TP-Link Omada ES220GMP 20-Port Gigabit Easy Managed PoE Switch (250W) - SFP/GbE Combo x2, 1GbE PoE+ x16

PB Tech price

NZD $ 312 .17

$ 312 .17

TP-Link Omada ES220GMP 20-Port Gigabit Easy Managed PoE Switch (250W) - SFP/GbE Combo x2, 1GbE PoE+ x16

Support up to 250m Long Range PoE

Brand: TP-Link
MPN: ES220GMP
Part #: SWHTPL2201
UPC:

PB Tech price

NZD $ 312 .17

Available on order

Delivery: Order now and it ships on 06 Oct

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: TP-Link
MPN: ES220GMP
Part #: SWHTPL2201
UPC:

Be the first to review this product

Form Factor

Not Specified

10 Gigabit Ports

0 Ports

10 Gigabit

Management Level

Managed L2

Number of Ports

16 Ports

PoE Ports

16 Ports

PoE Budget

250 Watts

View full specs

Returns & Warranty Bulk Quote Print Page

Features

mada 20-Port Gigabit Easy Managed Switch with 16-Port PoE+

- 16× Gigabit 802.3af/at-compliant PoE+ RJ45 ports
- 2× Gigabit RJ45 port, 2× Gigabit SFP port
- 250W Power Budget, with up to 30W for each PoE port*
- Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
- Centralised Cloud Management via the web or the Omada app†
- Up to 250m PoE**, QoS?, PoE Auto Recovery‡, and Port Isolation for reliable surveillance networking
- Automatic Loop Prevention, VLAN, and IGMP Snooping
- Durable metal casing and rack-mountable design

Omada Cloud Essentials - A Free and Easy Cloud-Based Network Management

Omada Cloud Essentials is a free, easy-to-use cloud-based management option for the Omada networking system§, covering access points, switches, and gateways. It enables simple, centralised network management and monitoring with essential features, making it ideal for surveillance networks and small businesses that don't require the complexity of larger operations.

Specifications

HARDWARE FEATURES

Interface

- 16× 10/100/1000 Mbps PoE+ RJ45 Ports (support 802.3af PoE and 802.3at PoE+)
- 2× 10/100/1000 Mbps RJ45 Port
- 2× Gigabit SFP Slot
- Auto-Negotiation/Auto MDI/MDIX

Fan Quantity

Installation

Rackmountable

Physical Security Lock

Yes

Power Supply

100-240V AC, 50/60Hz

PoE Ports (RJ45)

- Standard: 802.3af PoE and 802.3at PoE+ compliant
- PoE Ports: 16 ports
- PoE Budget: 250W available for all PoE+ ports, 30W max per port
- Fast PoE & Perpetual PoE
- PoE Auto Recovery‡
- Up to 250m PoE transmission distance**

Dimensions ( W x D x H )

17.3 × 7.1 × 1.7 in.(440 × 180 × 44 mm)

Surge Protection

±6kV

PERFORMANCE

Switching Capacity

40 Gbps

Packet Forwarding Rate

29.76 Mpps

MAC Address Table

Packet Buffer Memory

4 Mbit

Jumbo Frame

15 KB

SOFTWARE FEATURES

Quality of Service

- Port-based/802.1p/DSCP QoS
- 8 Priority Queues
- Priority Schedule Mode
- WRR (Weighted Round Robin)
- Queue Weight Config
- Bandwidth Control
- Port-Based Rating Limit
- Storm Control
- Multiple Control Modes (kbps/pps)
- Broadcast/Multicast/Unknown-Unicast Control

L2 Features

- Static Link Aggregation
- Loop Prevention / Loopback Detection
- Flow Control
- 802.3x Flow Control
- Mirroring
- Port Mirroring
- One-to-One
- Many-to-One
- Ingress/Egress/Both
- Port Statistics
- Port Mirror Status
- Traffic Statistics
- 802.1ab LLDP

L2 Multicast

- IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave

VLAN

- MTU VLAN
- Port-Based VLAN
- 802.1Q Tag VLAN
- Max 32 VLAN Groups
- 4K VID

Transmission Method

Store-And-Forward

Management Features

Omada App

Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

Centralized Management

- Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller

Cloud Access

Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning Yes. Requires the use of Omada Cloud-Based Controller

Management Features

- Web-based GUI
- DHCP Client
- Cable Diagnostics
- Automatic Device Discovery†
- Batch Configuration†
- Batch Firmware Upgrading†
- Unified Configuration†

OTHERS

Certification

FCC, CE, RoHS

Package Content

- ES220GMP
- Power Cord
- Mounting Brackets
- Rubber Feet
- Screws
- Installation Guide

Environment

- Operating Temperature: -5?~50? (23?~122?)
- Storage Temperature: -40?~70? (-40?~158?)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing

Manufacturer Part No:

ES220GMP

Brand:

TP-Link

Product Type:

20-Port Gigabit Easy Managed PoE Switch (250W)

UPC

Product Family:

Omada

Shipping Weight:

3.14 kg

PB Part No:

SWHTPL2201

Product Model:

ES220GMP

Warranty: 36 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
