Advantech PPC-312-RJ60A 12.1" PPC w/Intel J6412, Res.

PB Tech price

NZD $ 1,733 .34

$ 1,733 .34

Advantech PPC-312-RJ60A 12.1" PPC w/Intel J6412, Res.

Brand: Advantech
MPN: PPC-312-RJ60A
Part #: IPCAVH221267
UPC:

PB Tech price

NZD $ 1,733 .34

In stock at Supplier

Delivery: Order now and it ships on 25 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Advantech
MPN: PPC-312-RJ60A
Part #: IPCAVH221267
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

PPC-312 EHL is an industrial panel PC with 12.1" XGA LCD, powered by Intel Celeron quad core J6412 processor. With aesthetic aluminum alloy enclosure, PPC-312 EHL ensures fanless reliability and easy maintenance in diverse industrial applications. Moreover, it provides more faster and flexible connection via 2 x 2.5G Ethernet port, 2 x USB 3.1 and 1 x Type C (USB only). The PPC-312 EHL is ideal for MES, processing and general industrial equipment integration.

- Industrial-grade 12" XGA TFT LCD with 30K backlight lifetime
- Durable true-flat touchscreen with 5-wire resistive/projected capacitive touch control
- Intel® Celeron® J6412 quad-core, 2.0 GHz, processor
- Up to 32 GB DDR4 SDRAM
- 1 x RS-232, 1 x RS-232/422/485, 2 x USB 2.0, and 2 x USB 3.1
- Compact, fanless design with solid aluminum alloy enclosure and IP66-rated front panel
- Supports E-key for wireless module
- Supports expansion via M.2 slot
- Supports Windows Embedded Linux and Android OS

For more information: https://advdownload.advantech.com/productfile/PIS/PPC-312%20EHL/file/PPC-312-EHL_DS(062024)20240621103825.pdf

Specifications

MPN

PPC-312-RJ60A
12" PPC w/Intel J6412, Resistive

Environment

Ingress Protection

Front Panel IP66

Operating Temperature

-10~50 °C (14~122 °F)

Relative Humidity

95% RH (non-condensing)

Storage Temperature

-20~60 °C (-4~140 °F)

Vibration Protection

2 Grms, random

Hardware

Certification

CE, FCC Class B, BSMI, CB, UL, CCC, UKCA, VCCI

CPU

Intel® Celeron® J6412 2.00 GHz, Quad core

Ethernet

Intel® i225-LM

Expansion

1 x M.2 E Key 2230

Hardware Security

TPM 2.0

I/O

1 x RS-232, 1 x RS-232/422/485, 2 x USB 3.0, 2 x USB 2.0, 1 x HDMI

LAN

2 x 10/100/1000/2500 Mbps

Memory

1 x DDR4 SO-DIMM Slot

OS Support

Microsoft® Windows 10 LTSC, Microsoft® Windows 11, Linux, Android

Power Consumption

40 W @ 19 VDC

Power Input

12~30 VDC

I/O Interface

Power Connector

1 x 2-Pin Terminal Block

Serial Ports

1 x RS-232, 1 x RS-232/422/485

LCD Display

Backlight Life (hrs)

30,000

Display Size

12"

Luminance (cd/m²)

500

Max. Resolution

1024 x 768

Viewing Angle (H/V°)

170/178

Mechanical

Dimension (W x H x D)

317 x 246 x 52 mm

Enclosure

Die-cast aluminum alloy

Mounting

Stand, Wall, VESA, Panel

Weight (Net)

3.16 kg (8.14 lb)

Touchscreen

Touch Type

5-wire resistive

USB Vision

Connector

2 x USB 3.0 Type A, 2 x USB 2.0 Type A

Manufacturer Part No:

PPC-312-RJ60A

Brand:

Advantech

Product Type:

UPC

Product Family:

Shipping Weight:

1 kg

PB Part No:

IPCAVH221267

Product Model:

PPC-312-RJ60A

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
