Intel Xeon E5-2650 v3 Processor 2.3GHz, 25MB Cache, LGA2011-3, 10Core/20Thread 105W TDP
- Brand: Intel
- MPN: BX80644E52650V3
- Part #: CPUITX52650V3
- UPC:735858283786
Product URL: https://www.pbtech.com/pacific/product/CPUITX52650V3/Intel-Xeon-E5-2650-v3-Processor-23GHz-25MB-Cache-L
Features
Intel E5 v3 Family
With this processor at the heart of an agile, efficient data center, your organization can respond rapidly to changing buisiness demands, protect data from cybercriminals and streamline data center operations.
A New Way to Think About the Data Center
Now designed for compute, storage, and networking to work better together, the latest Intel Xeon processor can help you meet today's challenges while laying the groundwork for tomorrow's fully-orchestrated data center.
- Deliver more automation capabilities for higher-performing, more secure clouds
- Solve increasing demands for storage and quickly crunch through complex data analytics problems
- Meet the speed of execution expected today
- Operate a more cost-effective, energy-efficient data center
- Measure and monitor
Responsive Performance, Remarkable Energy Efficiency
The latest members of the Intel Xeon processor E5 family deliver the best combination of performance, built-in capabilities, and cost-effectiveness to address technical computing challenges, enable cloud deployments, accelerate processor performance for peak loads, deliver intelligent storage or power data analytics. In comparison to previous generation processors you get:
- Up to 3x more performance
- The world's most energy efficient server
- Up to 1.9x more performance with Intel AVX2
- Up to 1.7x increased virtual machine density1
- Up to 1.4x increased memory bandwidth with DDR4
Streamline Your Path to Private Cloud Services Delivery
Built-in virtualization delivers faster performance for core virtualization processes and improves the quality and control of services.
- Improved application performance, live migration, provisioning, dynamic load balancing, and disaster recovery.
- Greater service quality and utilization by monitoring individual virtual machines (VMs) in cache and addressing "noisy neighbor" issues.
- Enabling ultra-high isolation for usages such as financial services.
A Foundation for Trust and Security
Improve your ability to safeguard your data and infrastructure with foundational, hardware-assisted security capabilities.
- Encourage pervasive encryption by reducing associated performance penalties.
- Deploy a wide range of security applications with faster, higher-quality cryptographic keys and certificates.
- Protect your operating system by increasing security against malware, denial-of-service (DoS), privilege escalation, and platform surface attacks.
- Protect against attacks against the hypervisor, BIOS, firmware, and other prelaunch software components and gain visibility into system security to strengthen IT compliance.
Specifications
Family
Intel Xeon E5-2600 v3
Model number
E5-2650 v3
Frequency
2300 MHz
Turbo frequency
3000 MHz
Bus speed
9.6 GT/s QPI (4800 MHz)
5 GT/s DMI
Clock multiplier
23
Package
2011-land Flip-Chip Land Grid Array
Socket
Socket 2011-3 / R3 / LGA2011-3
Size
2.07" x 1.77" / 5.25cm x 4.5cm
Microarchitecture
Haswell
Platform
Grantley-EP
Processor core
Haswell-EP
Core steppings
M0 (QG99)
M1 (QGPL, SR1YA)
CPUID
306F2 (SR1YA)
Manufacturing process
22nm
Data width
64 bit
The number of cores
10
The number of threads
20
Floating Point Unit
Integrated
Level 1 cache size
10 x 32 KB 8-way set associative instruction caches
10 x 32 KB 8-way set associative data caches
Level 2 cache size
10 x 256 KB 8-way set associative caches
Level 3 cache size
25 MB shared cache
Physical memory
768 GB
Multiprocessing
Up to 2 processors
Features
MMX instructions
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSSE3 / Supplemental Streaming SIMD Extensions 3
SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4
AES / Advanced Encryption Standard instructions
AVX / Advanced Vector Extensions
AVX2 / Advanced Vector Extensions 2.0
BMI / BMI1 + BMI2 / Bit Manipulation instructions
F16C / 16-bit Floating-Point conversion instructions
FMA3 / 3-operand Fused Multiply-Add instructions
EM64T / Extended Memory 64 technology / Intel 64
NX / XD / Execute disable bit
HT / Hyper-Threading technology
VT-x / Virtualization technology
VT-d / Virtualization for directed I/O
TBT 2.0 / Turbo Boost technology 2.0
TXT / Trusted Execution technology
Low power features
Enhanced SpeedStep technology
Integrated graphics
None
Memory controller The number of controllers
2
Memory channels per controller
2
Supported memory
DDR4-1600, DDR4-1866, DDR4-2133
DIMMs per channel
3
Maximum memory bandwidth (GB/s)
68
ECC supported
Yes
Other peripherals
Direct Media Interface 2.0
Quick Path Interconnect v1.1 (2 links)
PCI Express 3.0 interface (40 lanes)
V core
0.65V - 1.3V
Maximum operating temperature
78.9 C
Thermal Design Power
105 Watt
Notes on Intel Xeon E5-2650 v3
The processor has 43W TDP in C1E state, 33W TDP in C3 state, and 13W TDP in C6 state
The processor has the following security, data protection and/or software features: Intel Secure Key, vPro technology and OS Guard.
