ASUS HA2741A 27" QHD HealthCare Monitor
2560x1440 - AGLR - DICOM Part14 GSDF - DICOM Preset - AUTO Calibration - JND< 10% - Antibacterial Treatment - Ergonomic Stand
ASUS HA2741A 27" QHD HealthCare Monitor
2560x1440 - AGLR - DICOM Part14 GSDF - DICOM Preset - AUTO Calibration - JND< 10% - Antibacterial Treatment - Ergonomic Stand
- Brand: ASUS
- MPN: HA2741A
- Part #: MONAS91271
- UPC: 197105308251
- Brand: ASUS
- MPN: HA2741A
- Part #: MONAS91271
- UPC: 197105308251
Features
ASUS HA2741A HealthCare Monitor - 27-inch (27-inch viewable), 3.6MP (2560 x 1440), AGLR, DICOM Part 14 GSDF, DICOM Preset, Auto Calibration, JND < 10%, Antibacterial Treatment, USB-C, HDMI, DisplayPort Daisy-chain, Ergonomic Stand
- 27-inch 3.6MP (2560 x 1440) frameless design with IPS 178° wide viewing angle panel
- Anti-Glare, Low-Reflection (AGLR) with Eye Care+ to protect eyes from long time use
- Compliant with DICOM Part 14 GSDF standard
- DICOM Preset and auto compensation of DICOM curve for ambient light changing
- ASUS exclusive Auto calibration to ensures DICOM accuracy
- Factory calibrated to ensures JND < 10%
- Multiple I/O for flexibility: DisplayPort with Daisy-chain, HDMI, USB-C and USB hub
- Ergonomic design with tilt, swivel, pivot and height adjustments for a comfortable viewing experience
- Proprietary long-lasting antibacterial treatment inhibits the growth of bacteria and fungi on the monitor head
- IEC 62368-1, IEC 60601-1-2, AAPM TG270, IEC62563-1 and ISO13485 Compliance
ASUS HealthCare Displays provides comprehensive line-up targeting for every HealthCare institutions needs. ASUS HealthCare Displays are factory calibrated with DICOM® Part 14 GSDF (Grayscale Standard Display Function) compliance to ensure visual accuracy and consistency in finest details. ASUS HA2741A features 27-inch 3.6MP Anti-Glare, Low-Reflection (AGLR) IPS panel, ASUS exclusive Hardware Calibration Technology supports auto calibration to keep DICOM long term accuracy. ASUS HealthCare Displays delivers high-performance, precise and stable capabilities to fit any scenario.
Lifelike Views Vith 178° Wide View Angle
ASUS HA2741A IPS panel provides 178° viewing angles, both horizontally and vertically, so you can reproduce excellent contrast, ensuring the accurate and clear medical images from almost any direction.
Factory-Precise for DICOM Excellence
To provides reliable images and stable grayscale, ASUS HealthCare Displays compliant with the Digital Imaging and Communications in Medicine (DICOM) Part 14 GSDF standard, and also pass AAPM TG270 and IEC62563-1 compliance test.
Each ASUS HealthCare display is factory calibrated to guarantee DICOM color accuracy. The display then undergoes stringent testingto ensure smoother color gradations, better uniformity with Just-Noticeable Difference (JND) < 10%.
ASUS exclusive DICOM Preset
ASUS exclusive DICOM Preset Mode provides multiple ambient brightness setting (0 lux, 50 lux, 100 lux) and auto detected brightness setting through ambient light sensor to provide different DICOM curves for different environmental changes.
f
Long-term DICOM Accuracy
ASUS Calibration technology saves all color parameter profiles on the monitor's internal scaler IC chip, instead of on the PC. The monitor can be calibrated and the look-up table subsequently rewritten, allowing users to connect it to devices with different operating systems or applications without needing to adjust settings.
Optimal Screen Resolution
In different medical imaging modalities, the presentation of medical images can differ in terms of both size and the amount of information displayed. ASUS HealthCare Displays can simulate multiple resolutions to display varies source of medical image with onscreen dot to dot present.?
Switchable Color & Monochrome
ASUS HealthCare Displays features color and monochrome with two positive and negative film mode to helps X-ray reading in different perspective.
Diverse Viewing Options
Picture-by-Picture (PbP)
View two different settings simultaneously by placing multiple input sources onscreen side-by-side; and configure each individual window's color settings with sRGB, DICOM, User Mode 1 / 2.
Picture-in-Picture (PiP)
Easily place your second input source in a window in one corner of the display.
Long-lasting Antibacterial Treatment
The monitor head and hotkeys on HA2741A feature an antibacterial ionic silver treatment*. By preventing bacteria adhesion by up to 99.9%, it keeps key areas of the monitor clean and hygienic, potentially reducing the spread of harmful bacteria. ASUS HA2741A has been subjected to the ISO 22196 Antimicrobial Activity and Efficacy tests conducted by independent testing lab SGS.
Connect to your workflow
HA2441A offers a USB-C, two DisplayPort1.4 (in, out), HDMI(v2.0) and USB3.2 hub for compatibility with current and future displays and peripherals. It also features an earphone jack.
USB-C Connectivity
USB-C connectivity capable to provide a variety of devices you can connect. The reversible USB-C connector design makes connecting any device effortless and quick. USB-C supports video transmission in DisplayPort signal and 15W power output for your devices via only one USB-C cable.
Connect to Your Devices Easily
A built-in USB 3.2 hub at the bottom of HA2441A includes two USB Type-A port, allowing you to easily connect a variety of devices and peripherals, as well as charge compatible devices.*? Additional USB Type-A and USB Type-C port each on the back for expanded connectivity.
Intelligent Sensor Design
Synchronizes display brightness and color temperature with environment light changes, it located in the top of monitor shared with colorimeter.
Ergonomic Design
Ergonomic stand offers tilt, swivel, pivot, and height adjustments. Being able to pivot the screen 90° clockwise or anticlockwise to portrait orientation comes in handy when check X-ray or working with long documents.
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Monitors
MSI Pro MP2412 24" FHD 100hz Business Monitor 1920x1080 - HDMI -...
LG 34WR50QK 34" WQHD Curved Ultrawide Monitor 3440x1440 -...
Samsung LS24D300G 24" FHD 100Hz IPS Monitor 1920x1080 - HDMI -...
Samsung Odyssey G5 27" QHD 165Hz Curved Gaming Monitor 2560x1440 ...
Samsung Odyssey G5 34" Ultrawide QHD 165Hz Curved Gaming Monitor...
ASUS HA2741A 27" QHD HealthCare Monitor 2560x1440 - AGLR - DICOM Part14 GSDF - DICOM Preset - AUTO Calibration - JND< 10% - Antibacterial Treatment - Ergonomic Stand
- Brand: ASUS
- MPN: HA2741A
- Part #: MONAS91271
- UPC:197105308251
Product URL: https://www.pbtech.com/pacific/product/MONAS91271/ASUS-HA2741A-27-QHD-HealthCare-Monitor-2560x1440
Features
ASUS HA2741A HealthCare Monitor - 27-inch (27-inch viewable), 3.6MP (2560 x 1440), AGLR, DICOM Part 14 GSDF, DICOM Preset, Auto Calibration, JND < 10%, Antibacterial Treatment, USB-C, HDMI, DisplayPort Daisy-chain, Ergonomic Stand
- 27-inch 3.6MP (2560 x 1440) frameless design with IPS 178° wide viewing angle panel
- Anti-Glare, Low-Reflection (AGLR) with Eye Care+ to protect eyes from long time use
- Compliant with DICOM Part 14 GSDF standard
- DICOM Preset and auto compensation of DICOM curve for ambient light changing
- ASUS exclusive Auto calibration to ensures DICOM accuracy
- Factory calibrated to ensures JND < 10%
- Multiple I/O for flexibility: DisplayPort with Daisy-chain, HDMI, USB-C and USB hub
- Ergonomic design with tilt, swivel, pivot and height adjustments for a comfortable viewing experience
- Proprietary long-lasting antibacterial treatment inhibits the growth of bacteria and fungi on the monitor head
- IEC 62368-1, IEC 60601-1-2, AAPM TG270, IEC62563-1 and ISO13485 Compliance
ASUS HealthCare Displays provides comprehensive line-up targeting for every HealthCare institutions needs. ASUS HealthCare Displays are factory calibrated with DICOM® Part 14 GSDF (Grayscale Standard Display Function) compliance to ensure visual accuracy and consistency in finest details. ASUS HA2741A features 27-inch 3.6MP Anti-Glare, Low-Reflection (AGLR) IPS panel, ASUS exclusive Hardware Calibration Technology supports auto calibration to keep DICOM long term accuracy. ASUS HealthCare Displays delivers high-performance, precise and stable capabilities to fit any scenario.
Lifelike Views Vith 178° Wide View Angle
ASUS HA2741A IPS panel provides 178° viewing angles, both horizontally and vertically, so you can reproduce excellent contrast, ensuring the accurate and clear medical images from almost any direction.
Factory-Precise for DICOM Excellence
To provides reliable images and stable grayscale, ASUS HealthCare Displays compliant with the Digital Imaging and Communications in Medicine (DICOM) Part 14 GSDF standard, and also pass AAPM TG270 and IEC62563-1 compliance test.
Each ASUS HealthCare display is factory calibrated to guarantee DICOM color accuracy. The display then undergoes stringent testingto ensure smoother color gradations, better uniformity with Just-Noticeable Difference (JND) < 10%.
ASUS exclusive DICOM Preset
ASUS exclusive DICOM Preset Mode provides multiple ambient brightness setting (0 lux, 50 lux, 100 lux) and auto detected brightness setting through ambient light sensor to provide different DICOM curves for different environmental changes.
f
Long-term DICOM Accuracy
ASUS Calibration technology saves all color parameter profiles on the monitor's internal scaler IC chip, instead of on the PC. The monitor can be calibrated and the look-up table subsequently rewritten, allowing users to connect it to devices with different operating systems or applications without needing to adjust settings.
Optimal Screen Resolution
In different medical imaging modalities, the presentation of medical images can differ in terms of both size and the amount of information displayed. ASUS HealthCare Displays can simulate multiple resolutions to display varies source of medical image with onscreen dot to dot present.?
Switchable Color & Monochrome
ASUS HealthCare Displays features color and monochrome with two positive and negative film mode to helps X-ray reading in different perspective.
Diverse Viewing Options
Picture-by-Picture (PbP)
View two different settings simultaneously by placing multiple input sources onscreen side-by-side; and configure each individual window's color settings with sRGB, DICOM, User Mode 1 / 2.
Picture-in-Picture (PiP)
Easily place your second input source in a window in one corner of the display.
Long-lasting Antibacterial Treatment
The monitor head and hotkeys on HA2741A feature an antibacterial ionic silver treatment*. By preventing bacteria adhesion by up to 99.9%, it keeps key areas of the monitor clean and hygienic, potentially reducing the spread of harmful bacteria. ASUS HA2741A has been subjected to the ISO 22196 Antimicrobial Activity and Efficacy tests conducted by independent testing lab SGS.
Connect to your workflow
HA2441A offers a USB-C, two DisplayPort1.4 (in, out), HDMI(v2.0) and USB3.2 hub for compatibility with current and future displays and peripherals. It also features an earphone jack.
USB-C Connectivity
USB-C connectivity capable to provide a variety of devices you can connect. The reversible USB-C connector design makes connecting any device effortless and quick. USB-C supports video transmission in DisplayPort signal and 15W power output for your devices via only one USB-C cable.
Connect to Your Devices Easily
A built-in USB 3.2 hub at the bottom of HA2441A includes two USB Type-A port, allowing you to easily connect a variety of devices and peripherals, as well as charge compatible devices.*? Additional USB Type-A and USB Type-C port each on the back for expanded connectivity.
Intelligent Sensor Design
Synchronizes display brightness and color temperature with environment light changes, it located in the top of monitor shared with colorimeter.
Ergonomic Design
Ergonomic stand offers tilt, swivel, pivot, and height adjustments. Being able to pivot the screen 90° clockwise or anticlockwise to portrait orientation comes in handy when check X-ray or working with long documents.
Specifications
Display
Panel Size (inch)
27
Aspect Ratio
16:9
Resolution
2560x1440
Pixel Pitch
0.233mm
Display Viewing Area (H x V)
596.74 x 335.66 mm
Display Surface
AGLR (Anti-Glare, Low-Reflection)
Panel Type
IPS
Viewing Angle (CR?10, H/V)
178°/ 178°
Brightness (Typ.)
350cd/?
Contrast Ratio (Typ.)
900:1
Display Colors
16.7M
Response Time
5ms(GTG)
Flicker-free
Yes
Video Inputs
USB-C x 1 (DP Alt Mode)
HDMI(v2.0) x 1
DisplayPort 1.4 x 2 (Daisy Chain)
USB-C Power Delivery : 15W
USB Hub : 3x USB 3.2 Gen 1 Type-A
USB Hub : 1x USB 3.2 Gen 1 Type-C
Earphone Jack : Yes
Features
Preset Mode
Native
Preset Mode
sRGB
Preset Mode
DICOM_0 lux
Preset Mode
DICOM_50 lux
Preset Mode
DICOM_100 lux
Preset Mode
DICOM_Auto
Preset Mode
User Mode 1
Color Temp. Selection
Yes(5000K, 5500K, 6500K, 7500K, 9300K, 12000K)
Monochrome
Off / Positive / Negative
Gamma adjustment
Yes (Support Gamma 2.0/2.2/2.4)
Aspect Control
Full / Dot to Dot / 1:1 Ratio
Pixel
4MP / 3MP
PIP(PbP) Technology
Yes
ASUS Hardware Calibration
Yes
HDCP
Yes, 2.2
Low Blue Light
Yes
Eye Care+ Technology
Yes
Sensor
Ambient Light Sensor
Yes
Power Consumption
Power Consumption
< 13W
Power Saving Mode
< 0.5W
Power Off Mode
<0.3W
Voltage
100-240V, 50/60Hz
Mechanical Design
Tilt
Yes (+23° ~ -5°)
Height Adjustment
0~130mm
Pivot
Yes (+90° ~ -90°)
Swivel
Yes (+30° ~ -30°)
Antibacterial treatment
Yes
VESA Wall Mount
100x100mm
Kensington Lock
Yes
Dimensions (Esti.)
Phys. Dimension with Stand (W x H x D)
61.33 x 53.67 x 19.72 cm (24.15" x 21.13" x 7.76")
Phys. Dimension without Stand (W x H x D)
61.33 x 36.34 x 4.49 cm (24.15" x 14.31" x 1.77")
Box Dimension (W x H x D)
69.5 x 42.1 x 13.3 cm (27.36" x 16.57" x 5.24")
Weight (Esti.)
Net Weight
6.7 kg (14.77 lbs)
Net Weight without Stand
5.0 kg (11.02 lbs)
Gross Weight
9.3 kg (20.50 lbs)
Reliability
Operation Temperature
0°C ~ 40°C
Operation Humidity
5% ~ 90%
Compliance Standard
Energy Star
TÜV Flicker-free
TÜV Low Blue Light
FSC MIX
ISO 13485
IEC 60601-1-2
AAPM TG270
IEC 62563-1
Accessories (vary by regions)
Color pre-calibration report
DisplayPort cable
HDMI cable
Power adapter
Power cord
Quick release stand
Quick start guide
USB-C cable
Warranty Card
