Advantech ADAM-6250-B 8DO/7DI IoT Modbus/SNMP/MQTT 2Ports Ethernet Remote I/O
- Brand: Advantech
- MPN: ADAM-6250-B
- Part #: IPCAVH220157

Product URL: https://www.pbtech.com/pacific/product/IPCAVH220157/Advantech-ADAM-6250-B-8DO7DI-IoT-ModbusSNMPMQTT-2P
Features
8DI/7DO IoT Modbus/SNMP/MQTT 2Ports Ethernet Remote I/O
- 8ch digital input(counter)/7ch digital output(pulse output)
- Protocols:MQTT(TLS),SNMP,Modbus TCP,RESTful,ASCII
- GCL to perform basic logic control rules
- Cloud access: Data update to Azure
- Auto-bypass function to ensure daisy-chain data transmission
- Peer-to-Peer function to map I/O status
- Built-in web server
- Watchdog timer to recover the system
Specifications
Communications
Interface
Ethernet
Environment
Isolation Voltage
2,500 VDC
Operating Temperature
-40~70 °C (-40~158 °F)
General
Connectors
2 x RJ45, 1 x 15-pin plug-in screw terminal, 1 x 5-pin plug-in screw terminal
Protocol
Modbus/TCP, TCP/IP, UDP, HTTP, DHCP, MQTT, SNMP, ASCII command
Isolated Digital Input
Channels
8
Input Voltage
Dry Contact
Logic level 1: close to GND
Logic level 0: open
Wet Contact
Logic level 1: 10~30 VDC and -10~-30 VDC
Logic level 0: -3~3 VDC
Isolated Digital Output
Channels
7
Output Type
Sink
Output Voltage
10~30 VDC
Sink Current
100 mA max./channel
Power Requirements
Input Voltage
10~30 VDC
Counter/Encoder Input
Max. Input Frequency
3 kHz
Channels
8
