Advantech TPC-312-R873B 12.1" XGA Touch Panel PC with Intel Core i7 , DDR4 8G

PB Tech price

NZD $ 4,486 .06

$ 4,486 .06

Advantech TPC-312-R873B 12.1" XGA Touch Panel PC with Intel Core i7 , DDR4 8G

Brand: Advantech
MPN: TPC-312-R873B
Part #: IPCAVH221366
UPC:

PB Tech price

NZD $ 4,486 .06

In stock at Supplier

Delivery: Order now and it ships on 30 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Advantech
MPN: TPC-312-R873B
Part #: IPCAVH221366
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

Advantech TPC-312-R873B 12.1" XGA Touch Panel PC with Intel Core i7 , DDR4 8G

- Industrial-grade 12.1 XGA TFT LCD with 50K lifetime and LED backlight
- 8th Gen. Intel® Core™ i7-8665UE quad-core processor with built-in 8 GB DDR4 SO-DIMM
- Dual channel memory slots support up to 64G in total
- Compact, fanless embedded system with aluminum alloy front bezel and chassis grounding protection
- True-flat touchscreen with 5-wire resistive touch control and IP66-rated front panel
- Support expansion via Full-size Mini PCIe and two M.2 slots (NVMe, 5G)
- Diverse system I/O and isolated digital I/O via iDoor technology
- Support fieldbus protocols/GPS/GPRS/Wi-Fi capabilities via iDoor technology
- Support TPM2.0 hardware security

For more information: https://advdownload.advantech.com/productfile/PIS/TPC-312/file/TPC-300-WHL_DS(050824)20240508114414.pdf

Specifications

Environment

Ingress Protection

Front Panel IP66

Operating Temperature

-10~55 °C (14~131 °F)

Storage Temperature

-20~70 °C (-4~158 °F)

Vibration Protection

1 Grms, random

General

Humidity (Operating)

10~95% RH (non-condensing)

Hardware

BIOS

AMI UEFI

Certification

CB, UL, CE, FCC Class A, CCC, BSMI

CPU

8th Gen. Intel® Core™ i7-8665UE 1.70GHz Quad-Core

I/O

1 x USB 2.0, 4 x USB 3.2, 1 x iDoor slot

LAN

1 x 10/100/1000 Mbps, 1 x 10/100/1000/2500 Mbps

Memory

1 x SO-DIMM with 8 GB DDR4 2400 MHz, 2 x DDR4 SO-DIMM Slot

OS Support

Microsoft® Windows 10 LTSC, Linux, Android

Power Consumption

41.06 W @ 24 VDC

Storage

1 x SATA M.2 SSD slot (2280 M-Key);
1 x 2.5" SSD/HDD Bay, 1 x mSATA, 1 x M.2 B key

Watchdog Timer

15~255 s

I/O Interface

Audio

Line-Out, Microphone

Displays

1 x DP

Expansion

1 x Full-size mPCIe Slot, 1 x SIM card Slot

Serial Ports

2 x RS-232/422/485

LCD Display

Backlight Life (hrs)

50,000

Display Size

12.1"

Luminance (cd/m²)

300

Max. Resolution

1024 x 768

Viewing Angle (H/V°)

178/178

Mechanical

Dimension (W x H x D)

311.8 x 238 x 67 mm

Enclosure

Die-cast aluminum alloy

Mounting

Stand, Wall, VESA, Panel

Weight (Net)

4.1 kg (9.04 lb)

Touchscreen

Touch Type

5-wire resistive

Manufacturer Part No:

TPC-312-R873B

Brand:

Advantech

Product Type:

UPC

Product Family:

Shipping Weight:

1 kg

PB Part No:

IPCAVH221366

Product Model:

TPC-312-R873B

Warranty: 12 months *
