Advantech EKI-2528I-BE 8 10/100Mbps Unmanaged Ethernet Switch, -40 75
- Brand: Advantech
- MPN: EKI-2528I-BE
- Part #: IPCAVH220473

Product URL: https://www.pbtech.com/pacific/product/IPCAVH220473/Advantech-EKI-2528I-BE-8-10100Mbps-Unmanaged-Ether
Features
8FE Unmanaged Ethernet Switch, -40~75?
- Provides 8-port Fast Ethernet ports with Auto MDI/MDI-X
- Supports 10/100 Mbps Auto-Negotiation
- Provides compact size with DIN-rail/Wall mount, and IP30 metal mechanism
- Supports redundant 12 ~ 48 VDC power input and P-Fail relay
- EKI-2528DI supports wide operating temperatures from -40 to 75°C
Specifications
General
Ethernet Port Count
8
Mounting
DIN, Panel
Power
12-48VDC
Technology
Ethernet
Temperature
-40 to 75C
Unmanaged
Yes
Certification
EMI
FCC Part 15 Subpart B Class A, EN 55022 Class A
EMS
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-2, EN 61000-6-4
Safety
DNVGL
Environment
Temperature (Min. Operating)
-40°C (-40°F)
Temperature (Max. Operating)
75°C (167°F)
Operating Temperature
-40 ~ 75°C (-40 ~ 167°F)
Storage Temperature
-40 ~ 85°C (-40 ~ 185°F)
Ethernet Communication
Fiber Port Number
-
Fiber Port Interface
-
Fiber Port Connector Type
-
Fiber Transmission Distance
-
Fiber Transmission Speed
-
RJ-45 Port Number
8
RJ-45 Port Connector Type
RJ-45
RJ-45 Transmission Distance
100 m
RJ-45 Transmission Speed
10/100 Mbps
Mechanism
Mounting (DIN-rail)
Yes
Mounting (Stack)
-
Mounting (Panel)
-
Mounting (Wall)
Yes
Mounting (Rack Mount)
-
Mounting (Pole Mount)
-
Dimensions (W x H x D)
30 x 140 x 95 mm (1.18' x 5.51' x 3.74 in.)
Enclosure (Plastic)
-
IP Rating
IP30
PoE Information
PoE Port Number
-
PoE Budget
-
PoE Output
-
Support PoE
No
Power
Power Connector Type
6-pin removable screw terminal
Power Consumption
3.93W
Power Input (AC)
-
Power Input (DC)
12 ~ 48 VDC, Marine 24VDC
Power Input (PoE)
-
Power Input (Battery)
-
Redundant Dual Inputs
Yes
