Aetina Fanless System ORIN NANO 4GB 1 x HDMI, 1 x GbE, 2 x USB, 128GB SSD, E/M Key, 12 to 24 VDC input, -25 C + 55 C
- Brand: Aetina
- MPN: AIE-CO21
- Part #: IPCAEA10042

Product URL: https://www.pbtech.com/pacific/product/IPCAEA10042/Aetina-Fanless-System-ORIN-NANO-4GB-1-x-HDMI-1-x-G
Features
- Supports NVIDIA Jetson Orin™ NX and Orin Nano™ module
- 1 x M.2 E-Key, 1 x M.2 M-Key (128GB built-in)
- 1 x RJ-45 GbE port
- Wide input voltage range from 12 to 24 VDC
- Operating temperature -25°C ~ +55°C
- Fanless Design
-- Up to 80 x AI performance enables AI inference in the smallest Jetson form factor
The NVIDIA Jetson Orin NX module offers up to 100 TOPS, 3 times more than the NVIDIA Jetson AGX Xavier™ module, and approximately 5 times the NVIDIA Jetson Xavier™ NX module; NVIDIA Jetson Orin Nano offers up to 40 TOPS, 80 times the NVIDIA Jetson Nano™ module. In other words, NVIDIA Jetson Orin NX and Orin Nano module set new standard for mainstream and entry-level edge AI in the smallest Jetson form factor.
-- Sufficient M.2 for internal and external storage expansion
AIE-CO21 are fanless systems, built in 1x M.2 E-Key for Wifi/BT and 1x M.2 M-Key for storage. To avoid insufficient data storage for edge computing, AIE-CO21 support external M.2 2242 NVMe with fast data transmission.
-- Wide input power and fanless design for smart city and smart agriculture
To cater to diverse applications, such as smart city and smart agriculture, where cost-effective maintenance and improved reliability are crucial, AIE-CO21 have been specifically designed with a fanless and silent mechanism. These systems are capable of operating within a wide temperature range of -25°C to 55°C. Additionally, they support a wide input power range from 12 to 24 VDC, enabling flexible power supply options.
Specifications
Model Number
AIE-CO21
Module Compatibility
NVIDIA Jetson Orin Nano 4GB
AI Performance
20 TOPS
GPU
512 Core NVIDIA Ampere, with 16 Tensor Cores
CPU
6-core Arm® Cortex®-A78AE v 8.2 64-bit 1.5MB L2 + 4MB L3
Memory
4GB 64-bit LPDDR5 34GB/s
Storage
1 x M.2 M-Key 2242 (128GB built-in)
Display
1 x HDMI 2.0 Type A
RTC
With super capacitor, battery (optional)
LAN
1 x RJ-45 GbE ports
USB
2 x USB 3.2 Gen2 Type A (supports up to 10Gbps shared)
1 x OTG Type-C
I/O Interfaces
5 x GPIO,
1 x UART,
1 x I2C,
1 x CAN (isolation; support CAN FD)
Expansion
1 x M.2 E-Key 2230 (WiFi/BT)
1 x M.2 M-Key 2242 (NVMe 128GB built-in)
MISC. Function
1 x Power / 1 x Recovery Button / 1 x Reset Button
1 x CAN 2.0b with isolation
Power Input/Connector
DC-in 12-24VDC / 2-Pin Terminal Block
Power Consumption
Idle: 3.4 W
Full Loading: 25.08* W
*For more test condition information, please refer to user manual
Dimension (WxDxH)
130 x 90.2 x 72 mm (5.11 x 3.55 x 2.83 in)
Mounting
Wall Mount (optional) / Din Rail (optional)
Net Weight
0.927 kg (2.044 lb)
Vibration
1 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
Shock
10 G, IEC 60068-2-27, half sine, 11 ms duration
Temperature
Operating Temp. -25°C ~ +55°C (-13°F ~ +131°F) with 0.5 m/s air flow
Storage Temp. -40°C ~ +85°C (-40°F ~ +185°F)
Humidity
95% @ 40°C (104°F) (non-condensing)
Software Support
Linux (Support Jetpack 5.0 above)
Certification
CE / FCC Class A / UKCA
