SOCKET TX3995-3058 SocketScan S370 Universal NFC & QR Code Mobile Wallet Reader - Black

PB Tech price

NZD $ 846 .96

$ 846 .96

Out of stock

Limited Supply - only stock on hand available, when sold out we may not be able to source this product again.

SOCKET TX3995-3058 SocketScan S370 Universal NFC & QR Code Mobile Wallet Reader - Black

Brand: SOCKET
MPN: TX3995-3058
Part #: POSSKT1006654
UPC:

PB Tech price

NZD $ 846 .96

Out of stock

Delivery: Out of stock

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: SOCKET
MPN: TX3995-3058
Part #: POSSKT1006654
UPC:

Be the first to review this product

Returns & Warranty Bulk Quote Print Page

Features

SocketScan® S370 Universal NFC & QR Code Mobile Wallet Reader - Black

The SocketScan S370, is a data capture platform that supports 1D and 2D barcode scanning as well as NFC Reading and Writing, designed to facilitate mobile wallet applications via on screen scanning or tap-and-go NFC Reading. It combines the latest 13.56 MHz Near Field Communication (NFC) contactless technology with barcode scanning and Bluetooth LEconnectivity.

Main Features

- Compatible with iOS, Android, Windows®, Mac and Linux.
- Wireless (Bluetooth LE) - Connectivity with iOS, Android and Windows devices with long-range Bluetooth connection up to 330 feet (100m).
- Easy Updates - Firmware can be updated over Bluetooth using an iOS or Android app.
- Battery or plug in - Comes with an easy-to-replace rechargeable battery or plug it into power.
- Long Lasting Battery - Power to last 16 hours or 2 shifts.
- User Feedback - Intuitive LED indicators let users monitor battery, Bluetooth connection and scanning or reading status.
- Configurable Visual Feedback/Credential Identifier - For ease of differentiating among the various transactions - distinguishing lights appear for access (blue), payment (green), vaccine (yellow), loyalty (purple). For two credentials, reader can show both colors, half and half.
- Customizable Audio Feedback - Program the S370 to speak and add sounds and tones.
- Keyboard Emulation - The combination of the S370 (reader mode) and Socket Mobile Keyboard provides HID equivalent for use in any app or web form. Fast, reliable with full error checking.
- HID Basic Mode - emulates a keyboard and delivers the data to the active cursor location. No software installation required.
- Application Mode - Along with Socket Mobile's CaptureSDK enables easy integration in your applications to unite the S370 into your ecosystem.
- Exceptional Form Factor - Small, sturdy and fits perfectly in areas with limited counter or table space.

NFC Features

- Reading - Reads Apple, Google, & Samsung Wallet Passes, Fast NFC and RFID Reader and Mobile Driver's Licenses (mDL) (HF tags, labels, smart devices).
- Writing - Write/Encode, lock, unlock tags.
- Reader Mode Templates - Reader and HID mode for popular tag types. Customizable with an application over BLE.

Scanning Features

- Scanning - Reads QR Codes, Data Matrix, PDF417, 1D and 2D, on paper or screen omni-directional ability allowing intuitive rapid scanning.
- Auto Scan Mode - Automatic scanning provides continuous scanning capabilities.
- Decoding Ability - Reads damaged and poorly printed barcodes.

*The S370 requires a supported software application. Before purchasing, please check with your application provider to confirm they are using the latest version of Socket Mobile's CaptureSDK within the app,
*The S370 is not a credit or debit card reader and cannot receive payments.

Specifications

Dimensions

2(D) x 1.5 (H) in (50.8 mm x 63.5 mm)

Weight/Mass

2.6 oz. (74g)

LEDs

Four Quadrant LED Circle (full RGB) that meets the EMV "Common User Interface Guidelines" and provides intuitive feedback to the cardholder during normal operation and also can be used to simplify setup and status.

Button

Power Button: On/Off

Power Connector

USB A Male to DC Plug Charging Cable 1.5 meters (4.9 feet)

Bluetooth Radio

Bluetooth LE V5.0 (2Mbps)

Bluetooth Range

Up to 100 m (330 ft.) depending on environment, range limit is usually due to the Host Device (phone, tablet or notebook)

Bluetooth Connection

"Keyboard"- Keyboard Emulation Profile
"Reader"- Reader Only Profile (default)
"Coupler"- Reader/Writer Profile (advanced user)

Operating Temperature

-20° to 50° C (-4° to 122° F) (Plugged into power)
0° to 38° C (32° to 100° F) (Battery Powered)

Storage Temperature

-40° to 70° C (-40° to 158° F)

Relative Humidity

95% at 60° C (140° F) (non-condensing)

Type of Battery

Lithium Ion Cell

Battery Life

300 charge-discharge cycles

Charge Time

4 Hours

Battery Life - Per Full Charge

Standby time: 16 hours
Active Operation: 2,400 reads
Note: Battery life varies depending on ambient temperature, read attempts, and age of battery

Number of Batteries Used

Weight of battery

39g

Percentage Lithium

37%

Battery mAh

1800 mAH

Number of cells per battery

Watt Hours per battery

8.51Wh

Type of Cell ( ex. AA)

NP-120

Chemical Composition( ex. Alkaline)

Lithium ion

Lithium Content

23.7%

Battery Voltage

3.7v

Hazmat

UN Number UN3481, P.I. 967

ROHS Compliance Indicator

Yes, included on product label

Android OS

Windows 10

Apple iOS

All devices supports: Keyboard Emulation Profile, Reader Only Profile and Reader/Writer Profile

Manufacturer Part No:

TX3995-3058

Brand:

SOCKET

Product Type:

SocketScan S370 Universal NFC & QR Code Mobile Wallet Reader

UPC

Product Family:

Shipping Weight:

1 kg

PB Part No:

POSSKT1006654

Product Model:

TX3995-3058

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
