Ubiquiti UISP WAVE-PRO 60GHz 5.4Gbps PtMP Wave Client Station with 5Ghz Backup
- Brand: Ubiquiti
- MPN: WAVE-PRO
- Part #: NAPUBI6036

Product URL: https://www.pbtech.com/pacific/product/NAPUBI6036/Ubiquiti-UISP-WAVE-PRO-60GHz-54Gbps-PtMP-Wave-Clie
Features
Ubiquiti UISP Wave Pro High-capacity 60 GHz radio for long-distance 2.7 Gbps Full Duplex, PtP Bridge and PtMP links with 5GHz Backup Radio.
- Max. link range: PtP: Up to 15 km, PtMP: Up to 8 km (Wave AP), up to 6 km (Wave AP Micro)
- Max. throughput: 5.4 Gbps (2.7 Gbps duplex)
- 5 GHz weatherproof backup radio (Max. throughput: 800 Mbps)
- (2) 2.5 GbE and (1) 10G SFP+ ports
- Ergonomic transportation handle
- Precision alignment mount
- Integrated GPS & Bluetooth
Building Features
Specifications
Brand
Ubiquiti
MPN
WAVE-PRO
Dimensions
424.4mm (diameter) x 166.2mm
Weight
Without mount: 2.8 kg (6.2 lb)
With mount: 4 kg (8.8 lb)
Enclosure material
Aluminum alloy, UV stabilized plastic
Mount material
Stainless steel
Pole mount diameter
25 to 76.2 mm (1 to 3") on pipe outer diameter
Wind loading
369 N at 200 km/h (83 lbf at 125 mph)
Weatherproofing
IPX6
Processor
Quad-core ARM® Cortex®-A53 at 1.4 GHz
Memory
DDR3L 512 MB
Networking interface
(2) 2.5 GbE RJ45 ports
(1) 10G SFP+ port
Max. power consumption
26W
Power method
Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Passive PoE 2-pairs (4, 5+; 7, 8-), for 44-54V DC only
Power supply
48V DC, 0.65A, 2.5 GbE PoE adapter (Included)
Supported voltage range
44-54V DC
22-27V DC
GPS
Yes
Button
Factory reset
LEDs
Power, (2) Ethernet, SFP+ , GPS, link
Ambient operating temperature
-40 to 60° C (-40 to 140° F)
Ambient operating humidity
5 to 95% noncondensing
Certifications
FCC, IC, CE
