Mimosa B24 24GHz 1.5 Gbps PtP backhaul

PB Tech price
PB Tech price
NZD $ 498 .26
$ 498 .26
$498.26  +GST
$498.26

Mimosa B24 24GHz 1.5 Gbps PtP backhaul

  • Brand: Mimosa
  • MPN: B24
  • Part #: NETMMS690056
  • UPC:
PB Tech price
NZD $ 498 .26 $ 498 .26
In stock at NZ Logistics Centre
Delivery: Order now and it ships on 11 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$498.26  +GST
$498.26
Add To Compare
Stock Alerts
Click or hover over image to enlarge
  • Brand: Mimosa
  • MPN: B24
  • Part #: NETMMS690056
  • UPC:
Returns & Warranty Bulk Quote Print Page

Features

Breaking through the barriers of price, size, and power requirements, the B24 delivers up to 1.5 Gbps of aggregate speed in the less crowded and unlicensed 24 GHz frequency band. By dynamically adjusting bandwidth based on upstream and downstream demand, the B24 efficiently delivers the most usable bandwidth possible with 1 ms low-latency, to meet modern internet traffic needs. The B24 is revolutionizing the industry, satisfying the needs of customers in multiple applications and verticals.



Lightweight, Low Power

At a fraction of the weight, size and power of alternative solutions, the B24 is incredibly easy to install and fits into any setting. At 6 lbs and consuming 19.5 W, the B24 is great for battery backup installations.

Fiber Ready

For flexibility, redundant ethernet and fiber connections are supported, a feature that was previously only available in stratospherically priced outdoor products.



GPS Sync for Collocation

Like other Mimosa products, GPS synchronization allows collocated B24 radios to share the same channel, permitting up to eight links to operate on the same rooftop, each running at 1.5 Gbps.

Reliable Shorthaul

With superior reliability compared to the congested 5 GHz band, the B24 goes the distance even in the rain with reliable links up to 3 km (2 mi), and reaching farther than other 60/70/80 GHz alternatives.

Specifications

Brand

Mimosa

Model

B24

Max Throughput

Up to 1.5 Gbps IP aggregate UL/DL

Max PHY rate

1.7 Gbps PHY

Latency

<1 ms

Supported MAC

TDMA, TDMA-FD

MIMO and Modulation

4x4:4 MIMO OFDM up to 256 QAM

Bandwidth

Single or dual channel; 20/40/80 MHz channel width

Channel Spacing

Single channel allows 5 MHz channel spacing; Dual channel allows separate, no-overlapping 5 MHz spacing increments

Frequency Range

24.05-24.25 GHz worldwide support; Operating range is 24.07-24.23 GHz

EIRP

~20 dBm (CE) ~33 dBm (FCC/IC) ~37 dBm (other regions)

Min Output Power

-20 dBm

Power Increment Level

1 dB

Sensitivity (MCS0)

-84 dBm @ 80 MHz, -87 dBm @ 40 MHz, -90 dBm @ 20 MHz

Antenna Gain

33 dBi

Antenna Beamwidth (3dB)

3.0º

Antenna Elevation Adjust

+-2.5º azimuth mechanical adjust, +-15º elevation mechanical adjust

Front to Back Ratio

>30 dB

Cross-Polar Isolation

>20 dB

Polarization

Dual-linear (slant 45º)

Max Power Consumption

19.5 W

System Power Method

48V DC 802.3at compliant

System Lightning & ESD Protection

6 kV

PoE Power Supply

Passive POE compliant, 50V 1.2A power over Ethernet (included)

Dimensions

Height: 260 mm
Width: 260 mm
Depth: 134 mm without bracket; 252 mm with bracket

Weight 2.76 kg (6 lbs) including mount

Enclosure Characteristics

Outdoor UV stabilized plastic; Powder-coated, aluminum mounting panel

Wind Survivability

200 km/h (125 mph)

Wind Loading

12.52 kg @ 160 km/h (27.61 lbs @ 100 mph)

Mounting

Precision lightweight aiming pole mount with +-15º elevation and +-2.5º horizontal adjustment screws

Network Interfaces

Gigabit Ethernet (RJ45) and gigabit fiber (SFP cage); Operation modes: Hot standby

Outdoor Ingress Protection Rating

IP67

Operating Temperature

-40°C to +55°C (-40°F to 131°F)

Operating Humidity

5 to 100% condensing

Operating Altitude

4,420 m max

Shock & Vibration

ETS 300-019-2-4 class 4M5

Approvals

FCC 15.249, IC RSS210, ETSI EN 300-440 V2.1.1, CE

RoHS Compliance

Yes; WEEE

Safety

EC/EN/ 60950-1

Gigabit Ethernet

10/100/1000-BASE-T

Fiber Capable

Supports SFP interface for fibre operation

Ethernet Redundancy

Dual-Link failover; Does not support simultaneous ethernet + fiber operation

Dual Protocol Operation

2 dual-stream radios operating on non-contiguous frequencies allow for traditional FDD-like performance or TDMA automatic load balancing of traffic across 4 total MIMO streams with individual stream encoding up to 256 QAM

Management Services

Mimosa cloud monitoring and management, SNMPv2 & Syslog monitoring, HTTPS, HTML5 based web UI, 2.4 GHz 802.11b/g/n radio for local management access

Smart Antenna Alignment

Hands-free, dedicated 2.4 GHz WiFi management radio

Smart Spectrum Management

Active scan monitors/logs ongoing RF interference across channels with no service impact; Dynamic auto optimization of bandwidth, power, and modulation

Security

128-bit AES PSK with hardware acceleration

QoS

Supports 4 pre-configured QoS levels

GPS Location

GNSS-1 (GPS + GLONASS)

Collocation Synchronization

1PPS GPS TX/RX synchronization for collocated co-channel radios; Adjustable up/downstream bandwidth ratio

Manufacturer Part No:
B24
Brand:
Mimosa
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1.01 kg
PB Part No:
NETMMS690056
Product Model:
-
Warranty: 12 months *
