Advantech PPC-3211W-P77A 21.5" FHD PPC w/Intel i7-7600U, P-Cap

PB Tech price

NZD $ 5,820 .00

$ 5,820 .00

Advantech PPC-3211W-P77A 21.5" FHD PPC w/Intel i7-7600U, P-Cap

Brand: Advantech
MPN: PPC-3211W-P77A
Part #: IPCAVH221299
UPC:

PB Tech price

NZD $ 5,820 .00

In stock at Supplier

Delivery: Order now and it ships on 25 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Advantech
MPN: PPC-3211W-P77A
Part #: IPCAVH221299
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

PPC-3211W is a new generation industrial interactive panel PC with a 21.5" TFT full HD LCD 1920 x 1080 resolution, which features a flat, sleek design to greatly reduce maintenance effort. Pre-installed Intel® Core™ i processor and designed fanless architecture, PPC-3211W provide high performance and reliable system for factory automation or variety of industrial applications. Furthermore, with the provision of multiple I/O, dual Intel® Gigabit ethernet, PCI/PCIe expansion, PPC-3211W ensures easy integration and connectivity.

- 21.5" true-flat Full HD LCD panel with projected capacitive touchscreen, anti-glare coating
- Intel® Core™ i5-7300U(default); i7-7600U/i3-7100U(optional) processor with fanless system design
- Supports PCIe x4 or PCI expansion
- 1x isolated RS-422/485 with auto flow
- Wide input power range (9 ~ 32 VDC)
- Dual Gigabit Ethernet with IEEE1588 support
- 3x Independent displays
- 1x M.2 bay (2242) for storage only & 1x TPM 2.0 internal support (optional)
- No RED Certification

For more information: https://advdownload.advantech.com/productfile/PIS/PPC-3211W/file/PPC-3211W_DS(052724)20240527144429.pdf

Specifications

MPN

PPC-3211W-P77A
21.5" PPC w/Intel i7-7600U, P-CAP

Hardware

CPU

7th Gen. Intel® Core™ i7-7600U 2.8 GHz Dual-Core

Memory

1 x DDR4 SO-DIMM Slot

Storage

1 x SATA M.2 SSD slot (2242 B-Key), 2 x 2.5" SSD/HDD Bay

LAN

2 x 10/100/1000 Mbps2 x 10/100/1000 Mbps

Ethernet

Intel i210-IT GbE, 802.1Qav, IEEE1588/802.1AS, 802, Intel i219-IT GbE

I/O

2 x RS-232, 1 x RS-422/485, 4 x USB 3.0,
1 x Line Out, 1 x Mic In, 1 x VGA, 1 x DP

Expansion

1 x Mini PCIe, 1 x PCIe x 4, 1 x PCI

Watchdog Timer

1~255 s

OS Support

Microsoft® Windows 10, Microsoft® Windows 10 LTSC, Linux

Power Input

9~32 VDC

Power Consumption

75 W @ 19 VDC

Certification

CE, FCC Class B, BSMI, CB, UL, CCC, UKCA, VCCI

I/O Interface

Serial Ports

4 x RS-232, 1 x RS-422/485

Displays

1 x VGA, 1 x DP

Audio

Line-Out, Mic-In

Power Connector

1 x 2-Pin Terminal Block

USB Vision

Connector

4 x USB 3.0 Type A

Mechanical

Dimension (W x H x D)

558 x 350 x 64 mm

Weight (Net)

7.7 kg (17.1 lb)

Enclosure

Die-cast aluminum alloy, PC + ABS

Mounting

Stand, Wall, VESA, Panel

Touchscreen

Touch Type

PCAP

LCD Display

Display Size

21.5"

Max. Resolution

1920 x 1080

Viewing Angle (H/V°)

178/178

Luminance (cd/m²)

300

Backlight Life (hrs)

50,000

Environment

Operating Temperature

0~50 °C (32~122 °F)

Storage Temperature

-20~60 °C (-4~140 °F)

Relative Humidity

95% RH (non-condensing)

Shock Protection

10 G, half sine

Vibration Protection

2 Grms, random

Ingress Protection

Front Panel IP66

Manufacturer Part No:

PPC-3211W-P77A

Brand:

Advantech

Product Type:

UPC

Product Family:

Shipping Weight:

1 kg

PB Part No:

IPCAVH221299

Product Model:

PPC-3211W-P77A

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
