Huawei eKitEngine AP361 (AX1800) Dual-Band 4-Stream Wi-Fi 6 Access Point (PoE 10W)
Huawei eKitEngine AP361 (AX1800) Dual-Band 4-Stream Wi-Fi 6 Access Point (PoE 10W)
- Brand: Huawei
- MPN: 50086871
- Part #: NAPHUA50086871
- UPC:
- Brand: Huawei
- MPN: 50086871
- Part #: NAPHUA50086871
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Ceiling Mounted Access Points





Huawei eKitEngine AP361 (AX1800) Dual-Band 4-Stream Wi-Fi 6 Access Point (PoE 10W)
- Brand: Huawei
- MPN: 50086871
- Part #: NAPHUA50086871

Product URL: https://www.pbtech.com/pacific/product/NAPHUA50086871/Huawei-eKitEngine-AP361-AX1800-Dual-Band-4-Stream
Features
Settled AP | 802.11ax | 1.775 Gbps device rate | Dual-radio | 80 access users recommended | Max. 128 access users | 23 dBm transmit power | Smart antenna | 20 m optimal coverage range
Wireless Network with Guaranteed Security
WPA3 with industry's strongest encryption ensuring network security.
AI-based Intelligent Signal Optimization
Adaptive channel adjustment, ensuring Internet access signal quality 20% greater coverage range and one more wall penetrated.
Seamless Roaming
Seamless roaming steering technology Eliminating service interruption for mobile terminals
Powerful Forwarding capabilities
Smooth multi-channel HD video conferencing without frame freezing, improving user experience
Specifications
Wi-Fi standard
2.4G: 802.11b/g/n/ax 5G: 802.11a/n/ac/ac Wave 2/ax
Installation Type
Wall,Ceiling (Solid Wall/Gypsum Board/Spring Tee/Flat-Edge T-Rail/Channel Rail/Beam/Threaded Rod)
Optimal Signal Distance (m)
20
Max Number of Access Users
128
Recommended Number of Access Users
80
Device Rate
1.775 Gbps
Maximum number of physical ports on the entire device
GE (RJ45) x 1, 10M/100M/1000M auto-sensing
Radio number
2
Maximum channel bandwidth [MHz]
Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 80 MHz
Maximum transmit power
2.4 GHz: 20 dBm/chain 23 dBm (combined power) 5 GHz: 20 dBm/chain 23 dBm (combined power) Note: In V200R024C10 and later versions, the combined power is increased to 23 dBm by default. In versions earlier than V200R024C10, the combined power is only 20 dBm. To increase the transmit power for the AP running an earlier version, install the corresponding patch by referring to the announcement on the official website.
MIMO spatial streams
Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2
Maximum power consumption [W]
9.4
Input voltage range [V]
PoE: 802.3af
Dimensions without packaging (H x W x D) [mm(in.)]
Diameter x depth: 180 mm x 35 mm (7.09 in. x 1.38 in.)
Dimensions with packaging (H x W x D) [mm(in.)]
200 mm x 231 mm x 61 mm (7.87 in. x 9.09 in. x 2.40 in.)
Weight without packaging [kg(lb)]
0.45 kg (0.99 lb)
Weight with packaging [kg(lb)]
0.75 kg (1.65 lb)
Long-term operating temperature [°C(°F)]
0°C to 40°C (32°F to 104°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Long-term operating relative humidity [RH]
5% RH to 95% RH, non-condensing
Radio interface
Built-in smart antennas
Antenna gain
2.4G: 4 dBi/chain (peak) 2 dBi (combined gain) 5G: 5 dBi/chain (peak value) 3 dBi (combined gain)
Operating frequency band
2.4GHz,5GHz
