ASUS HA3281A 32" 4K 8MP OLED HealthCare Monitor
- 3840x2160 - AGLR - DICOM Part14 GSDF - DICOM Preset - Built-in Motorised Colormeter - JND< 10% - Antibacterial Treatment - Ergonomic Stand
Out of stock
ASUS HA3281A 32" 4K 8MP OLED HealthCare Monitor
- 3840x2160 - AGLR - DICOM Part14 GSDF - DICOM Preset - Built-in Motorised Colormeter - JND< 10% - Antibacterial Treatment - Ergonomic Stand
- Brand: ASUS
- MPN: HA3281A
- Part #: MONAS93328
- UPC:
- Brand: ASUS
- MPN: HA3281A
- Part #: MONAS93328
- UPC:
Features
ASUS HA3281A HealthCare Monitor - 32-inch (31.5-inch viewable), OLED, 8MP (3840 x 2160), AGLR, DICOM Part 14 GSDF, DICOM Preset, Built-in Motorized Colorimeter, Self / Auto Calibration, JND < 10%, USB-C, HDMI, Ergonomic Stand
- 31.5-inch 8MP (3840 x 2160) pure RGB OLED true 10-bit panel
- Anti-Glare, Low-Reflection (AGLR) with Eye Care+ to protect eyes from long time use
- Compliant with DICOM Part 14 GSDF standard
- DICOM Preset and auto compensation of DICOM curve for ambient light changing
- Built-in colorimeter supports Self / Auto calibration to ensures DICOM accuracy
- Factory calibrated to ensures JND < 10%
- Multiple I/O for flexibility: DisplayPort, HDMI, USB-C and USB hub
- Ergonomic design with tilt, swivel, pivot and height adjustments for a comfortable viewing experience
- IEC 60601-1-2, AAPM 270, TG18 and ISO13485 Compliance
ASUS HealthCare Displays provides comprehensive line-up targeting for every HealthCare institutions needs. ASUS HealthCare Displays are factory calibrated with DICOM® Part 14 GSDF (Grayscale standard display function) compliance to ensure visual accuracy and consistency in finest details. ASUS HA3281A features 31.5-inch 8MP Anti-Glare, Low-Reflection (AGLR) pure RGB OLED panel, built-in colorimeter supports self / auto calibration to keep DICOM long term accuracy. ASUS HealthCare Displays delivers high-performance, precise and stable capabilities to fit any scenario.
Premium OLED panel with RGB stripes
ASUS HA3281A incorporates OLED technology which achieves ultra-precise control and extreme contrast by making each individual pixel its own light source. HA3281A has a pure RGB Stripe OLED panel with billions of self-illuminating pixels that can be individually activated to reproduce excellent contrast, ensuring the accurate and clear medical images.
8MP High Resolution
ASUS HealthCare Displays offers high resolution displaying up to 8 megapixels images give you four times the pixel density and up to 300% more onscreen space than similarly-sized 2 megapixels displays. This means you get to enjoy sharp, detailed visuals. On top of that, more onscreen space for multitasking, so any image could be fit in or even side by side comparison on a single screen.
Anti-Glare, Low-Reflection - Protect Your Eyes
ASUS HealthCare Displays is always take care of your eyes. Made with AGLR (Anti-glare, Low-reflection) coating, and undergone stringent performance tests and has been certified by TÜV Rheinland laboratories, a global provider of technical, safety, and certification services, to be flicker-free and to emit low blue light levels.
High Contrast with True Black
Experience true black visual excellence with an exceptional 1M:1 high contrast ratio, delivers every detail is visible, meeting the stringent requirements of healthcare professionals.
Factory-Precise for DICOM Excellence
To provides reliable images and stable grayscale, ASUS HealthCare Displays compliant with the Digital Imaging and Communications in Medicine (DICOM) Part 14 GSDF standard, and also pass AAPM TG270 and TG18 compliance test.
Each ASUS HealthCare display is factory calibrated to guarantee DICOM color accuracy. The display then undergoes stringent testing to ensure smoother color gradations, better uniformity with Just-Noticeable Difference (JND) <10%.
ASUS exclusive DICOM Preset
ASUS exclusive DICOM Preset Mode provides multiple ambient brightness setting (0 lux, 50 lux, 100 lux) and auto detected brightness setting through ambient light sensor to provide different DICOM curves for different environmental changes.
Self Calibration
ASUS HA3281A now boasts an innovative self-calibration feature for the embedded colorimeter. The self-calibration is a standalone solution without any software and compatible with any operating system. You can directly complete the calibration and scheduled calibration functions through the OSD operation of HA3281A. With this flexibility, you can achieve grayscale consistency anytime and anywhere.
Auto Calibration
ASUS Calibration technology saves all color parameter profiles on the monitor's internal scaler IC chip, instead of on the PC. The monitor can be calibrated and the look-up table subsequently rewritten, allowing users to connect it to devices with different operating systems or applications without needing to adjust settings.
Optimal Screen Resolution
In different medical imaging modalities, the presentation of medical images can differ in terms of both size and the amount of information displayed. ASUS HealthCare Displays can simulate multiple resolutions to display varies source of medical image with onscreen dot to dot present.?
Switchable Color & Monochrome
ASUS HealthCare Displays features color and monochrome with two positive and negative film mode to helps X-ray reading in different perspective.
Diverse Viewing Options
- Picture-by-Picture (PbP)
View two to four different settings simultaneously by placing multiple input sources onscreen side-by-side; and configure each individual window's color settings with sRGB, DICOM, User Mode 1 / 2.
- Picture-in-Picture (PiP)
Easily place your second input source in a window in one corner of the display.
Connect to your workflow
HA3281A offers a USB-C, DisplayPort 1.4, three HDMI (v2.0) and USB3.2 hub for compatibility with current and future displays and peripherals. It also features an earphone jack.
Versatile Stand
Two versatile stand options make it easy to deploy HA3281A in any healthcare setting, allowing users to find the optimal working or viewing position when working on-location.
Better Management
Bundled clips make it easy to manage cables to keep desks and work areas tidy, while the sturdy and elegant metal handle makes it easy to carry HA3281A to anywhere it's needed.
Intelligent Sensor Design
- Ambient Light Sensor
Synchronizes display brightness with environment light changes, it located in the top of monitor shared with colorimeter.
- Proximity Sensor
Automatically decrease brightness when it detects you've moved away.
Ergonomic Design
The bundled ergonomic stand offers tilt, swivel, pivot, and height adjustments. Being able to pivot the screen 90° clockwise or anticlockwise to portrait orientation comes in handy when check X-ray or working with long documents.
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Monitors
MSI Pro MP2412 24" FHD 100hz Business Monitor 1920x1080 - HDMI -...
LG 34WR50QK 34" WQHD Curved Ultrawide Monitor 3440x1440 -...
Samsung LS24D300G 24" FHD 100Hz IPS Monitor 1920x1080 - HDMI -...
Samsung Odyssey G5 27" QHD 165Hz Curved Gaming Monitor 2560x1440 ...
Samsung Odyssey G5 34" Ultrawide QHD 165Hz Curved Gaming Monitor...
ASUS HA3281A 32" 4K 8MP OLED HealthCare Monitor - 3840x2160 - AGLR - DICOM Part14 GSDF - DICOM Preset - Built-in Motorised Colormeter - JND< 10% - Antibacterial Treatment - Ergonomic Stand
- Brand: ASUS
- MPN: HA3281A
- Part #: MONAS93328
Product URL: https://www.pbtech.com/pacific/product/MONAS93328/ASUS-HA3281A-32-4K-8MP-OLED-HealthCare-Monitor---3
Features
ASUS HA3281A HealthCare Monitor - 32-inch (31.5-inch viewable), OLED, 8MP (3840 x 2160), AGLR, DICOM Part 14 GSDF, DICOM Preset, Built-in Motorized Colorimeter, Self / Auto Calibration, JND < 10%, USB-C, HDMI, Ergonomic Stand
- 31.5-inch 8MP (3840 x 2160) pure RGB OLED true 10-bit panel
- Anti-Glare, Low-Reflection (AGLR) with Eye Care+ to protect eyes from long time use
- Compliant with DICOM Part 14 GSDF standard
- DICOM Preset and auto compensation of DICOM curve for ambient light changing
- Built-in colorimeter supports Self / Auto calibration to ensures DICOM accuracy
- Factory calibrated to ensures JND < 10%
- Multiple I/O for flexibility: DisplayPort, HDMI, USB-C and USB hub
- Ergonomic design with tilt, swivel, pivot and height adjustments for a comfortable viewing experience
- IEC 60601-1-2, AAPM 270, TG18 and ISO13485 Compliance
ASUS HealthCare Displays provides comprehensive line-up targeting for every HealthCare institutions needs. ASUS HealthCare Displays are factory calibrated with DICOM® Part 14 GSDF (Grayscale standard display function) compliance to ensure visual accuracy and consistency in finest details. ASUS HA3281A features 31.5-inch 8MP Anti-Glare, Low-Reflection (AGLR) pure RGB OLED panel, built-in colorimeter supports self / auto calibration to keep DICOM long term accuracy. ASUS HealthCare Displays delivers high-performance, precise and stable capabilities to fit any scenario.
Premium OLED panel with RGB stripes
ASUS HA3281A incorporates OLED technology which achieves ultra-precise control and extreme contrast by making each individual pixel its own light source. HA3281A has a pure RGB Stripe OLED panel with billions of self-illuminating pixels that can be individually activated to reproduce excellent contrast, ensuring the accurate and clear medical images.
8MP High Resolution
ASUS HealthCare Displays offers high resolution displaying up to 8 megapixels images give you four times the pixel density and up to 300% more onscreen space than similarly-sized 2 megapixels displays. This means you get to enjoy sharp, detailed visuals. On top of that, more onscreen space for multitasking, so any image could be fit in or even side by side comparison on a single screen.
Anti-Glare, Low-Reflection - Protect Your Eyes
ASUS HealthCare Displays is always take care of your eyes. Made with AGLR (Anti-glare, Low-reflection) coating, and undergone stringent performance tests and has been certified by TÜV Rheinland laboratories, a global provider of technical, safety, and certification services, to be flicker-free and to emit low blue light levels.
High Contrast with True Black
Experience true black visual excellence with an exceptional 1M:1 high contrast ratio, delivers every detail is visible, meeting the stringent requirements of healthcare professionals.
Factory-Precise for DICOM Excellence
To provides reliable images and stable grayscale, ASUS HealthCare Displays compliant with the Digital Imaging and Communications in Medicine (DICOM) Part 14 GSDF standard, and also pass AAPM TG270 and TG18 compliance test.
Each ASUS HealthCare display is factory calibrated to guarantee DICOM color accuracy. The display then undergoes stringent testing to ensure smoother color gradations, better uniformity with Just-Noticeable Difference (JND) <10%.
ASUS exclusive DICOM Preset
ASUS exclusive DICOM Preset Mode provides multiple ambient brightness setting (0 lux, 50 lux, 100 lux) and auto detected brightness setting through ambient light sensor to provide different DICOM curves for different environmental changes.
Self Calibration
ASUS HA3281A now boasts an innovative self-calibration feature for the embedded colorimeter. The self-calibration is a standalone solution without any software and compatible with any operating system. You can directly complete the calibration and scheduled calibration functions through the OSD operation of HA3281A. With this flexibility, you can achieve grayscale consistency anytime and anywhere.
Auto Calibration
ASUS Calibration technology saves all color parameter profiles on the monitor's internal scaler IC chip, instead of on the PC. The monitor can be calibrated and the look-up table subsequently rewritten, allowing users to connect it to devices with different operating systems or applications without needing to adjust settings.
Optimal Screen Resolution
In different medical imaging modalities, the presentation of medical images can differ in terms of both size and the amount of information displayed. ASUS HealthCare Displays can simulate multiple resolutions to display varies source of medical image with onscreen dot to dot present.?
Switchable Color & Monochrome
ASUS HealthCare Displays features color and monochrome with two positive and negative film mode to helps X-ray reading in different perspective.
Diverse Viewing Options
- Picture-by-Picture (PbP)
View two to four different settings simultaneously by placing multiple input sources onscreen side-by-side; and configure each individual window's color settings with sRGB, DICOM, User Mode 1 / 2.
- Picture-in-Picture (PiP)
Easily place your second input source in a window in one corner of the display.
Connect to your workflow
HA3281A offers a USB-C, DisplayPort 1.4, three HDMI (v2.0) and USB3.2 hub for compatibility with current and future displays and peripherals. It also features an earphone jack.
Versatile Stand
Two versatile stand options make it easy to deploy HA3281A in any healthcare setting, allowing users to find the optimal working or viewing position when working on-location.
Better Management
Bundled clips make it easy to manage cables to keep desks and work areas tidy, while the sturdy and elegant metal handle makes it easy to carry HA3281A to anywhere it's needed.
Intelligent Sensor Design
- Ambient Light Sensor
Synchronizes display brightness with environment light changes, it located in the top of monitor shared with colorimeter.
- Proximity Sensor
Automatically decrease brightness when it detects you've moved away.
Ergonomic Design
The bundled ergonomic stand offers tilt, swivel, pivot, and height adjustments. Being able to pivot the screen 90° clockwise or anticlockwise to portrait orientation comes in handy when check X-ray or working with long documents.
Specifications
Model
HA3281A
Display
Panel Size (inch)
31.5
Aspect Ratio
16:9
Resolution
3840x2160
Pixel Pitch
0.182mm
Display Viewing Area (H x V)
697.92 x 392.58 mm
Display Surface
AGLR (Anti-Glare, Low-Reflection)
Panel Type
OLED
Viewing Angle (CR?10, H/V)
178°/ 178°
Brightness (Typ.)
250cd/?
Contrast Ratio (Typ.)
1,000,000:1
Display Colors
1073.7M (10 bit)
Response Time
0.1ms(GTG)
Flicker-free
Yes
Video Inputs
USB-C x 1 (DP Alt Mode)
HDMI(v2.0) x 3
DisplayPort 1.4 x 1
USB-C Power Delivery : 15W
USB Hub : 4x USB 3.2 Gen 2 Type-A
Earphone Jack : Yes
Features
Preset Mode : Native
Preset Mode : sRGB
Preset Mode : DICOM_0 lux
Preset Mode : DICOM_50 lux
Preset Mode : DICOM_100 lux
Preset Mode : DICOM_Auto
Preset Mode : User Mode 1
Preset Mode : User Mode 2
Color Temp. Selection : Yes(5000K, 5500K, 6500K, 7500K, 9300K, 12000K)
Monochrome : Off / Positive / Negative
Gamma adjustment : Yes (Support Gamma 2.0/2.2/2.4)
Aspect Control : Full / Dot to Dot / 1:1 Ratio
Pixel : 8MP / 6MP / 5MP / 3MP
PIP(PbP) Technology : Yes
ASUS Hardware Calibration : Yes
HDCP : Yes, 2.2
Low Blue Light : Yes
Eye Care+ Technology : Yes
Audio
Speaker
No
Sensor
Embedded Colorimeter
Yes (Support Self-Calibration)
Ambient Light Sensor
Yes
Proximity Sensor
Yes
Power Consumption
Power Consumption
< 23.2W
Power Saving Mode
< 0.5W
Power Off Mode
<0.3W
Voltage
100-240V, 50/60Hz
Mechanical Design
Tilt
Yes (+23° ~ -5°)
Height Adjustment
0~130mm
Pivot
Yes (+90° ~ -90°)
Swivel
Yes (+30° ~ -30°)
VESA Wall Mount
100x100mm
Kensington Lock
Yes
Dimensions (Esti.)
Phys. Dimension with Stand (W x H x D)
73.5 x 62.6 x 24.5 cm (28.94" x 24.65" x 9.65")
Phys. Dimension without Stand (W x H x D)
73.54 x 46.69 x 5.44 cm (28.95" x 18.38" x 2.14")
Box Dimension (W x H x D)
87.8 x 61.6 x 29.8 cm (34.57" x 24.25" x 11.73")
Weight (Esti.)
Net Weight
14.8 kg (32.63 lbs)
Net Weight without Stand
7.4 kg (16.31 lbs)
Gross Weight
18.2 kg (40.12 lbs)
Reliability
Operation Temperature
0°C ~ 40°C
Operation Humidity
5% ~ 90%
Compliance Standard
Energy Star
TÜV Flicker-free
TÜV Low Blue Light
ISO 13485
IEC 60601-1-2
AAPM TG18
AAPM TG270
