Vestel PN65D-4H NEW Vestel Prime Series PN65+ - 65" 24/7
- Brand: Vestel
- MPN: PN65D-4H
- Part #: PRAVTL1042

Product URL: https://www.pbtech.com/pacific/product/PRAVTL1042/Vestel-PN65D-4H-NEW-Vestel-Prime-Series-PN65---65
Features
Vestel PN65D-4H NEW Vestel Prime Series PN65+ - 65" 24/7
- VAP400 (Vestel Android Platform 400)
- 2 GB DDR4 / 16 GB eMMC
- Resolution: 3840x2160 (UHD)
- Brightness: 500 cd/m²
- Operation: 24/7
- Embedded IR/IR Extender Options
- 30° Tilting Installation
- Application Areas: Retail, QSR, Corporate, Control Rooms, Transportation
Daisy Chain
The display can mirror the content (to another display) into its display port out coming from its display port in. This set up creates a daisy chain like structure allowing for monitors to be set up as Video Wall mode.
Usb Security
This series lets your USB and your content to be secured within the back cover of the display. The cover is protected with a screw not allowing any outside intervention.
Usb Auto-Play
You will be able to show photo and video content automatically with USB Auto-play feature. SoC software gives you a choice to turn on USB auto-play function making it easy for end-users to show any media on the screen and not worry about anything else.
Subtle Design
This series' displays exhibit ultra narrow bezel design eliminating the visual superfluities, directing audience focus on your advertised content. This series is found to be desirable for digital signage specific design: internal usb cover, detachable power plug and IR extender.
SoC Content Management
With quad core SoC (System on Chip), this Series displays are the digital signage monitors for both offline designed content and cloud-based managed content. This helps your digital content to be displayed in the displays by content management systems.
Scheduler
The built in scheduler is one of the many important included features. The scheduler allows you to plan daily routines of when the display is powered on or off, along with selection of different sources or USB playlists.
Pixel Shifting
The Pixel Shifting feature can be activated in order to reduce the potential risk of image sticking when static content is displayed over long periods of time. The feature periodically shifts the image on the display, without causing any interference of the visual experience.
Open Platform Support
SoC supports API (Application Programming Interface) for solution providers/integrators to develop and integrate any HTML5-based to be installed and used on the displays.
External Device Connections
You may want to connect your teleconference system, screen sharing system, set-top box or external PCs via HDMI port. For this purposes, these monitors help you to maximize user experience with HDMI CEC (Consumer Electronics Control) and HDMI Hotplug capabilities.
Display Control
Digital Signage Display SoC enables the users to control the displays using RS232 commands in a Local Area Network. Together with the full RS232 command list you can change/set volume, turn on/off the monitor, set a schedule for content display, set a webpage link to be displayed and give a wide range of commands in real-time.
Specifications
Panel
Screen Size
65"
Panel Technology
IPS
Backlight Type
Slim DLED
Brightness (typical)
500 cd/m²
Native Resolution
3840 x 2160 (16:9) - UHD
Contrast Ratio (typical)
1200:1 (typ.)
Dynamic Contrast Ratio
50000:1
Panel Life Time ( Min. )
50000 Hrs
Response Time (typical)
8 ms
Active Area (H x V)
1428.5 (H) × 803.5 (V) mm
Viewing Angle
178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
Color Value
1.07G (8bits + FRC)
Color Gamut
72% NTSC
Haze Level
1%
Refresh Rate
60 Hz
Orientation
Landscape / Portrait
Operation Hours
24/7
Area of Usage
Indoor
Built-in System
Mainboard Model
17MB400VS
Operating System
Custom OS (built on Android AOSP)
Memory
2 GB DDR4
Storage
16 GB eMMC
Additional Storage
Micro SD (up to 1TB)
CPU
Quad-Core ARM Cortex-A55
GPU
ARM Mali-G31 MP2
Wired
10/100 Mbps Ethernet, IEEE 802.1X Authentication
WiFi
WiFi 5 (802.11 a/b/g/n/ac), IEEE 802.1X Authentication
Bluetooth
BT 5.1
HTML5 Browser
Vewd
Wireless Display
Miracast
Monitor Connectivity
Video Input
4xHDMI2.0, 1xUSB-A 3.0, 1xUSB-A 2.0, 1xUSB-A 2.0 (Internal), 1x Micro USB
Video Output
1xHDMI2.0
Audio Output
Headphone, Optic SPDIF
External Control
RS232 (3.5mm jack green), Fast Ethernet (RJ45), Service (RJ12)
External Sensor
RJ12
Mechanical
Product Dimensions (WxDxH)
1456 x 74 x 834 mm
Package Dimensions (WxDxH)
1650 x 190 x 997 mm
Product Weight
24.7 kg
Package Weight
34.75 kg
Vesa Mounting
600 (W) x 400 (H) mm M6
Bezel Width
B: 14 mm, T/L/R: 10 mm
Environmental Conditions
Operating Temperature
0-40°C
Operating Humidity
10-90%
Power
Power Supply
110 VAC - 240 VAC - 50/60 Hz
Power Consumption
Typical
194 W
Maximum
220 W
Deep Standby
=0.5 W
