MikroTik R11e-LTE7 3G/4G/LTE CAT7 miniPCI-e Card with Carrier Aggregation and Band 28 support
- Brand: MikroTik
- MPN: R11e-LTE7
- Part #: NETMKT1535
Product URL: https://www.pbtech.com/pacific/product/NETMKT1535/MikroTik-R11e-LTE7-3G4GLTE-CAT7-miniPCI-e-Card-wit
Features
The MikroTik R11e-LTE7 is an easy drop-in upgrade for RouterBOARD integrators. This miniPCIe CAT7 modem delivers up to 300 Mbps with Band 28 & 32 support and carrier aggregation for better rural performance. Fully compatible with RouterOS v7 devices such as LtAP and RBM33G - upgrade your LTE speed without changing your setup.
The next-generation miniPCIe LTE CAT7 modem for your RouterBOARDs. Drop-in replacement for FG621-EA - now offering 300 Mbps down / 100 Mbps up, with added Band 32 & Band 28 support.
Perfect for LtAP, RBM33G, or any system with miniPCIe or USB (if you're using an adapter). Compared to the previous FG621 version, this miniPCIe unit has a smaller form-factor, so it should fit better inside more devices. Upgrade your mobile connectivity without changing the whole setup!
- LTE Cat7
- Supports Band 28
Specifications
MPN
R11e-LTE7
MTBF
Approximately 100000 hours at 25°C
Tested ambient temperature
-10°C to 55°C
Max power consumption
5 W
RF connector type
2 uUFL
3G Category
R8 (DL 42.2 Mbps; UL 5.76 Mbps)
3G bands
1 (2100MHz), 5 (850MHz), 8 (900MHz), 3 (1800MHz)
LTE Category
7 (DL 300 Mbps; UL 100 Mbps)
MIMO DL
2x2
MIMO UL
1x1
LTE FDD bands
1 (2100MHz), 3 (1800MHz), 5 (850MHz), 7 (2600MHz), 8 (900MHz), 20 (800MHz), 28 (700MHz), 32 (1500MHz)
LTE TDD bands
38 (2600MHz), 40 (2300MHz), 41 (2500MHz)
TAC
35312597
Certification
CE, ROHS
IP rating
IP00
