CTC Union IFS-402GSM-E IFS-402GSM-E 4x 10/100Base-T(X) plus 2x 100/1000Base-X SFP (Total 6 Ports), -40 ~ 75°C

PB Tech price
PB Tech price
NZD $ 999 .13
$ 999 .13
$999.13  +GST
$999.13

CTC Union IFS-402GSM-E IFS-402GSM-E 4x 10/100Base-T(X) plus 2x 100/1000Base-X SFP (Total 6 Ports), -40 ~ 75°C

  • Brand: CTC Union
  • MPN: IFS-402GSM-E
  • Part #: SWHCTC1009
  • UPC:
PB Tech price
NZD $ 999 .13 $ 999 .13
In stock at NZ Logistics Centre
Delivery: Order now and it ships on 12 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$999.13  +GST
$999.13
Add To Compare
Stock Alerts
Click or hover over image to enlarge
  • Brand: CTC Union
  • MPN: IFS-402GSM-E
  • Part #: SWHCTC1009
  • UPC:

10 Gigabit

No

10 Gigabit Ports

0 Ports

Form Factor

DIN Rail

Management Level

Managed

Number of Ports

6 Ports

PoE

No

PoE Ports

N/A

PoE Budget

N/A

View full specs
Returns & Warranty Bulk Quote Print Page

Features

CTC Union IFS-402GSM-E IFS-402GSM-E 4x 10/100Base-T(X) plus 2x 100/1000Base-X SFP

This series models are managed by industrial-grade gigabit switches with 4~16x 10/100Base-TX ports and 2~4x Gigabit/Fast Ethernet SFP ports that provide stable and reliable Ethernet transmission. The switches support a variety of Ethernet functions, including STP/RSTP/MSTP/ ITU-T G.8032 ERPS and multiple µ-Ring for redundant cabling, layer 2 Ethernet IGMP, VLAN, QoS, Security, IPv6, bandwidth control, port mirroring, cable diagnostic and Green Ethernet. Housed in rugged DIN rail or wall mountable enclosures, these switches are designed for harsh environments, such as industrial networking, security automation applications, intelligent transportation systems (ITS) and are also suitable for many militaries and utility market applications where environmental conditions exceed commercial product specifications. Wide operating temperature range models (-40°C ~ 75°C) fulfil the special needs of industrial automation applications.

- 8x 10/100Base-TX RJ45 and 3x 100/1000Base-X SFP Fiber (IFS-803GSM)
- UL60950-1, CE, FCC, Rail Traffic EN50121-4, Traffic control NEMA TS2 certified
- Industrial Grade EMS, EMI, EN61000-6-2, EN61000-6-4 certified
- Cable diagnostic, Measuring cable normal or broken point distance
- Supports Green Ethernet IEEE802.3az EEE (Energy Efficient Ethernet) management to optimise the power Consumption
- STP, RSTP, MSTP, ITU-T G.8032 Ethernet Ring Protection Switching (ERPS) for redundant cabling
- Provides 5 instances that each can support µ-Ring, u-Chain or Sub-Ring type for flexible uses. Supports up to 5 rings in one device.
- µ-Ring for Redundant Cabling, recovery time<10ms in 250x devices
- DHCP Server/Client/Relay/Snooping/Snooping option 82/Relay
- QoS, Traffic classification QoS, CoS, bandwidth control for Ingress and Egress, Storm Control, DiffServ
- IEEE802.1q VLAN, MAC-based VLAN, IP subnet-based VLAN, Protocol-based VLAN, VLAN translation, GVRP, MVR
- Dynamic IEEE 802.3ad LACP Link Aggregation, Static Link Aggregation
- IGMP snooping V1/V2/V3, IGMP Filtering/Throttling, IGMP query, IGMP proxy reporting, MLD snooping V1/V2
- Security: Port-based and MAC-based IEEE802.1X, RADIUS, ACL, TACACS+, HTTP/HTTPS, SSL/SSH v2
- Software upgrades via TFTP and HTTP, redundant firmware to avoid in case of upgrade failure
- Supports IEEE1588 PTP V2 for precise time synchronisation to operate in Ordinary-Boundary, Peer to Peer Transparent Clock, End to End Transparent Clock, Master, Slave mode by each port
- RMON, MIB II, Port mirroring, Event Syslog, DNS, NTP, IEEE802.1ab LLDP
- Supports IPv6 Telnet server /ICMP v6
- CLI, Web-based management, SNMP v1/v2c/v3, Telnet server for management
- Industrial power supply purchased separately - MDR-40-24

Application Example

Dimensions (IFS-402GSM)

Specifications

Network Connector

4x 10/100Base-TX RJ-45 + 2x 100/1000Base-X SFP connector (IFS-402GSM)
RJ-45 UTP port support Auto negotiation speed,Auto MDI/MDI-X function,SFP port support dual speed with DDMI

Standard

IEEE 802.3 10Base-T 10Mbit/s Ethernet
IEEE 802.3u 100Base-TX, 100Base-FX, Fast Ethernet
IEEE 802.3z 1000Base-X Gbit/s Ethernet over Fiber-Optic
IEEE 802.1d STP (Spanning Tree Protocol)
IEEE 802.1w RSTP (Rapid Spanning Tree Protocol)
IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
ITU-T G.8032 / Y.1344  ERPS (Ethernet Ring Protection Switching)
IEEE 802.1Q Virtual LANs (VLAN)
IEEE 802.1X Port-based and MAC based Network Access Control, Authentication
IEEE802.3ac Max frame size extended to 1522Bytes
IEEE 802.3ad Link aggregation for parallel links with LACP(Link Aggregation Control Protocol)
IEEE 802.3x Flow control for Full Duplex
IEEE 802.1ad Stacked VLANs, Q-in-Q
IEEE 802.1p LAN Layer 2 QoS/CoS Protocol for Traffic Prioritization
IEEE 802.1ab Link Layer Discovery Protocol (LLDP)
IEEE 802.3az EEE (Energy Efficient Ethernet)

VLAN ID

4094 IEEE802.1Q VLAN VID

Switch Architecture

Back-plane (Switching Fabric): 4.8Gbps (IFS-402GSM) Full wire-speed

Data Processing

Store and Forward

Flow Control

IEEE 802.3x for full duplex mode Back pressure for half duplex mode

Console

RS-232 (RJ-45)

Network Cable

UTP/STP above Cat. 5e cable
EIA/TIA-568 100-ohm (100m)

Protocols

CSMA/CD

Reverse Polarity Protection

Present

Overload Current Protection

Present

CPU Watch Dog

Present

Power Supply

Redundant Dual DC 12/24/48V (9.6~60VDC) Input power (Removable Terminal Block )
Provide DC Power JACK adapter cable for external power supply

Power Consumption

Input Voltage 12VDC: 5.7W
Input Voltage 24VDC: 5.8W
Input Voltage 48VDC: 8.5W

LED

Per unit: Power 1 (Green), Power 2 (Green), Fault (Amber), CPU Act (Green), Ring Master (Yellow)
Per RJ-45 port: 10/100 Link/Active (Green)
SFP Fiber Per port: Link/Active (Green)

Warning Message

System Syslog, SMTP/ e-mail event message, alarm relay

Alarm Relay Contact

Relay outputs with current carrying capacity of 1 A @24VDC

Removable Terminal Block

Provide 2 redundant power, alarm relay contact, 6 Pin

Operating Temperature

-40 ~ 75°C

Storage Temperature

-40 ~ 85°C

Housing

Rugged Metal, IP30 Protection, Fanless

Installation Mounting

DIN Rail mounting or wall mounting

MTBF

321,556hrs (IFS-402GSM)

Dimensions

106 x 62.5 x 135 mm (D x W x H)

Weight

0.715kg (IFS-402GSM)

Manufacturer Part No:
IFS-402GSM-E
Brand:
CTC Union
Product Type:
IFS-402GSM-E
UPC
-
Product Family:
-
Shipping Weight:
1.01 kg
PB Part No:
SWHCTC1009
Product Model:
IFS-402GSM-E
Warranty: 60 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
