Hz)
1 Grms
Non-Operating Vibration (5 ~ 500 Hz)
2G
Weight
10.7 kg (23.5 lb)
Dimensions (W x H x D)
481 x 175 x 446 mm ( 19" x 7" x 17.6" )
5.25 External Bay
3
3.5 External Bay
1
LED Indicators
Power, HDD activity
Rear Panel
One 9-pin D-Sub opening
