Ubiquiti U-PoE+ 30W Gigabit PoE Adapter (48V DC / 0.65A)
- Brand: Ubiquiti
- MPN: U-PoE+
- Part #: NETUBI10912

Product URL: https://www.pbtech.com/pacific/product/NETUBI10912/Ubiquiti-U-PoE-30W-Gigabit-PoE-Adapter-48V-DC--065
Features
PoE+ Adapter (30W)
An adapter that can power UniFi PoE+ devices, reduce dependency on PoE switch power, and provide a Gigabit LAN connection.
- Delivers up to 30W of PoE+
- Surge, peak pulse, and overcurrent protection
- Contains RJ45 data input, AC cable with earth ground, and PoE+ output
- LED indicator for status monitoring
Specifications
Dimensions
93 x 62 x 35 mm (3.7 x 2.4 x 1.4")
Weight
156 g (5.5 oz)
Output voltage
48V DC @ 0.65A
LAN activity indicator
No
Gigabit LAN port
Yes
Remote reset capability
No
Reset button
No
Rated voltage
100-240V AC @ 50/60Hz
Input current
0.75A max.
Inrush current
<100A peak at 26°C
Efficiency
87%
Output ripple
1% max.
Switching frequency
70 kHz max.
Line regulation
= 3%
Load regulation
= 5%
2-pair powering
Pins 4, 5 (+) and 7, 8 (-)
4-pair powering
No
AC connector
IEC-320 C6
Data In / PoE
RJ45 shielded socket
Surge protection
Difference and common mode
Clamping protection
11V data, 60V power
Max. surge discharge
1500A (8/20 µs) power
Peak pulse current
36A (10/1000 µs) data
Shunt capacitance
<5 pF data
Response time
<1 ns
Ambient operating temperature
0 to 40° C (32 to 104° F)
Storage temperature
-30 to 70°C (-22 to 158° F)
Ambient operating humidity
10 to 95% noncondensing
Certifications
CE, FCC, IC, UL
Compatibility
U6-LR
UVC-G5-PTZ
U6-IW
UVC-AI-DSLR
UVC-AI-Pro
UDB-Pro
UTP-G3-Touch-Wall
UTP-TouchMax
UA-Ultra
