MikroTik CRS326-4C+20G+2Q+RM CloudRouterSwitch 326-4C+20G+2Q+RM with 20 x 2.5Gbps Ethernet,4xComboand 2 x 40G QSFP+

PB Tech price

NZD $ 1,515 .65

$ 1,515 .65

MikroTik CRS326-4C+20G+2Q+RM CloudRouterSwitch 326-4C+20G+2Q+RM with 20 x 2.5Gbps Ethernet,4xComboand 2 x 40G QSFP+

Brand: MikroTik
MPN: CRS326-4C+20G+2Q+RM
Part #: NETMKT1477
UPC:

PB Tech price

NZD $ 1,515 .65

In stock at NZ Logistics Centre

Delivery: Order now and it ships on 10 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: MikroTik
MPN: CRS326-4C+20G+2Q+RM
Part #: NETMKT1477
UPC:

Be the first to review this product

10 Gigabit

10 Gigabit Ports

Form Factor

1U Rackmount

Management Level

Managed L2+

Number of Ports

24 Ports

PoE Ports

PoE Budget

View full specs

Returns & Warranty Bulk Quote Print Page

Features

MikroTik CloudRouterSwitch 326-4C+20G+2Q+RM with 20 x 2.5Gbps Ethernet, 4 x Combo and 2 x 40G QSFP+

The mighty Marvell Prestera switch-chip that comes with a dedicated CPU can handle all your daily tasks without breaking a sweat. VLAN's, Jumbo frames, link aggregation, ACL rules… You can even do Layer3 routing!

Dual-redundant power supplies and an extra 100 Mbps Ethernet port for management purposes will save you a lot of troubles in the long run. And we've included everything you need to secure this marvelous switch in a standard 19" rackmount!

Like many MikroTik devices, this one was born out of necessity. Our video team needed a fast, cost effective solution that would enable them to connect all the studio devices without the need for a dedicated rack - the studio has no extra space. They use the 2.5 Gigabit Ethernet ports to connect all the equipment, computers, extra screens and recorders, and so on. Then the four combo ports go to other departments in case they need to transfer some footage for review. One 40 Gigabit line goes to the NAS media server and another 40 Gigabit line goes to the editor's multimedia station where all the magic happens. This is a wire speed switch, so the team can get maximum speed on all the ports and make all the videos so much faster.

Specifications

Brand

MikroTik

MPN

CRS326-4C+20G+2Q+RM

CPU

QCA9531 650 MHz

CPU architecture

MIPSBE

CPU core count

Size of RAM

128 MB

RAM type

DDR2

Storage

32 MB, NAND

Number of 100M Ethernet ports

Number of 2.5G Ethernet ports

Number of 40G QSFP+ ports

Number of Combo 10G Ethernet/ SFP+ ports

Operating system RouterOS v7, License level

Switch chip model

98DX8332

Switch connection to CPU

1 Gbps

Dimensions

443 x 258 x 44 mm

Operating temperature

-20°C to +60°C

Number of AC inputs

AC input range

100-240 V

Nominal voltage

12 V

Nominal current

10.8 A

Max power consumption (without attachments)

51 W

Max power consumption

70 W

Manufacturer Part No:

CRS326-4C+20G+2Q+RM

Brand:

MikroTik

Product Type:

UPC

Product Family:

Shipping Weight:

2 kg

PB Part No:

NETMKT1477

Product Model:

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
