Cooler Master V SFX 750W ATX 3.1 Power Supply
80 Plus Gold - Fully Modular - 10 Years Warranty
Cooler Master V SFX 750W ATX 3.1 Power Supply
80 Plus Gold - Fully Modular - 10 Years Warranty
- Brand: Cooler Master
- MPN: MPY-7501-SFHAGV-3EAU
- Part #: PSUCLM6752
- UPC: 884102120336
- Brand: Cooler Master
- MPN: MPY-7501-SFHAGV-3EAU
- Part #: PSUCLM6752
- UPC: 884102120336
What PB Tech customers are saying about this product...
See More Reviews"Actually pleasently surprised by the build quality of the PSU. Comes with lots of cables, accessories and zip ties too. The fan only turns on when it's hot, so it runs silently mos ...view more"
COMBO DEALS: Buy Together and SAVE!





ProsKit SD-9828 58 PCS Screwdriver & Bit Set Suitable For Home Appliances, iPhone MacBook Xbox...
$53.67
$53.67


Posh TA-001 ESD Anti Static Wrist Strap Band - 1.8M (Blue)
$6.50
$6.50
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Desktop Power Supplies





Cooler Master V SFX 750W ATX 3.1 Power Supply 80 Plus Gold - Fully Modular - 10 Years Warranty
- Brand: Cooler Master
- MPN: MPY-7501-SFHAGV-3EAU
- Part #: PSUCLM6752
- UPC:884102120336

Product URL: https://www.pbtech.com/pacific/product/PSUCLM6752/Cooler-Master-V-SFX-750W-ATX-31-Power-Supply-80-Pl?is-review=1
Features
Small But Mighty
As the leading SFX power supply design, the V SFX Gold offers a highly powerful unit in a space-saving, mini form factor.
Flexible compatibility
With the included SFX-to-ATX bracket, the V SFX Gold ATX 3.1 can be used to power systems ranging from as small as a mini-ITX all the way up to E-ATX motherboards.
ATX 3.1 support & a durable 90-degree 12V-2x6 cable
Includes ATX 3.1 support and a 90-degree 12+4pin (12V-2x6) PCIe 5.1 connector featuring higher electrical durability, lower temperatures, and improved safety.
80 PLUS Gold certified
The V SFX Gold is certified to achieve more than 90% efficiency at typical loads.
100% Japanese capacitors
Large, high-quality Japanese capacitors feature improved efficiency
Fully modular cabling
Modular cabling reduces clutter, increases airflow, and improves overall thermal performance.
Specifications
ATX Version
ATX 3.1 & SFX 12V Ver. 3.42
PFC
Active PFC
Input Voltage
100-240V
Input Current
10-5A
Input Frequency
50-60Hz
Dimensions (L x W x H)
100 x 125 x 63.5 mm
Fan Size
92mm
Fan Bearing
FDB
Efficiency
90% @ Typical Load
80 PLUS Rating
80 PLUS Gold
ErP 2014 Lot 3
Yes
Operating Temperature
0-50°C
Power Good Signal
100 - 500 ms
Hold Up Time
16ms
MTBF
>100,000 Hours
Protections
OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection
Regulatory
TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, CB, UKCA
ATX 24 Pin Connectors
1
EPS 4+4 Pin Connectors
1
EPS 8 Pin Connector
1
SATA Connectors
8
Peripheral 4 Pin Connectors
4
PCI-e 6+2 Pin Connectors
4
12V-2x6 Connectors
1
Series
V SFX Series
80 Plus Efficiency
Gold
Modular
Fully Modular
Form Factor
SFX
Watts
750W
