LevelOne Gigabit PoE Injector, 802.3at/at/bt, 90W
- Brand: LevelOne
- MPN: POI-5003
- Part #: NETLEL005003

Product URL: https://www.pbtech.com/pacific/product/NETLEL005003/LevelOne-Gigabit-PoE-Injector-8023atatbt-90W
Features
LevelOne Gigabit PoE Injector, 802.3at/at/bt, 90W
The POI-5003 is a single port, high-power 90W PoE PSE solution for remote PoE PD devices.
Generating up to 90W through 8 pins, the POI-5003 supplies remote power for new applications such as high-power wireless access points, pan-tilt-zoom (PTZ) IP cameras, lighting, panel displays for digital signage and video-phones.
It complies with IEEE 802.3bt PoE standards to deliver 90W on both end-point and midspan pairs with a total power of 90W PoE output.
- Auto-detection and protection of non-standard PoE devices
- IEEE 802.3af/at/bt PoE compliant to simplify deployment and installation
- 10/100/1000Mbps wire speed transmission and reception
- Total PoE power budget: 90W,
- Unique interlocking feature for easy installation
Specifications
Network
Ethernet interface type
Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u
Features
Product colour
Black
LED indicators
Yes
Ports & interfaces
RJ-45 input ports
1
RJ-45 output ports
1
Power
Total Power over Ethernet (PoE) budget
90 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
0 - 95%
Storage temperature (T-T)
0 - 70 °C
Storage relative humidity (H-H)
0 - 95%
Weight & dimensions
Width
65.3 mm
Depth
40 mm
Height
179.5 mm
Weight
750 g
