Advantech IMC-771-SXL Managed Modular Media Converter, 1000Mbps, Single mode 1550nm, 100km, SC (also known as iMcV 850-15515)
Advantech IMC-771-SXL Managed Modular Media Converter, 1000Mbps, Single mode 1550nm, 100km, SC (also known as iMcV 850-15515)
- Brand: Advantech
- MPN: IMC-771-SXL
- Part #: IPCAVH220944
- UPC:
- Brand: Advantech
- MPN: IMC-771-SXL
- Part #: IPCAVH220944
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Industrial PCs & IoT





Advantech IMC-771-SXL Managed Modular Media Converter, 1000Mbps, Single mode 1550nm, 100km, SC (also known as iMcV 850-15515)
- Brand: Advantech
- MPN: IMC-771-SXL
- Part #: IPCAVH220944

Product URL: https://www.pbtech.com/pacific/product/IPCAVH220944/Advantech-IMC-771-SXL-Managed-Modular-Media-Conver
Features
Managed Modular Media Converter, 1000Mbps, Single mode 1550nm, 100km, SC (also known as iMcV 850-15515)
- Variety of choices: multi-mode, single-mode or single-strand including SFP form factor
- The modular, hot-swappable architecture reduces operational costs associated with product installation, upgrades, and maintenance
- SNMP manageable
- Supports configuration control
- Supports Link Fault Pass Through (LFPT)
For more information: https://advdownload.advantech.com/productfile/PIS/IMC-771I-SFP/Product%20-%20Datasheet/IMC-771I-SFP20190424221611.pdf
Specifications
Technical
IEEE 802.3ab, 802.3z (IMC-771 series)
Link Fault Pass-Through (LFPT)
Support GUI-Based iView²
Includes Diagnostic LEDs
Includes Hot-swappable Architecture
Meantime Before Failure (MTBF)
1.9 million hours (IMC-770I-2SFP & IMC-771 series)
Ethernet Speed
1000Mbps
Optical Mode
Single-Strand
Wavelength
1550nm
Distance
100km
Optical Connector
1 x SC
Operating Temperature
0 to +50 °C (+32 to +122 °F)
Storage Temperature
-25 to +70 °C (-13 to +158 °F)
Operating Humidity
5 ~ 95% (non-condensing)
0 ~ 10,000 ft. altitude
Dimensions (H x W x D)
10.74 x 2.0 x 7.05 cm (4.19 x 0.78 x 2.75 in)
Weight
0.11 kg (0.30 lb)
Certifications(IMC-771 series)
CE FCC Class A
