Advantech TPC-121W-N31YB 21.5" FHD Touch Panel Computer with ARM Cortex -A53 Processor,Yocto3.3

PB Tech price

NZD $ 2,400 .00

$ 2,400 .00

Advantech TPC-121W-N31YB 21.5" FHD Touch Panel Computer with ARM Cortex -A53 Processor,Yocto3.3

Brand: Advantech
MPN: TPC-121W-N31YB
Part #: IPCAVH221343
UPC:

PB Tech price

NZD $ 2,400 .00

In stock at Supplier

Delivery: Order now and it ships on 30 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Advantech
MPN: TPC-121W-N31YB
Part #: IPCAVH221343
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

[Yocto] 21.5" Touch Panel Computer with ARM Cortex™-A53 Processor

- arm SystemReady IR certified
- NXP® ARM® Cortex™-A53 i.MX 8M Mini quad-core processor
- 16:9 LCD with multi-touch P-CAP and true-flat IP66-rated front panel
- Up to 4 GB DDR4 RAM and 16 GB eMMC storage onboard
- 1 mb FRAM backup memory for unexpected power interruptions
- 2 x Serial port with 120O termination resistor that one supports the CAN 2.0B protocol and offers a programmable bit rate of up to 1 Mb/sec
- Embedded browser and for rapid Web App development
- Supports Linux Yocto and Android
- Compatible with VESA and panel mounting

Specifications

LCD Display

Display Size

21.5"

Luminance (cd/m2)

250

Backlight Life (hrs)

50,000

Max. Resolution

1920 x 1080

Environment

Ingress Protection

Front Panel IP66

Operating Temperature

-20~60 °C (-33~140 °F)

Storage Temperature

-30~70 °C (-22~158 °F)

Vibration Protection

2 Grms, random

General

Humidity (Storage)

95% RH (non-condensing)

Rated Voltage

24 VDC (±20%)

Hardware

CPU

NXP® ARM® Cortex™ A53 i.MX8M 1.6 GHz Quad-Core

Memory

1 x LPDDR4 with 4 GB

Storage

16 GB eMMC

LAN

2 x 10/100/1000 Mbps

I/O

RS-232 x1, RS-232/422/485 x 1, USB 2.0 x 2 (Host)

Hardware Security

TPM 2.0

OS Support

Linux Yocto

Power Input

24 VDC ±20%

Certification

CB, UL, CE, FCC Class A, CCC, BSMI

I/O Interface

Serial Ports

1 x RS-232, 1 x RS-232/422/485

USB Ports

2 x USB 2.0

LAN Ports

2 x 10/100/1000 Mbps

Touchscreen

Touch Type

PCAP

Mechanical

Dimension (W x H x D)

558.4 x 349.8 x 56.2 mm

Weight (Net)

6.1 kg (13.45 lb)

Manufacturer Part No:

TPC-121W-N31YB

Brand:

Advantech

Product Type:

UPC

Product Family:

Shipping Weight:

1 kg

PB Part No:

IPCAVH221343

Product Model:

TPC-121W-N31YB

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
