Advantech TPC-1051WP-E3AE 10.1" WXGA Thin Client Terminal Intel Atom E3827 , 1.75Ghz , DDR3 4G

PB Tech price

NZD $ 2,406 .90

$ 2,406 .90

Advantech TPC-1051WP-E3AE 10.1" WXGA Thin Client Terminal Intel Atom E3827 , 1.75Ghz , DDR3 4G

Brand: Advantech
MPN: TPC-1051WP-E3AE
Part #: IPCAVH221335
UPC:

PB Tech price

NZD $ 2,406 .90

In stock at Supplier

Delivery: Order now and it ships on 30 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Advantech
MPN: TPC-1051WP-E3AE
Part #: IPCAVH221335
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

10.1" WXGA TFT LED LCD Intel® Atom™ Thin Client Terminal

The TPC-1051WP thin-client terminal is equipped with a 10.1" WXGA TFT LCD, low-power Intel® Atom™ E3827 1.75 GHz dual-core processor, and 4 GB DDR3L SDRAM to deliver sufficient computing performance in a compact, fanless system. For enhanced durability, TPC-1051WP features a true-flat touchscreen with IP66-rated front panel, die cast aluminum alloy front bezel, and projected capacitive touch control. Because of the system's compact but robust design, it can be easily deployed into existing infrastructure. Moreover, Advantech's iDoor technology can be integrated via the mini PCIe slot in order to provide additional I/O connectors, isolated digital I/O, fieldbus protocols, 3G/GPS/GPRS/WiFi communication, and MRAM to support diverse industrial automation applications.

- Industrial 10.1 TFT LCD with 25K Lifetime LED Backlight
- Intel® Atom™ E3827 1.75 GHz Processor with 4GB DDR3L SDRAM
- 16:9 Wide Screen with PCT Multi-Touch
- IP66 Approved Front Protection & Panel Mounting
- Built-in Intelligent Home key and i Key for an intuitive user interface
- Front LED Indicator to Show Operating Status
- Supports iDoor with optional accessory kit
- Chassis Grounding Protection
- Anti-scratch surface: 7H hardness
- AC/DC support (option by Power adapter)
- Supports Advantech SNMP Subagent

Specifications

Environment

Ingress Protection

Front Panel IP66

Operating Temperature

-20~55 °C (-4~131 °F)

Storage Temperature

-30~70 °C (-22~158 °F)

Vibration Protection

1 Grms, random

Ethernet

Speed

10/100/1,000 Mbps

General

Humidity (Operating)

10~95% RH (non-condensing)

Hardware

BIOS

AMI UEFI

Certification

CE, FCC class A; CB/UL, CE, FCC Class A, CCC, BSMI

CPU

Intel® Atom™ E3827 1.75GHz Dual-core

I/O

1 x USB 2.0, 2 x USB 3.0

LAN

2 x 10/100/1000 Mbps

Memory

1 x SO-DIMM with 4 GB DDR3 1600 MHz

OS Support

Microsoft® Windows 7, Linux, Android

Power Consumption

36 W @ 24 VDC

Power Input

24 VDC ±20%

Storage

1 x CFast slot

Watchdog Timer

15~255 s

I/O Interface

Expansion

1 x Full-size mPCIe Slot

Serial Ports

1 x RS-232, 1 x RS-232/422/485

LCD Display

Backlight Life (hrs)

25000

Display Size

10.1"

Luminance (cd/m2)

300

Max. Resolution

1280 x 800

Viewing Angle (H/V°)

170/170

Mechanical

Dimension (W x H x D)

283.1 x 202.3 x 61.4 mm

Enclosure

Die-cast aluminum alloy

Mounting

Stand, Wall, Panel

Weight (Net)

2.56 kg (5.64 lb)

Touchscreen

Touch Type

PCAP

Manufacturer Part No:

TPC-1051WP-E3AE

Brand:

Advantech

Product Type:

UPC

Product Family:

Shipping Weight:

1 kg

PB Part No:

IPCAVH221335

Product Model:

TPC-1051WP-E3AE

Warranty: 12 months *
