Ubiquiti Unifi USW-Ultra 7-Port Gigabit L2 Managed PoE-Passthrough PoE Switch (42W) - 1GbE PoE+ x7 (No PSU included)

PB Tech price

NZD $ 204 .86

$ 204 .86

Ubiquiti Unifi USW-Ultra 7-Port Gigabit L2 Managed PoE-Passthrough PoE Switch (42W) - 1GbE PoE+ x7 (No PSU included)

Hybrid Power - PoE++ / AC

Brand: Ubiquiti
MPN: USW-Ultra
Part #: SWHUBI10561
UPC: 810084693698

PB Tech price

NZD $ 204 .86

In stock at NZ Logistics Centre

Delivery: Order now and it ships on 07 Oct

Estimated Delivery Times

7 - 10 working days for international destinations

View all shipping info

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: Ubiquiti
MPN: USW-Ultra
Part #: SWHUBI10561
UPC: 810084693698

Be the first to review this product

10 Gigabit

10 Gigabit Ports

Not Specified

Form Factor

Not Specified

Management Level

Not Specified

Number of Ports

8 Ports

PoE Ports

7 Ports

PoE Budget

Not Specified

View full specs

Returns & Warranty Bulk Quote Print Page

Features

A compact, Layer 2, 8-port GbE PoE switch with versatile mounting options.

- (7) GbE PoE+ output ports

- (1) GbE PoE++ input port*

- 42W PoE availability with PoE++ input

- 16W PoE availability with PoE+ input

Specifications

Mechanical

Dimensions

203 x 76 x 33 mm (8 x 3 x 1.3")

Weight

Device: 320 g (11.3 oz)
Wall mount: 45 g (1.6 oz)

Enclosure material

Polycarbonate

Hardware

Management interface

Ethernet In-Band

Networking interface

(8) GbE RJ45 ports

PoE interface

(7) PoE/PoE+ (Pins 1, 2+; 3, 6-)

Total non-blocking throughput

8 Gbps

Switching capacity

16 Gbps

Forwarding rate

11.904 Mpps

Power method

(1) 54V, 3.9A power adapter (Not included)
(1) 54V, 1.1A power adapter (Not included)
PoE++ (Pins 1, 2+; 3, 6- and 4, 5+; 7, 8-)

Supported voltage range

44-57V DC

Max. power consumption

9W with PoE input (Excluding PoE output)
8W with AC adapter input (Excluding PoE output)

Total available PoE

PoE++ input: 42W
PoE+ input: 16W
60W PoE adapter input: 42W
60W AC adapter input: 52W
210W AC adapter input: 202W*
*At 45° C (113° F) operating temperature. Reduced to 161W (230V) or 121W (115V) at 60° C (140° F)

Max. PoE+ wattage per port by PSE

30W

Button

Factory reset

Ambient operating temperature

PoE++ input: -30 to 60° C (-22 to 140° F)
60W AC adapter input: -20 to 45° C (-4 to 113° F)
210W AC adapter input: -20 to 60° C (-4 to 140° F)

Ambient operating humidity

10 to 90% noncondensing

Certifications

CE, FCC, IC

Switching Features

Layer 2 features

Port isolation
Storm control
Port mirroring
Multicast / broadcast rate limiting
Flow control
Jumbo frames
Egress rate limit

LEDs

System

Status

Ethernet

PoE
Link/activity

Application Requirements

UniFi Network

Version 8.0.28 and later

Manufacturer Part No:

USW-Ultra

Brand:

Ubiquiti

Product Type:

UPC

810084693698

Product Family:

Unifi

Shipping Weight:

0.5 kg

PB Part No:

SWHUBI10561

Product Model:

USW-Ultra

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
