Huawei eKit S380-L4P1T Multi-Service Gateway with built-in WAC (32APs Managed)

1GbE WAN - 4x 1GbE PoE LAN

PB Tech price

NZD $ 500 .00

$ 500 .00

Huawei eKit S380-L4P1T Multi-Service Gateway with built-in WAC (32APs Managed)

1GbE WAN - 4x 1GbE PoE LAN

Brand: Huawei
MPN: 98012178
Part #: NETHUA98012178
UPC:

NEW ARRIVAL

PB Tech price

NZD $ 500 .00

In stock at NZ Logistics Centre

Delivery: Order now and it ships on 09 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Huawei
MPN: 98012178
Part #: NETHUA98012178
UPC:

Be the first to review this product

Wireless Technology

N/A

Ethernet Ports Per Unit

USB Ports

Wireless Transmission Speed

N/A

WiFi Bands

N/A

Cellular Connectivity

Not Specified

HyperFibre Compatible

Coverage Area

Not Specified

View full specs

Returns & Warranty Bulk Quote Print Page

Features

Huawei eKitEngine S380 Series Multi-Service Gateway

Huawei eKitEngine S380 series Multi-Service Gateway include various models, such as those with 4 downlink GE electrical ports, 8 downlink GE electrical ports (PoE/non-PoE ports), or GE uplink ports. With features like easy installation and deployment, as well as flexible Ethernet networking, the products can be widely used for indoor coverage in SME markets such as SOHO enterprise office, economic hotels, factories, primary and secondary education, and building security.

Powerful: 50% larger connection capacity

Fast: 2x faster forwarding

Stable: PoE on all ports, compatible with 100+ types of non-standard terminals

Specifications

Switching Capacity

8Gbps

Packet forwarding rate

Upload:300 Kpps, download:420 Kpps

Egress bandwidth

1Gbps

Maximum user

200

Managed APs

GE RJ45

5 (4 PoE+) (1G/100M/10M)

WAN ports

1 x GE WAN

LAN ports

4 x GE LAN (50 W PoE+)

PoE

Supported

Maximum PoE power consumption [W]

Dimensions without packaging (H x W x D) [mm(in.)]

Basic dimensions (excluding the parts protruding from the body): 35.0 mm x 210.0 mm x 130.0 mm (1.38 in. x 8.27 in. x 5.12 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 35.0 mm x 210.0 mm x 136.3 mm (1.38 in. x 8.27 in. x 5.37 in.)

Dimensions with packaging (H x W x D) [mm(in.)]

90.0 mm x 285.0 mm x 180.0 mm (3.54 in. x 11.22 in. x 7.09 in.)

Installation type

Desk mounting,Wall mounting

Chassis material

Metal

Weight without packaging [kg(lb)]

0.9 kg (1.98 lb)

Weight with packaging [kg(lb)]

1.1 kg (2.43 lb)

Typical power consumption [W]

7.19

Maximum power consumption [W]

61.65 W (PoE: 50 W)

Long-term operating temperature [°C(°F)]

0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.)

Long-term operating relative humidity [RH]

5% RH to 95% RH, non-condensing

Power supply mode

Power adapter

Input voltage range [V]

Power adapter input: 90-290 V AC; 47-63 Hz

Power supply surge protection [kV]

Power adapter: ±6 kV in differential mode and ±6 kV in common mode

Heat dissipation mode

Natural heat dissipation

Certification

EMC certification Safety certification Manufacturing certification

Manufacturer Part No:

98012178

Brand:

Huawei

Product Type:

UPC

Product Family:

eKit

Shipping Weight:

1 kg

PB Part No:

NETHUA98012178

Product Model:

S380-L4P1T

Warranty: 12 months *
