TP-Link Omada ES228GMP 28-Port Gigabit Easy Managed PoE Switch (384W) - SFP x2, 1GbE PoE+ x24

PB Tech price

NZD $ 564 .35

$ 564 .35

TP-Link Omada ES228GMP 28-Port Gigabit Easy Managed PoE Switch (384W) - SFP x2, 1GbE PoE+ x24

Support up to 250m Long Range PoE

Brand: TP-Link
MPN: ES228GMP
Part #: SWHTPL22801
UPC:

PB Tech price

NZD $ 564 .35

In stock at Supplier

Delivery: Order now and it ships on 25 Sep

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: TP-Link
MPN: ES228GMP
Part #: SWHTPL22801
UPC:

Be the first to review this product

10 Gigabit

10 Gigabit Ports

0 Ports

Form Factor

Desktop

Management Level

Managed L2

Number of Ports

28 Ports

PoE Ports

Not Specified

PoE Budget

Not Specified

View full specs

Returns & Warranty Bulk Quote Print Page

Features

Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+

- 8× Gigabit 802.3af/at-compliant PoE+ RJ45 ports
- 1× Gigabit RJ45 port, 1× Gigabit SFP/RJ45 Combo port
- 123W Power Budget, with up to 30W for each PoE port*
- Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
- Centralized Cloud Management via the web or the Omada app†
- Up to 250m PoE**, QoS?, PoE Auto Recovery‡, and Port Isolation for reliable surveillance networking
- Automatic Loop Prevention, VLAN, and IGMP Snooping
- Fanless design for silent operation
- Durable metal casing and desktop/wall mounting design

Omada Cloud Essentials - A Free and Easy Cloud-Based Network Management

Omada Cloud Essentials is a free, easy-to-use cloud-based management option for the Omada networking system§, covering access points, switches, and gateways. It enables simple, centralized network management and monitoring with essential features, making it ideal for surveillance networks and small businesses that don't require the complexity of larger operations.

Specifications

HARDWARE FEATURES

Interface

- 8× 10/100/1000 Mbps PoE+ RJ45 Ports (support 802.3af PoE and 802.3at PoE+)
- 1× 10/100/1000 Mbps RJ45 Port
- 1× Gigabit SFP/RJ45 Combo Port
- Auto-Negotiation/Auto MDI/MDIX

Fan Quantity

Fanless

Installation

- Desktop
- Wall Mount

Physical Security Lock

Yes

Power Supply

DC Power Adapter (Output: 53.5V DC / 2.43A)

PoE Ports (RJ45)

- Standard: 802.3af PoE and 802.3at PoE+ compliant
- PoE Ports: 8 ports
- PoE Budget: 123W available for all PoE+ ports, 30W max per port
- PoE Auto Recovery‡
- Up to 250m PoE transmission distance**

Dimensions ( W x D x H )

8.2×4.9×1.0 in (209×126×26 mm)

Surge Protection

±6kV

PERFORMANCE

Switching Capacity

20 Gbps

Packet Forwarding Rate

14.88 Mpps

MAC Address Table

Packet Buffer Memory

4 Mbit

Jumbo Frame

15 KB

SOFTWARE FEATURES

Quality of Service

- Port-based/802.1p/DSCP QoS
- 8 Priority Queues
- Priority Schedule Mode
- WRR (Weighted Round Robin)
- Queue Weight Config
- Bandwidth Control
- Port-Based Rating Limit
- Storm Control
- Multiple Control Modes (kbps/pps)
- Broadcast/Multicast/Unknown-Unicast Control?

L2 Features

- Static Link Aggregation
- Loop Prevention / Loopback Detection
- Flow Control
- 802.3x Flow Control
- Mirroring
- Port Mirroring
- One-to-One
- Many-to-One
- Ingress/Egress/Both
- Port Statistics
- Port Mirror Status
- Traffic Statistics
- 802.1ab LLDP

L2 Multicast

- IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave

VLAN

- MTU VLAN
- Port-Based VLAN
- 802.1Q Tag VLAN
- Max 32 VLAN Groups
- 4K VID

Transmission Method

Store-And-Forward

Management Features

Omada App

Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

Centralized Management

- Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller

Cloud Access

Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning Yes. Requires the use of Omada Cloud-Based Controller

Management Features

- Web-based GUI
- DHCP Client
- Cable Diagnostics
- Automatic Device Discovery†
- Batch Configuration†
- Batch Firmware Upgrading†
- Unified Configuration†

OTHERS

Certification

FCC, CE, RoHS

Package Content

- ES210GMP
- Power Adapter
- Installation Guide
- Rubber Feet

Environment

- Operating Temperature: 0?~40? (32?~104?)
- Storage Temperature: -40?~70? (-40?~158?)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing

Manufacturer Part No:

ES228GMP

Brand:

TP-Link

Product Type:

28-Port Gigabit Easy Managed PoE Switch (384W)

UPC

Product Family:

Omada

Shipping Weight:

3 kg

PB Part No:

SWHTPL22801

Product Model:

ES228GMP

Warranty: 36 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
