LENKENG 4K 5-In-1-Out HDMI HDR Switch. Support 12 bit full HD video, 3D video and 4K x 2K 30/60Hzultra HD video. Compatible with HDMI 1.4, HDMI 2.0 & HDCP 1.4, HDCP 2.2. Includes Remote Control.

With promo code $42.20
With promo code $42.20
Save 19%
Save 19%
NZD $ 52 .67
$ 52 .67
$52.67  +GST
$52.67

Limited Supply - only stock on hand available, when sold out we may not be able to source this product again.

LENKENG 4K 5-In-1-Out HDMI HDR Switch. Support 12 bit full HD video, 3D video and 4K x 2K 30/60Hzultra HD video. Compatible with HDMI 1.4, HDMI 2.0 & HDCP 1.4, HDCP 2.2. Includes Remote Control.

  • Brand: LENKENG
  • MPN: LKV501HDR-V3.0
  • Part #: KVMLNK1183
  • UPC:
CLEARANCE
With promo code $42.20
With promo code $42.20
Save 19% with code CLEARANCE
Save 19% with code CLEARANCE
Without promo code
NZD $ 52 .67 $ 52 .67

Part of Clearance Zone
For a limited time only, only 1 unit left!


Delivery: Order now and it ships on 08 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$52.67  +GST
$52.67
  • Brand: LENKENG
  • MPN: LKV501HDR-V3.0
  • Part #: KVMLNK1183
  • UPC:

Features

LENKENG 4K 5-In-1-Out HDMI HDR Switch. Support 12 bit full HD video, 3D video and 4K x 2K@30/60Hz ultra HD video. Compatible with HDMI 1.4, HDMI 2.0 & HDCP 1.4, HDCP 2.2. Includes Remote Control.

This 5×1 switch routes from 5 different sources at a resolution of up to 4K@60Hz UHD to a single display. The switch has 5x HDMI inputs, which makes this unit ideal for simultaneous connection to multiple HDMI devices. In addition, this switch supports IR control, thus it is easy and flexible to control the input signal as you need. It is perfect for security systems, medium entertainment, conference exhibition centre and digital monitoring system, etc.

- Switch easily among any 5x HDMI sources
- Support resolution up to Ultra HD 4K@60Hz
- Support highest bandwidth of up to 18Gpbs
- Support HDR
- Support HDMI 3D
- Support IR control
- Plug and play, easy to use
- Power-off memory

Specifications

Input ports

5x HDMI

Output ports

1x HDMI

Power indicator led

1x LED

Signal indicator led

5x LED

HDMI version

Compatible with HDMI 1.4, HDMI 2.0

HDCP version

Compatible with HDCP 1.4, HDCP 2.2

Video format supported

Support 12 bit full HD video, 3D video and 4K@30/60Hz Ultra HD video

I/O TMDS signal

0.7~1.2V p-p

I/O DDC signal

5V p-p

Audio format supported

Support standard audio and DSD (Direct Stream Digital) and HD (HBR) audio

HDMI resolution

480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1920x1200, 3840x 2160@24/25/30/50/60Hz, 4096x2160@24/25/30/50/60Hz

HDMI length

4K@60Hz HDMI input length =2m, HDMI output length =3m 1080p@60Hz HDMI input length =5m, HDMI output length =5m

HDR

Yes

Working temperature

0°C~60°C

Power supply

DC 5V 1A

Power consumption

<3.5W

Dimension

160(L)×60(W)×16.5(H) mm

Weight

226g

Colour

Black

Manufacturer Part No:
LKV501HDR-V3.0
Brand:
LENKENG
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
KVMLNK1183
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
