HiLook NS-0318P-130 16-Port 10/100M Unmanaged PoE Switch (Max 130W)

Brand: HiLook
MPN: NS-0318P-130
Part #: SWHHLK0318
UPC:

In stock at NZ Logistics Centre

Delivery: Order now and it ships on 09 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: HiLook
MPN: NS-0318P-130
Part #: SWHHLK0318
UPC:

Be the first to review this product

Form Factor

Not Specified

10 Gigabit Ports

10 Gigabit

Management Level

Unmanaged

Number of Ports

18 Ports

PoE Ports

16 Ports

PoE Budget

130 Watts

View full specs

Returns & Warranty Bulk Quote Print Page

Features

- 16x 100Mbps PoE ports, 1x 1000Mbps RJ45 port, and 1x 1000Mbps SFP fiber optical port
- IEEE 802.3at/af standard
- IEEE 802.3, IEEE 802.3u, and IEEE 802.3x standard
- High priority ports
- 8-core power supply
- Up to 25m transmission distance
- 6KV surge protection for PoE ports
- PoE power management
- 1000Mbps network access
- Wire-speed forwarding and non-blocking design
- Store-and-forward switching
- Solid high-strength metal shell

Specifications

General

Shell

Metal material

Operating temperature

-10 °C to 55 °C (14 °F to 131 °F)

Storage temperature

-40 °C to 85 °C (-40 °F to 185 °F)

Power supply

100 to 240 VAC, 50/60 Hz, Max. 2.5 A

Storage humidity

5% to 95% (no condensation)

Net weight

1.8 kg (4.0 lb)

Dimension (L × H × D)

266 mm × 44.5 mm × 220.8 mm (10.5" × 1.8" × 8.7")

Operating humidity

5% to 95% (no condensation)

Power consumption in idle

20 W

Network parameters

Port number

16 × 100 Mbps PoE ports, 1 × 1000 Mbps RJ45 port, and 1 × 1000 Mbps SFP fiber optical port

Port type

RJ45 port, full duplex, MDI/MDI-X adaptive

Standard

IEEE 802.3, IEEE 802.3u, IEEE 802.3x

Forwarding mode

Store-and-forward switching

Working mode

Standard mode (default); Extend mode

MAC address table

4 K

Switching capacity

7.2 Gbps

Packet forwarding rate

5.356 Mpps

Internal cache

2.75 Mbits

High priority ports

Ports 1 to 8

Ports for long-distance transmission

Ports 9 to 16

PoE power supply

PoE standard

IEEE 802.3af, IEEE 802.3at

PoE power pin

Ports for long-distance transmission (9-16) support 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply.
Ports for close-range transmission (1-8) support 4-core power supply, Ethernet cable 1/2/3/6 provide power supply.

PoE port

Ports 1 to 16

Max. port power

30 W

PoE power budget

130 W

Max. power consumption

150 W

Manufacturer Part No:

NS-0318P-130

Brand:

HiLook

Product Type:

UPC

Product Family:

Shipping Weight:

3 kg

PB Part No:

SWHHLK0318

Product Model:

NS-0318P-130

Warranty: 24 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
