MINIX Indusstrail PC RIC SJ64-8 Intel J6412/8G/256GB Win 11 Pro (64-bit)
Out of stock
MINIX Indusstrail PC RIC SJ64-8 Intel J6412/8G/256GB Win 11 Pro (64-bit)
- Brand: MINIX
- MPN: RIC SJ64-8
- Part #: IPCMNXSJ6402
- UPC:
- Brand: MINIX
- MPN: RIC SJ64-8
- Part #: IPCMNXSJ6402
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Computers





MINIX Indusstrail PC RIC SJ64-8 Intel J6412/8G/256GB Win 11 Pro (64-bit)
- Brand: MINIX
- MPN: RIC SJ64-8
- Part #: IPCMNXSJ6402

Product URL: https://www.pbtech.com/pacific/product/IPCMNXSJ6402/MINIX-Indusstrail-PC-RIC-SJ64-8-Intel-J64128G256GB
Features
- Onboard Intel® Celeron® Quad-Core J6412 CPU, TDP 10W
- Single SO-DIMM Socket, 4GB DDR4 by default, Max up to 32GB DDR4 3200MHz
(non-ECC Supported)
- Dual Display, DP 1.4a + HDMI 2.0
- Dual Intel® Ethernet, 2.5GbE
- Intel® Dual Band Wi-Fi (2.4/5GHz), BT 5.3
- Support M.2 Key-B 3042/3052 4G/5G Module
- Support M.2 Key-M 2242/2280 SATA SSD
- 4 x RS-232/422/485 COM
- Wide DC-Input, +12V ~ 24V ±5%
Specifications
Processor
Intel® Celeron® J6412 Processor (up to 2.60GHz)
System Memory
Single 260-pin DDR4 SO-DIMM Socket, 4GB DDR4 by default,
Supports up to 32GB DDR4 3200MHz (non ECC supported)
I/O Chipset
Nuvoton NCT6126D
BIOS Information
AMI BIOS, 120M-bit SPI Flash ROM
Watchdog Timer
Programmable 1~255 sec, support system reset
TPM2.0
Infineon_SLB9670VQ2.0
Expansion
1 x M.2 (Key-B, 3042, PCIe x1 + USB 3.0), 1 x M.2 (Key-M, M.2 SATA 2242/2280)
Storage
256GB M.2 SATA SSD (Upgradable to 1TB)
USB Port
3 x USB3.2 Gen1 Type-A, 3 x USB2.0 Type-A
COM Port
4 x RS-232/422/485
SATA
Support 1 x 2.5" SATA Storage
Graphic Chipset
Intel® UHD Graphics for 10th Gen Intel® Processors
Spec.& Resolution
HDMI 2.0 Max resolution 4096x2160@60Hz
DP 1.4a Max resolution 4096x2160@60Hz
Multiple Display
Dual Display
Audio Codec
ALC897-VA2-CG
Audio Interface
Mic-In, Line-Out, 2-in-1 3.5mm audio jack
Certification Information
CE, UKCA, FCC Class B
LAN Chipset
2 x Intel® I226V
Ethernet Interface
2 x 10M/100M/1000M/2.5G Ethernet
Wireless Connectivity
Intel® Wireless-AX210 Wi-Fi 6E (802.11ac) , BT 5.3
Operation Temperature
Operating Standard Temp: 0°C ~ 60°C
Storage Temperature
-40°C ~ 85°C (-40°F ~ 185°F)
Operating Humidity
5% ~ 95% Relative Humidity, Non-condensing
Power Requirement
DC IN +12V ~ 24V ±5%
Dimensions(L x W x H)
175 x 106 x 56.5 mm
OS Information
Windows 11 Pro
Power
19V/3.42A, 65W Adapter
Weight(net)
1.18 kg
