Advantech PPC-415W-PD3A 15.6" PPC w/Intel i3-1315URE, P-CAP

PB Tech price
PB Tech price
NZD $ 3,233 .34
$ 3,233 .34
$3,233.34  +GST
$3,233.34

Advantech PPC-415W-PD3A 15.6" PPC w/Intel i3-1315URE, P-CAP

  • Brand: Advantech
  • MPN: PPC-415W-PD3A
  • Part #: IPCAVH221313
  • UPC:
PB Tech price
NZD $ 3,233 .34 $ 3,233 .34


Delivery: Order now and it ships on 26 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$3,233.34  +GST
$3,233.34

Features

Designed for high-performance computing 13th gen applications, PPC-415W with a 15.6" FHD provides a superior human-machine interface and reliability, with multi-touch screen, rich I/O and aluminum alloy front bezel. The inclusion of PCIe/PCI slot for fieldbus or proprietary card expansion increases the system's compatibility for diverse applications. In addition, Time Sensitive Network(TSN)configuration integrated allows more possibilities for optimized industrial applications

- 15.6" true-flat Full HD LCD panel with projected capacitive touchscreen, anti-glare coating
- Intel® Core™ i3-1315URE processor with fanless system design
- Supports PCIe x4 or PCI expansion
- 1x isolated RS-422/485 with auto flow
- Wide input power range (9 ~ 32 VDC)
- Dual 2500BASE-T Ethernet Supports Time-Sensitive Network(TSN) technology
- 3x Independent displays
- 1x M.2 bay (2242/2280) for storage only
- Support TPM2.0 hardware security

Specifications

General

MPN

PPC-415W-PD3A

Description

15.6" PPC w/Intel i3-1315URE, P-CAP

Hardware

CPU

13th Gen. Intel® Core™ i3-1315URE 1.20GHz Hexa-Core

Memory

2 x SO-DIMM Slot with DDR5 4800MHz

Storage

1 x 2.5" SSD/HDD Bay, 1 x NVMe PCIe x 4/SATA M.2 slot (2242/2280 M-key)

LAN

2 x 10/100/1000/2500 Mbps

Ethernet

Intel® i226-LM

I/O

2 x RS-232, 1 x RS-422/485, 3 x USB 3.2, 1 x USB 2.0, 1 x Line Out, 1 x Mic In, 1 x HDMI, 1 x DP

Expansion

1 x M.2 E key 2230, 1 x PCIe x4 or 1 x PCI

Watchdog Timer

1~255 s

Certification

CE, FCC Class B, BSMI, CB, UL, CCC, UKCA, VCCI

OS Support

Microsoft® Windows 10 LTSC, Microsoft® Windows 11, Linux

Power Input

9~32 VDC

Power Consumption

105 W @ 19 VDC

I/O Interface

Serial Ports

2 x RS-232, 1 x RS-422/485

Audio

Line-Out, Mic-In

Displays

1 x HDMI, 1 x DP

Power Connector

1 x 2-Pin Terminal Block

USB Vision

Connector

3 x USB 3.2 Type A,1 x USB 2.0 Type A

Mechanical

Dimension (W x H x D)

420 x 269 x 59 mm

Enclosure

Die-cast aluminum alloy, PC + ABS

Mounting

Stand, Wall, VESA, Panel

Weight (Net)

5.4 kg (11.90 lb)

Environment

Relative Humidity

95% RH (non-condensing)

Vibration Protection

2 Grms, random

Operating Temperature

-20~60 °C (-4~140 °F)

Storage Temperature

-40~60°C (-40~140°F)

Shock Protection

10 G, half sine

Ingress Protection

Front Panel IP66

Touchscreen

Touch Type

PCAP

LCD Display

Display Size

15.6"

Max. Resolution

1920 x 1080

Viewing Angle (H/V°)

170/170

Luminance (cd/m2)

450

Backlight Life (hrs)

50,000

Manufacturer Part No:
PPC-415W-PD3A
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
IPCAVH221313
Product Model:
PPC-415W-PD3A
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
