Advantech ADAM-4570L-DE 2-PORT RS-232 SERIAL DEVICE SERVER

PB Tech price
PB Tech price
NZD $ 340 .36
$ 340 .36
$340.36  +GST
$340.36

Advantech ADAM-4570L-DE 2-PORT RS-232 SERIAL DEVICE SERVER

  • Brand: Advantech
  • MPN: ADAM-4570L-DE
  • Part #: IPCAVH010015
  • UPC:
PB Tech price
NZD $ 340 .36 $ 340 .36


Delivery: Order now and it ships on 30 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$340.36  +GST
$340.36

Features

ADAM-4571 and ADAM-4571L are fast and cost effective data gateways between serial and Ethernet interfaces. The units also bring the advantages of remote management and dataaccessibility to RS-232/422/485 devices. The transmission speed of the units is up to 230 kbps, meeting the demands for high-speed data exchanges. In addition, you can useWindows utility to configure ADAM-4571 and ADAM-4571L without further programming. The units not only protect your current hardware investment but also ensure future networkexpandability. Since the protocol conversion is transparent, all your existing devices can be seamlessly integrated with an Ethernet network. Therefore, ADAM-4571 and ADAM-4571Lcan be used in security systems, factory automation, SCADA, transportation and more. ADAM-4571 and ADAM4571L link both your existing human-machine interface(HMI) PC andyour RS-232/422/485 devices with Ethernet cables.ADAM-4571 and ADAM-4571L come with a Windows configuration and port-mapping utility. The configuration tool can auto-detect all Ethernet Data Gateway devices on the localnetwork, and let you adjust all settings. The port mapping utility helps you to setup up COM ports for Windows NT/2000/XP platform. This helps you configure all ports to meetyour needs.

- Supports RS-232 serial communication
- Supports baud rate up to 921.6 kbps
- Provides COM port redirection (Virtual COM) mode
- Allows a max. of 5 hosts to access one serial port
- Built-in 15 KV ESD protection for all serial signals
- Provides 10/100 Mbps auto-sensing Ethernet port
- Supports auto re-connection function
- Supports Windows 2000/XP/Vista drivers
- Supports remote update firmware

Specifications

EMC

CE, FCC

EMI

EN 55011/ EN 55032 Class A, EN 61000-6-4, FCC Part 15 Subpart B Class A

EMS

EN 61000-4-2 (Level 2), EN 61000-4-3 (Level 2), EN 61000-4-4 (Level 2), EN 61000-4-5 (Level 2), EN 61000-4-6 (Level 2), EN 61000-4-8 (Level 2), EN55024

Freefall

NA

RJ-45 Port Connector Type

RJ-45

Ethernet Standard

IEEE 802.3 , 802.3u

RJ-45 Port Number

1

RJ-45 Transmission Speed

10/100 Mbps

Serial Port Connector Type

RJ48

Serial Port Number

2

RS-232

Yes

Baud Rate

50 ~ 921.6 Kbps

Humidity (Operating Range)

5~95% RH

Temperature (Min. Operating)

-10°C (14°F)

Temperature (Max. Operating)

60°C (140°F)

Temperature (Operating Range)

-10 ~ 60°C (14 ~ 140°F)

Temperature (Storage Range)

-20 ~ 80°C (-4 ~ 176°F)

Dimensions (W x H x D)

70 x 112 x 25 mm

Enclosure (Plastic)

Yes

IP Rating

IP30

Mounting (DIN-rail)

Yes

Mounting (Wall)

Yes

Weight

125 g

Power Consumption

2.5W

Power Input (DC)

10 ~ 30 VDC

Power Operating Current

0.3A @ 12 V

Configuration

Windows utility, Web Browser

Driver

Windows XP/7/8.1/10, Windows Server 2003/2008/2012/2016/2019, and Linux

Operation Mode

Virtual COM, TCP/UDP server TCP/UDP client

Manufacturer Part No:
ADAM-4570L-DE
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
IPCAVH010015
Product Model:
ADAM-4570L-DE
