Extreme Networks ExtremeWireless AP310i Wi-Fi 6 (802.11ax) Indoor Access Point
Out of stock
Extreme Networks ExtremeWireless AP310i Wi-Fi 6 (802.11ax) Indoor Access Point
- Brand: Extreme Networks
- MPN: AP310i-WR
- Part #: NAPEXN63100
- UPC:
- Brand: Extreme Networks
- MPN: AP310i-WR
- Part #: NAPEXN63100
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Indoor Access Points





Extreme Networks ExtremeWireless AP310i Wi-Fi 6 (802.11ax) Indoor Access Point
- Brand: Extreme Networks
- MPN: AP310i-WR
- Part #: NAPEXN63100

Product URL: https://www.pbtech.com/pacific/product/NAPEXN63100/Extreme-Networks-ExtremeWireless-AP310i-Wi-Fi-6-80
Features
AP310i/e Access Point
High-Efficiency Wi-Fi 6 Indoor Access Point, based on a new system-on-a-chip (SoC) architecture providing the best value for a Wi-Fi 6, Dual 5 GHz access point
Wi-Fi 6 Technology
802.11ax technology enhances Wi-Fi efficiency by burrowing key technology (OFDMA) from cellular to increase device capacity and improve spectral efficiency, extracting more out of available Wi-Fi spectrum.
Optimizes RF for the Optimal User Experience
ExtremeAI and SmartRF uses AI/ML technology to monitor and automatically adjust Wi-Fi radios to achieve the best coverage and greatest client performance, even in dynamic RF environments.
802.11ax Technology
Whereas prior generations of 802.11n, 802.11ac wave 1 and 2, can be considered generational improvements, each building on the prior standard, the new PHY technology of 802.11ax adds a significant level of new technology which takes Wi-Fi networks to an entirely new level.
For more information: https://www.extremenetworks.com/product/ap310/
Specifications
Interfaces
(2) Autosensing 10/100/1000 Ethernet Port, RJ45
USB3.0, Type A , 0.5A
Power Specifications
IEEE 802.3af PoE Power
Power Options
Power Draw: Typical: 9W, Max:11.1W (w/o USB)
Typical: 12W, Max:14W (w/ USB)
802.3af Power over Ethernet (PoE) capable
Gigabit Ethernet port (RJ-45 power input pins:
Wires 4,5,7,8 or 1,2,3,6)
802.3af Power over Ethernet injector
PoE Out Supports 802.3af Powered Devices (PD) when powered by 802.3at
Physical
6.4" x 6.4" x 1.7" (165mm x 165mm x 45mm)
AP310i/e: 1.5 lbs (.7 kg)
Antennas
AP310i - Internal Antennas
(2) Integrated dual band, 2.4 GHz/5 GHz omnidirectional antennas
(2) Integrated single band, 5.1-5.8 GHz omnidirectional antennas
(1) Integrated single band, 2.4-2.5 GHz omnidirectional antennas for BLE AP310e - External Antenna
(4) RP SMAs connectors
(1) RP SMAs connectors for BLE
Mounting
Wall, and flat tile and 15/16" wide tbar, mount included as part of AP
Built-in slot for Kensington type locks
5/8" Ceiling tile protrusions on 9/16". 15/16" and 1.5" wide t-bars sold as an accessory
Flush ceiling tiles with 9/16". 15/16" and 1.5" wide t-bars sold as an accessory
Environmental
Operating: AP310i: 0 to 50°C
AP310e: -20 to 55°C
Storage: -40 to 70°C
Environmental Discharge
+/-8 kV (contact discharge)/ +/-15 kV (Air Discharge)
Environmental Compliance
UL2043 - Plenum Rated
Regulatory Compliance
Product Safety Certifications
IEC 62368/60950-1, EN 62368/60950-1, USA 62368/60950-1, AS/NZS 62368/60950.1, Intertek NTRL
RoHS Directive 2011/65/EU
