Edgecore 10 Port Lite L2 Smart Gigabit Web Managed PoE Switch with 8 PoE Ports (90W) and 2SFPPorts.250W Power Budget. 6KV Power Surge Protection. Fan-Cooled Design.

PB Tech price
PB Tech price
NZD $ 470 .43
$ 470 .43
$470.43  +GST
$470.43

Edgecore 10 Port Lite L2 Smart Gigabit Web Managed PoE Switch with 8 PoE Ports (90W) and 2SFPPorts.250W Power Budget. 6KV Power Surge Protection. Fan-Cooled Design.

  • Brand: Edgecore
  • MPN: ECS1100-10HP
  • Part #: SWHEDG1098
  • UPC:
PB Tech price
NZD $ 470 .43 $ 470 .43
In stock at NZ Logistics Centre
Delivery: Order now and it ships on 09 Sep
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$470.43  +GST
$470.43
Add To Compare
Stock Alerts
Click or hover over image to enlarge
  • Brand: Edgecore
  • MPN: ECS1100-10HP
  • Part #: SWHEDG1098
  • UPC:

10 Gigabit

No

10 Gigabit Ports

0 Ports

Management Level

Managed

Number of Ports

10 Ports

PoE

Yes

PoE Ports

8 Ports

PoE Budget

250 Watts

Stacking

Not Specified

View full specs
Returns & Warranty Bulk Quote Print Page

Features

EDGECORE 10 Port Lite L2 Smart Gigabit Web Managed PoE Switch

The ECS1100 Series is Edgecore's latest generation of cost-effective smart switches. The ECS1100 Series is designed for SMB and enterprise markets with complete solutions from 5 to 28 ports, including 802.3af/at/bt PoE options. The switches comply with the IEEE 802.3az Energy Efficient Ethernet standard and support IPv4 management features.

The ECS1100-10HP is a rack-mountable switch and supports 802.3bt PoE Type 4 with Power Class 8, enabling a maximum power transfer from Power Sourcing Equipment (PSE) to Powered Device (PD) of up to 90W.

This switch provides a standard 250W of PoE power, ensuring robust support for upcoming devices like IP cameras, IP video telephones, access points, and PoE-enabled computers. It adheres to the IEEE 802.3az Energy Efficient Ethernet standard and incorporates IPv4 management features.

- 8 x RJ-45 10/100/1000 Ports (PoE)
- af/at/bt 250W
- 2 x 1G SFP Port
- 20 Gbps Switching Capacity
- Support ecCLOUD

Network Application

Specifications

Product Model

ECS1100-10HP

Port

RJ-45 10/100/1000 Ports

8

100/1000 SFP Ports

2

Performance

Switching Capacity

20 Gbps

Forwarding Rate

14.9 Mpps

Flash Memory

8 MB

SRAM (Built-In)

256 KB

Packet Buffer Size

4 Mbits

MAC Address Table Size

8 K

Jumbo Frames

15 KB

Auto-negotiation, Auto-MDI/MDIX

Yes

Surge Protection

6KV (RJ-45), 6KV (Power)

MTBF

= 200,000 hrs

Heat Dissipation

921.2

Acoustic Noise

< 50 dB (A)

PoE

PoE Ports

8

PoE++ based on IEEE 802.3bt (up to 90 W)

Yes

PoE+ based on IEEE 802.3at/802.3af

Yes

Auto Disable a?ter Exceeding Power Budget

Yes

Dynamic Power Allocation

Yes

PoE Power Budget

250 W

Mechanical

Dimension (W x D x H)

294 x 180 x 44 mm

Weight

1.56 kg (3.44 lb)

Power Supply

100-240 VAC, 50-60 Hz

Yes

Max System Power Consumption (Watts)

270 W

Environmental

Operating Temperature

0 - 50ºC

Storage Temperature

-40 - 70ºC

Operating Humidity (non-condensing)

10% to 90%

Storage Temperature (non-condensing)

10% to 90%

WEEE

Yes

RoHS

Yes

Certification

FCC Class A

Yes

CE

Yes

Safety Compliance: LVD

Yes

VCCI/BSMI

Yes

UKCA

Yes

Manufacturer Part No:
ECS1100-10HP
Brand:
Edgecore
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
3 kg
PB Part No:
SWHEDG1098
Product Model:
-
Warranty: 12 months *
