Advantech ADAM-5017H-BE 8-channel High-speed Analog Input Module
- Brand: Advantech
- MPN: ADAM-5017H-BE
- Part #: IPCAVH220105

Product URL: https://www.pbtech.com/pacific/product/IPCAVH220105/Advantech-ADAM-5017H-BE-8-channel-High-speed-Analo
Features
ADAM-5017H
8-channel High-speed Analog Input Module
- Accuracy: ±0.1% or better
- Effective resolution: 12-bit plus sign bit
- 1000 Hz bandwidth
- High sampling rate:ADAM-5000/485&5000E: 100 samples/sec, ADAM-5510 & ADAM-5511: 8000 samples/sec max
- 3000VDC Isolation voltage protection
- Distinct range settings allowed on each channel
- Input type: mV, V, mA
Specifications
Channels
8 differential
Effective Resolution
12-bit plus sign bit
Input Type
mV, V, mA
Input Range
±250 mV, ±500 mV, ±1 V, ±5 V, ±10 V, 0 ~ +500 mV, 0 ~ +1 V, 0 ~ +5 V, 0 ~ +10 V, 0 ~ 20 mA, 4 ~ 20 mA
Isolation Voltage
3000 VDC
Sampling Rate
Depends on base unit
ADAM-5000/485 & 5000E: 100 samples/sec
ADAM-5510: 8000 samples/sec max.: one ADAM-5017H installed
ADAM-5510KW: Up to 100 samples/sec
ADAM-5511: Up to 100 samples/sec
ADAM-5000/TCP: 1000 samples/sec max.: depending on the performance of client server or controller
Input Impedance
20 M? (voltage inputs)
125 ? (current inputs)
Bandwidth
1 kHz
Signal Input Bandwidth
1 kHz for both voltage and current inputs
Accuracy
±0.1% or better
CMR @ 50/60 Hz
92 dB min
Power Consumption
1.75 W (typical); 2.2 W (max)
Other
Distinct Range Settings Allowed on Each Channel
Note
The voltage difference between any two pins must not exceed ±15 V
