Vestel PDU43UF82-4 Vestel 43in Professional UHD Signage
- Brand: Vestel
- MPN: PDU43UF82-4
- Part #: PRAVTL1021

Product URL: https://www.pbtech.com/pacific/product/PRAVTL1021/Vestel-PDU43UF82-4-Vestel-43in-Professional-UHD-Si
Features
Signal Failover
Our displays have a protection for "No Signal". If the source is disconnected, the display will either show your customized banner or search for any other signal from video sources. Since blank screen is the worst case scenario for advertisement, failover is one of the critical feature in our signage displays.
Display Control
Digital Signage Display SoC enables the users to control our displays using RS232 commands in a Local Area Network. Together with the full RS232 command list you can change/set volume, turn on/off the monitor, set a schedule for content display, set a webpage link to be displayed and give a wide range of commands in real-time.
Scheduler
The built in scheduler is one of the many important included features. The scheduler allows you to plan daily routines of when the display is powered on or off, along with selection of different sources or USB playlists.
Pixel Shifting
The Pixel Shifting feature can be activated in order to reduce the potential risk of image sticking when static content is displayed over long periods of time. The feature periodically shifts the image on the display, without causing any interference of the visual experience.
External Device Connections
You may want to connect your teleconference system, screen sharing system, set-top box or external PCs via HDMI port. For this purposes, our monitors help you to maximize user experience with HDMI CEC (Consumer Electronics Control) and HDMI Hotplug capabilities.
USB Security
This series lets your USB and your content to be secured within the back cover of the display. The cover is protected with a screw not allowing any outside intervention.
HDMI Wake Up
You will be able to show photo and video content automatically with USB Auto-play feature. SoC software gives you a choice to turn on USB auto-play function making it easy for end-users to show any media on the screen and not worry about anything else.
OPS Support
All our products in this series have compliance with OPS (Open Pluggable Standard). OPS will empower your screens with enhanced processing power and ability to choose Windows or Android as your operating system to fit your specific application.
Subtle Design
This series' displays exhibit ultra narrow bezel design eliminating the visual superfluities, directing audience focus on your advertised content. This series is found to be desirable for digital signage specific design: internal usb cover, OPS-slot, detachable power plug, carrying handles and IR extender.
SoC Content Management
With quad core SoC (System on Chip), this Series displays are the digital signage monitors for both offline designed content and cloud-based managed content. This helps your digital content to be displayed in the displays by content management systems.
Open Platform Support
Our SoC supports API (Application Programming Interface) for solution providers/integrators to develop and integrate any HTML5-based to be installed and used on our displays.
Daisy Chain
The display can mirror the content (to another display) into its display port out coming from its display port in. This set up creates a daisy chain like structure allowing for monitors to be set up as Video Wall mode.
Specifications
DISPLAY
Screen Size
43"
Panel Technology
IPS
Backlight Type
Direct-Type LED
Brightness (typical)
500 cd/m²
Native Resolution
3840 x 2160 (16:9) - UHD
Contrast Ratio (typical)
1200:1
Dynamic Constrast Ratio
50000:1
Response Time (typical)
8 ms
Active Area (H x V)
941 x 530mm
Pixel Pitch (H x V)
0.2451 x 0.2451 mm
Viewing Angle
178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Color Value
8bit, 16.7 M colors
Screen Treatment
3H
Haze Level
1%
Refresh Rate
60 Hz
Orientation
Landscape / Portrait
Operation Hours
24/7
Area of Usage
Indoor
BUILT-IN SYSTEM
Mainboard Model
17MB135VS
REAR I/OS
RGB Input
VGA(DE-15F)
RGB Output
N/A
Video Input
4xHDMI2.0 (HDCP2.2),1xDP1.2a, 2xUSB2.0, USB2.0(Internal)
Video Output
HDMI2.0, DP1.2a
Audio Input
Line In L/R
Audio Output
Headphone, Optic SPDIF
External Control
RS232(DE-9F), Ethernet(RJ45), Service(RJ12)
External Sensor
RJ12
MECHANICAL
Product Dimensions (WxDxH)
966 x 106 x 557 mm
Package Dimensions (WxDxH)
1050 x 178 x 718 mm
Product Weight
10.3 kg
Package Weight
13.65 kg
Vesa Mounting
200 x 200 mm - M6
Bezel Width
B:9 | T:6 | L/R:6 mm
ENVIRONMENTAL CONDITIONS
Operating Temperature
0-40°C
Operating Humidity
10-90%
POWER
Power Supply
110 VAC - 240 VAC - 50/60 Hz
POWER CONSUMPTION
Typical
62W (TBD)
Deep Standby
<=0.5 W
ACCESSORY
Standard
QSG, IB, Power Cord, Remote Control, RC Battery, Mounting Kit, Extension Brackets, IR Extender Cable
FEATURES
Main Features
Open Content Management Support, Scheduler, USB-Autoplay, Auto-Launch, HDMI-CEC, HDMI-Wakeup, Auto-switch on Failover, Panel Lock
Mechanical Features
Joystick, IR Extender Support, Rocker Switch, Detachable power cable, Carrying slots, Detachable logo positioning, Internal usb cover, Cable Holder
Optional Features
OPS Compliance, IR Overlay Touch Compliance
Speaker
2 x 8 W
CERTIFICATION
Safety
YES
EMC
YES
CE
YES
