NZXT F Series 360 RGB Core PWM Fan single frame with Three Fans Black
NZXT F Series 360 RGB Core PWM Fan single frame with Three Fans Black
- Brand: NZXT
- MPN: RF-U36HF-B1
- Part #: FANNZX0180
- UPC: 810074844529
What PB Tech customers are saying about this product...
See More Reviews"Rather than buying two separate single fans, this is the option if you are looking for a tidy cable and RGB sync."
"Seems to work well, mostly purchased for aesthetics. Great that it includes an adapter for PWM and 5V RGB unlike some other fans with proprietary connectors so that was a big plus"
"Got these to replace the stock fans that came on the NZXT Kraken AIO cooler, because aRGB. Not only do the LEDs throw a good amount of light, the fans also perform better than the ...view more"
COMBO DEALS: Buy Together and SAVE!
Posh TA-001 ESD Anti Static Wrist Strap Band - 1.8M (Blue)
$6.50
$6.50
ProsKit SD-9857M DIY Tool 57 IN 1 Screwdriver Set For Cell Phone, Notebook, Electronic Field, Home,...
$29.75
$29.75
Dynamix CK-AD400 400ml Air Duster, Super High Pressure, Non-Flammable Safe on all Electronics,...
$11.54
$11.54
NZXT TKL Mechanical Keyboard - Black Gateron Red Switches
$99.00
$99.00
Features
F360 RGB Core - 360mm Single-Frame RGB Fan Unit
NZXT F Series RGB Core single-frame fans seamlessly integrate multiple fans for effortless installation while offering superior cooling, whisper-quiet performance, and striking RGB visuals.
- Single-frame unit with integrated fans streamlines installation, setup, and lighting control-no need to connect individual fans.
- Simply connect a single cable to an NZXT controller (sold separately) for lighting and speed control via NZXT CAM software. Or, connect to any motherboard's 5V ARGB header using the included splitter cable.
- Fan blade design boosts static pressure to push air through tight spaces while ensuring optimal airflow. Suitable for both intake and exhaust.
- Fluid dynamic bearings ensure quiet, stable operation across an exceptional 60,000 hour lifespan.
- Eight individually-addressable RGB LEDs per fan hub are diffused through semi-translucent blades for brilliantly colorful visuals.
- PWM-controlled fans dynamically adjust spinning speeds based on PC temperatures for optimal efficiency and reduced noise.
- Anti-vibration rubber corners effectively eliminate noise caused by vibrations for hushed performance at any speed.
- Control lighting and fan speeds via CAM software when connected to an NZXT controller (sold separately).
All-in-one Design
Single-frame unit with integrated fans streamlines installation, setup, and lighting control.
Versatile Connectivity
Simply connect a single cable to an NZXT controller (sold separately) for lighting and speed control via NZXT CAM software. Or, connect to any motherboard's 5V ARGB header using the included splitter cable.
Optimal Performance
Blade design boosts static pressure to push air through tight spaces with superior airflow.
Fluid Dynamic Bearings
Ensures low noise, high rotational stability, and a 60,000-hour fan lifespan.
Radiant RGB Lighting
8 aRGB LEDs per fan hub shine through semi-translucent blades and frame side windows.
PWM Control
Dynamically adjusts fan speeds based on PC temperatures for optimal efficiency*.
*Requires PWM connection to motherboard or controller (sold separately)
Silent Operation
Anti-vibration rubber corners dampen noise and Zero RPM Mode* shuts fans off during light loads.
*Requires an NZXT controller or NZXT motherboard, each sold separately.
Do More with CAM
Control fan speeds, personalize lighting effects, and sync with other NZXT products*.
*Requires an NZXT controller or NZXT motherboard, each sold separately.
Specifications
Reviews
Do you own this product?
Simplify everything
Rather than buying two separate single fans, this is the option if you are looking for a tidy cable and RGB sync.
Works great, love having the 3 fans in a single frame. Makes for a clean, tidy look
Seems to work well, mostly purchased for aesthetics. Great that it includes an adapter for PWM and 5V RGB unlike some other fans with proprietary connectors so that was a big plus
Good upgrade
Got these to replace the stock fans that came on the NZXT Kraken AIO cooler, because aRGB. Not only do the LEDs throw a good amount of light, the fans also perform better than the standard AIO cooler fans. CPU temps are avg 2 deg C cooler and also run a little quieter.
Bonus is you do not need a controller to run the aRGB as long as your mobo has an aRGB socket to plug into.
Great option for PC builders
Cable management can be a pain in the neck so these are perfect. I have three of these now to complete the desired look of a clean black build and they look great.
Easy to setup
Used with NZXT motherboard and Case. No issues installing. Gives off a decent amount of light, depending on the colour chosen. Looks good and works well.
Best
Good choice
Accessories
Delivery & Pick-up
Returns & Warranty
Popular Case Fans
DEEPCOOL XFAN 120 120mm Hydro Bearing Case Fan with 4-pin Molex...
DEEPCOOL FD12 Black 3 Pack 120mm PWM Case Cooling Fan, Triple...
DEEPCOOL FD12 ARGB Black 3 Pack 120mm PWM Case Cooling Fan,...
DEEPCOOL FC120 White 3 Pack 120mm A-RGB PWM Case Cooling Fan, Low...
Phanteks M25 G2 120mm PWM ARGB Fan, Reverse, Black, 3 Pack
NZXT F Series 360 RGB Core PWM Fan single frame with Three Fans Black
- Brand: NZXT
- MPN: RF-U36HF-B1
- Part #: FANNZX0180
- UPC:810074844529
Product URL: https://www.pbtech.com/pacific/product/FANNZX0180/NZXT-F-Series-360-RGB-Core-PWM-Fan-single-frame-wi?is-review=1
Features
F360 RGB Core - 360mm Single-Frame RGB Fan Unit
NZXT F Series RGB Core single-frame fans seamlessly integrate multiple fans for effortless installation while offering superior cooling, whisper-quiet performance, and striking RGB visuals.
- Single-frame unit with integrated fans streamlines installation, setup, and lighting control-no need to connect individual fans.
- Simply connect a single cable to an NZXT controller (sold separately) for lighting and speed control via NZXT CAM software. Or, connect to any motherboard's 5V ARGB header using the included splitter cable.
- Fan blade design boosts static pressure to push air through tight spaces while ensuring optimal airflow. Suitable for both intake and exhaust.
- Fluid dynamic bearings ensure quiet, stable operation across an exceptional 60,000 hour lifespan.
- Eight individually-addressable RGB LEDs per fan hub are diffused through semi-translucent blades for brilliantly colorful visuals.
- PWM-controlled fans dynamically adjust spinning speeds based on PC temperatures for optimal efficiency and reduced noise.
- Anti-vibration rubber corners effectively eliminate noise caused by vibrations for hushed performance at any speed.
- Control lighting and fan speeds via CAM software when connected to an NZXT controller (sold separately).
All-in-one Design
Single-frame unit with integrated fans streamlines installation, setup, and lighting control.
Versatile Connectivity
Simply connect a single cable to an NZXT controller (sold separately) for lighting and speed control via NZXT CAM software. Or, connect to any motherboard's 5V ARGB header using the included splitter cable.
Optimal Performance
Blade design boosts static pressure to push air through tight spaces with superior airflow.
Fluid Dynamic Bearings
Ensures low noise, high rotational stability, and a 60,000-hour fan lifespan.
Radiant RGB Lighting
8 aRGB LEDs per fan hub shine through semi-translucent blades and frame side windows.
PWM Control
Dynamically adjusts fan speeds based on PC temperatures for optimal efficiency*.
*Requires PWM connection to motherboard or controller (sold separately)
Silent Operation
Anti-vibration rubber corners dampen noise and Zero RPM Mode* shuts fans off during light loads.
*Requires an NZXT controller or NZXT motherboard, each sold separately.
Do More with CAM
Control fan speeds, personalize lighting effects, and sync with other NZXT products*.
*Requires an NZXT controller or NZXT motherboard, each sold separately.
Specifications
Inside the Box
RGB Core Fan x1
Mounting Screws x4
Splitter Cable x1
DIMENSIONS
Height
360 mm
Width
120 mm
Depth
26 mm
FANS
Speed
500 - 2,400 ± 250 RPM per fan
Airflow
75.12 CFM per fan
Static Pressure
3.3 mm H2O per fan
Noise
30.00 dBA per fan
Power Consumption
12V DC, 0.56A, 6.72W / 5V DC, 0.45A, 2.25W
Bearing
Fluid Dynamic Bearing
Output LED
8 LEDs per Fan
Connector
8-pin for PWM & RGB
Cable Length
1 x 600 mm
Material
Plastic, Rubber, PCB
Life
60,000 Hours
CABLE
Splitter Cable Connections & Cable Length
4-pin PWM Fan Cable (1 x 300 mm) / 5V RGB & 4-pin NZXT RGB Cable (1 x 100 mm)
