Philips 49B2U6903CH 49" Curved Ultrawide USB-C Docking Monitor with Thunderbolt4 and Webcam
- 5120x1440 , HDR400 , HDMI+DP + Thunderbolt4 input 100W , TB4 Out , RJ45 2.5G , USB 3.0 Hub , Speaker , Height adjustable
Philips 49B2U6903CH 49" Curved Ultrawide USB-C Docking Monitor with Thunderbolt4 and Webcam
- 5120x1440 , HDR400 , HDMI+DP + Thunderbolt4 input 100W , TB4 Out , RJ45 2.5G , USB 3.0 Hub , Speaker , Height adjustable
- Brand: Philips
- MPN: 49B2U6903CH/75
- Part #: MONPHS524495
- UPC:
- Brand: Philips
- MPN: 49B2U6903CH/75
- Part #: MONPHS524495
- UPC:
Features
VA display delivers awesome images with wide viewing angles
Philips VA LED display uses an advanced multi-domain vertical alignment technology which gives you super-high static contrast ratios for extra vivid and bright images. While standard office applications are handled with ease, it is especially suitable for photos, web-browsing, movies, gaming, and demanding graphical applications. It's optimized pixel management technology gives you 178/178 degree extra wide viewing angle, resulting in crisp images.
DisplayHDR 400 for more lifelike and outstanding visuals
VESA-certified DisplayHDR 400 delivers a significant step-up from normal SDR displays. Unlike, other 'HDR compatible' screens, true DisplayHDR 400 produces astonishing brightness, contrast and colors. With global dimming and minimum 400 nits brightness, images come to life with notable highlights while featuring deeper, more nuanced blacks. It renders a fuller palette of rich new colors, delivering a visual experience that engages your senses.
Curved display design for more immersive experience
Desktop monitors offer a personal user experience, which suits a curve design very well. The curved screen provides a pleasant yet subtle immersion effect, which focuses on you at the center of your desk.
SmartKVM: for easily switching between sources.
Unlike traditional built-in KVM monitor button, the smart KVM allows for switching between sources with the click of a button on your keyboard. When all devices are properly connected, users can easily switch between sources by clicking the "Ctrl" key three times.
32:9 SuperWide screen designed to replace multiscreen setups
32:9 SuperWide 49" screen, with 5120 x 1440 resolution, is designed to replace multiscreen setups for massive wide view. It's like having two 27" 16:9 Quad HD displays side-by-side. SuperWide monitors offer screen area of dual monitors without the complicated setup.
Adjustable Webcam: for video conferencing in comfort.
Level up the comfort of video conferencing with this feature. By adjusting the webcam back and forth by 30 degrees, users can now comfortably call and attend meetings from any position that best suits them.
AI-enhanced Webcam Autoframing: for dynamic video calls.
This AI-enhanced feature is perfect for multi-person video conferencing. When one or more people join the webcam view, the AI-powered feature will automatically adjust and zoom to fit all team members in the frame. Likewise, when participants leave the webcam view, the AI-enhanced webcam will adjust accordingly; thereby making it ideal for long meetings as well as team calls.
Earphone Hook: for customizable storage
Earphone storage is unmatched with this feature. Carefully pull down the hook located on the side of the monitor: This feature makes for a tidy desktop and provides a handy cable management solution for your workspace.
Busylight: for setting your working status
This feature allows for privacy and optimal collaboration when working in a busy office setting. To transmit to others that they are busy, users can simply press the Busylight hotkey located on the bottom left menu of the monitor bezel and the light located on the webcam will turn red. In addition to this, the Busylight feature can also sync with user's Microsoft Teams status.
PowerSensor 2: for optimized energy efficiency
This monitor's PowerSensor 2 feature reduces energy consumption by detecting when users move closer and further away from the screen. After switching the OSD setting to "User", it is then needed to adjust the settings in Windows 11 for this feature to function properly. When adjustments are made, the monitor and connected PC/laptop will wake when someone approaches it and will sleep when someone walks away; effectively reducing the amount of wake time. The distance for detection can be changed from 50, 75, to 120cm from the user's laptop. Please note that Windows 11 must be installed.
Collaboration-ready webcam with noise-cancelling mic.
This Philips monitor comes with a built-in 5MP webcam, noise-cancelling microphone, and speakers, making it perfect for working from home and collaborating remotely. It is equipped with advanced sensors that work seamlessly with Windows Hello facial recognition, allowing you to log into your Windows devices in less than 2 seconds. For added privacy, a physical camera switch lets you disable the webcam when not in use. The noise-cancelling microphone and dual 5-watt integrated speakers ensure clear communication.
Thunderbolt™ 4 Connection: for lightning-fast connectivity
This Philips docking monitor is equipped with Thunderbolt 4 connection. Compared with conventional USB-C monitors, Thunderbolt 4 technology provides lightning-fast data transfer speeds, supports high resolution video, offers multi-stream transport for daisy chaining, and has the capability of up to 100W of power delivery to external devices.
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Business Monitors
MSI Pro MP2412 24" FHD 100hz Business Monitor 1920x1080 - HDMI -...
Samsung LS24D300G 24" FHD 100Hz IPS Monitor 1920x1080 - HDMI -...
Samsung LS27D300G 27" FHD 100Hz IPS Monitor 1920x1080 - HDMI -...
MSI Pro MP273A 27" FHD 100Hz Business Monitor 1920x1080 - IPS...
LG 27UP850K-W 27" 4K UHD USB-C 90W Business Monitor 3840x2160 -...
Philips 49B2U6903CH 49" Curved Ultrawide USB-C Docking Monitor with Thunderbolt4 and Webcam - 5120x1440 , HDR400 , HDMI+DP + Thunderbolt4 input 100W , TB4 Out , RJ45 2.5G , USB 3.0 Hub , Speaker , Height adjustable
- Brand: Philips
- MPN: 49B2U6903CH/75
- Part #: MONPHS524495
Product URL: https://www.pbtech.com/pacific/product/MONPHS524495/Philips-49B2U6903CH-49-Curved-Ultrawide-USB-C-Dock
Features
VA display delivers awesome images with wide viewing angles
Philips VA LED display uses an advanced multi-domain vertical alignment technology which gives you super-high static contrast ratios for extra vivid and bright images. While standard office applications are handled with ease, it is especially suitable for photos, web-browsing, movies, gaming, and demanding graphical applications. It's optimized pixel management technology gives you 178/178 degree extra wide viewing angle, resulting in crisp images.
DisplayHDR 400 for more lifelike and outstanding visuals
VESA-certified DisplayHDR 400 delivers a significant step-up from normal SDR displays. Unlike, other 'HDR compatible' screens, true DisplayHDR 400 produces astonishing brightness, contrast and colors. With global dimming and minimum 400 nits brightness, images come to life with notable highlights while featuring deeper, more nuanced blacks. It renders a fuller palette of rich new colors, delivering a visual experience that engages your senses.
Curved display design for more immersive experience
Desktop monitors offer a personal user experience, which suits a curve design very well. The curved screen provides a pleasant yet subtle immersion effect, which focuses on you at the center of your desk.
SmartKVM: for easily switching between sources.
Unlike traditional built-in KVM monitor button, the smart KVM allows for switching between sources with the click of a button on your keyboard. When all devices are properly connected, users can easily switch between sources by clicking the "Ctrl" key three times.
32:9 SuperWide screen designed to replace multiscreen setups
32:9 SuperWide 49" screen, with 5120 x 1440 resolution, is designed to replace multiscreen setups for massive wide view. It's like having two 27" 16:9 Quad HD displays side-by-side. SuperWide monitors offer screen area of dual monitors without the complicated setup.
Adjustable Webcam: for video conferencing in comfort.
Level up the comfort of video conferencing with this feature. By adjusting the webcam back and forth by 30 degrees, users can now comfortably call and attend meetings from any position that best suits them.
AI-enhanced Webcam Autoframing: for dynamic video calls.
This AI-enhanced feature is perfect for multi-person video conferencing. When one or more people join the webcam view, the AI-powered feature will automatically adjust and zoom to fit all team members in the frame. Likewise, when participants leave the webcam view, the AI-enhanced webcam will adjust accordingly; thereby making it ideal for long meetings as well as team calls.
Earphone Hook: for customizable storage
Earphone storage is unmatched with this feature. Carefully pull down the hook located on the side of the monitor: This feature makes for a tidy desktop and provides a handy cable management solution for your workspace.
Busylight: for setting your working status
This feature allows for privacy and optimal collaboration when working in a busy office setting. To transmit to others that they are busy, users can simply press the Busylight hotkey located on the bottom left menu of the monitor bezel and the light located on the webcam will turn red. In addition to this, the Busylight feature can also sync with user's Microsoft Teams status.
PowerSensor 2: for optimized energy efficiency
This monitor's PowerSensor 2 feature reduces energy consumption by detecting when users move closer and further away from the screen. After switching the OSD setting to "User", it is then needed to adjust the settings in Windows 11 for this feature to function properly. When adjustments are made, the monitor and connected PC/laptop will wake when someone approaches it and will sleep when someone walks away; effectively reducing the amount of wake time. The distance for detection can be changed from 50, 75, to 120cm from the user's laptop. Please note that Windows 11 must be installed.
Collaboration-ready webcam with noise-cancelling mic.
This Philips monitor comes with a built-in 5MP webcam, noise-cancelling microphone, and speakers, making it perfect for working from home and collaborating remotely. It is equipped with advanced sensors that work seamlessly with Windows Hello facial recognition, allowing you to log into your Windows devices in less than 2 seconds. For added privacy, a physical camera switch lets you disable the webcam when not in use. The noise-cancelling microphone and dual 5-watt integrated speakers ensure clear communication.
Thunderbolt™ 4 Connection: for lightning-fast connectivity
This Philips docking monitor is equipped with Thunderbolt 4 connection. Compared with conventional USB-C monitors, Thunderbolt 4 technology provides lightning-fast data transfer speeds, supports high resolution video, offers multi-stream transport for daisy chaining, and has the capability of up to 100W of power delivery to external devices.
Specifications
Picture/Display
Panel Size
48.8inch/124cm
Aspect ratio
32:9
LCD panel type
VA LCD
Backlight type
W-LED system
Pixel pitch
0.2328x0.2328mm
Brightness
450(SDR) cd/m² , 500(HDR) cd/m²
Display colors
1.07 B
Color gamut (typical)
NTSC: 97%*, RGB: 119% *
Contrast ratio (typical)
3000:1
SmartContrast
80,000,000:1
Response time (typical)
4 ms (Gray to Gray)*
Viewing angle
178º (H) / 178º (V)
@ C/R > 10
Picture enhancement
SmartImage
Maximum resolution
5120x1440 @ 60Hz (HDMI2.0)*, 5120x1440 @ 100Hz(DP1.4)*, 5120x1440 @ 75Hz (Thunderbolt)*
Effective viewing area
1191.936(H)x335.232(V)mm,1800R curvature*
Scanning Frequency
HDMI: 30 - 140 kHz (H) / 30-75 Hz (V); DP/Thunderbolt: 30 - 200 kHz (H) / 48-120 Hz (V)
sRGB
Yes
Delta E
< 2 (sRGB)
SoftBlue
Yes
Flicker-free
Yes
Pixel Density
109 PPI
Display Screen Coating
Anti-Glare, 3H, Haze 25%
SmartUniformity
93 ~ 105%
EasyRead
Yes
Adaptive sync
Yes
HDR
Display HDR 400 certified
EyeSafe
Yes
Connectivity
Signal Input
HDMI 2.0 x 2, DisplayPort 1.4 x 1, Thunderbolt 4 input x 1 (upstream, Data, Video, PD to 100W)
Sync Input
Separate Sync
Sync on Green
Audio (In/Out)
Audio out / Microphone in combo jack
RJ45
Ethernet LAN up to 2.5G*, Wake on LAN
Signal Output
Thunderbolt 4 output x 1 (downstream, Data, Video, PD 15W)
HDCP
HDCP 1.4 (HDMI / DisplayPort / Thunderbolt 4 ), HDCP 2.2 (HDMI / DisplayPort / Thunderbolt 4 )
HBR3
HBR 3 (Thunderbolt 4 )
USB Hub
USB 3.2 Gen 2 / 10 G, upstream: 1x Thunderbolt 4, 1x USB-C1 (data); downstream: 1x Thunderbolt 4, USB-A x4 (with x1 fast charge B.C 1.2), USB-C2x1 (data, 45W)
Power Delivery
Max power delivery
Up to 100 W (5/V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.8A)
Version
USB PD version 3.0
Convenience
Built-in Speakers
5 W x 2
Plug & Play Compatibility
DDC/CI
Mac OS
sRGB
Windows 11 / 10
User convenience
SmartImage
Input
User
Menu
Power On/Off
Mute
Handup
Busylight
OSD Languages
Brazil Portuguese
Czech
Dutch
English
French
Finnish
German
Greek
Hungarian
Italian
Japanese
Korean
Portuguese
Polish
Russian
Simplified Chinese
Spanish
Swedish
Traditional Chinese
Turkish
Ukrainian
Other convenience
Kensington lock
Earphone hook
VESA mount (100x100mm)
Control software
SmartControl
MultiView
PIP/PBP mode
2x devices
Built-in webcam
Pop-up 5.0 megapixel camera with microphone and LED indicator
Webcam with auto framing
Yes
Webcam tilt function
Yes, -/+30 degree
Busylight
Yes
Noise cancellation
Yes
SmartKVM
Yes (Thunderbolt 4/USB-C1)
Stand
Height adjustment
150 mm
Swivel
-/+30 degree
Tilt
-5/15 degree
Power
ECO mode
37.5 W (typ.)
Power supply
Built-in
100-240VAC, 50-60Hz
Off mode
0.5 W (typ.)
On mode
41.85 W (typ.) (EnergyStar test method)
Standby mode
0.5 W (typ.)
Power LED indicator
Operation - White
Standby mode- White (blinking)
Dimensions
Product without stand (mm)
1193 x 373 x 164 mm
Product with stand(max height)
1193 x 586 x 268 mm
Weight
Product with stand (kg)
15.45 kg
Product without stand (kg)
11.82 kg
Operating conditions
Altitude
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
Temperature range (operation)
0°C to 40 °C
Relative humidity
20%-80 %
Temperature range (storage)
-20°C to 60 °C
MTBF (demonstrated)
70,000 hrs (excluded backlight)
Sustainability
Environmental and energy
Energy Star
EPEAT*
RoHS
TCO Certified Edge
LightSensor
PowerSensor 2*
Post consumer recycled plastic
85%+OBP 5%
Recyclable packaging material
100 %
Specific Substances
Mercury free
PVC / BFR free housing
Compliance and standards
Regulatory Approvals
CB
CE Mark
TUV/GS
TUV Ergo
TCO Certified
MEPS
EAC
UKCA
EMF
FCC
ICES-003
eyesafe® CERTIFIED 2.0
TUV Rheinland Low Blue Light (Hardware Solution)
Cabinet
Finish
Texture
Foot
Silver
Front bezel
Charcoal
Rear cover
Charcoal
Note
Note
* Radius of the arc of the display curvature in mm
* Response time value equal to SmartResponse
* NTSC Area based on CIE1976
* sRGB Area based on CIE1931
* For Video transmission via USB-C, your Notebook/device must support USB-C DP Alt mode
* Activities such as screen sharing, on-line streaming video and audio over the Internet can impact your network performance. Your hardware, network bandwidth and its performance will determine overall audio and video quality.
* For USB-C power and charging function, your Notebook/device must support USB-C standard Power Delivery specifications. Please check with your Notebook user manual or manufacturer for more details.
* If your Ethernet connection seems slow, please enter OSD menu and select USB 3.0 or higher version which can support the LAN speed to 1G.
* EPEAT rating is valid only where Philips registers the product. Please visit https://www.epeat.net/ for registration status in your country.
* The display colors reduce to 8 bits, the max resolution of HDMI can be 5120x1440 @ 75Hz, and DisplayPort can be 5120x1440 @ 120Hz
* It's for laptop with DSC, if not, the max resoluiton of Thunderbolt 4 input and ouput can be 5120x1440 @ 60Hz, 8 bits display color and with USB 3.2 Gen1.
* Please note that the PowerSensor 2 is only functional with Windows 11 installed. When PowerSensor 2 is activated, WAL means Walk Away Lock and WOA means Wake On.
* The monitor may look different from feature images.
* The products and accessories listed on this leaflet may differ by country and region.
