TP-Link Omada MC112CS Gigabit WDM Media Converter Up to 20 km

PB Tech price
PB Tech price
NZD $ 30 .43
$ 30 .43

Out of stock

Buy Limit

2 Units Per Customer

TP-Link Omada MC112CS Gigabit WDM Media Converter Up to 20 km

  • Brand: TP-Link
  • MPN: MC112CS
  • Part #: NETTPL1112
  • UPC:
Buy Limit

2 Units Per Customer

PB Tech price
NZD $ 30 .43 $ 30 .43


Delivery: Out of stock
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
Buy Limit

2 Units Per Customer

Features

TP-Link Omada MC112CS 10/100Mbps WDM Media Converter

The MC112CS is a media converter designed to convert 100BASE-FX fiber to 10/100Base-TX copper media and vice versa. Adopting WDM technology, MC112CS takes only one fiber cable to transmit and receive data, which will save half cabling cost for you. Designed under IEEE 802.3u 100Base-TX and 100Base-FX standards, the MC112CS is designed for use with single-mode fiber cable utilizing the SC-Type connector.

The MC112CS supports longwave (LX) laser specification at a full wire speed forwarding rate. It works at 1310nm on transferring data and at 1550nm on receiving data. So the other end device to cooperate with the MC112CS should work at 1550nm on transferring data and at 1310nm on receiving data. Another TP-Link´s media converter MC111CS is just one of the examples to cooperate with MC112CS. Auto MDI/MDI-X for TX port, Auto negotiation of duplex mode on TX port. The MC112CS will transmit at extended fiber optic distances utilizing single-mode fiber up to 20 kilometers (12.5 miles).

- Complies with 802.3u 10/100Base-TX, 100Base-FX standards
- Auto-negotiation of Half-Duplex / Full-Duplex transfer mode
- Adopts WDM technology, transmitting and receiving data on one single fiber
- Work with MC112CS WDM single fiber media converter
- Extends fiber distance up to 20km (12.5 miles)



Specifications

Standards and Protocols

IEEE 802.3, IEEE 802.3u

Basic Function

Adopts WDM technology
Half/Full-Duplex transfer mode for FX port
minimize the loss caused by link failure timely
Extends fiber distance up to 20km

Interface

1 x 100M SC/UPC port
1 x 10/100M RJ45 port (Auto MDI/MDIX)

Wave Length

1310nm Tx/1550nm Rx

WDM TX

1310nm

WDM RX

1550nm

Network Media 10BASE-T

UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100ohm STP (maximum 100m)

Network Media 100BASE-T

UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100ohm STP (maximum 100m)

Network Media 100BASE-FX

Single-mode Fiber

Dimensions ( W x D x H )

3.7 x 2.9 x 1.1 in. (95 x 73 x 27 mm)

Power Supply

External Power Adapter

Max. Power Consumption

2.41W

LED

PWR, Link/Act

Safety & Emission

FCC, CE, RoHS

Package Content

Media Converter MC112CS
Power Adapter
Installation Guide

Environment

Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Manufacturer Part No:
MC112CS
Brand:
Product Type:
Gigabit WDM Media Converter
UPC
-
Product Family:
Omada
Shipping Weight:
0.5 kg
PB Part No:
NETTPL1112
Product Model:
MC112CS
Warranty: 36 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
Provide feedback on product content: If this product page is missing key information or you spotted a mistake please let us know.
