Ubiquiti UniFi USW-Pro-Max-16-PoE 18-Port 10G L3 Managed Etherlighting PoE Switch (180W) - SFP+ x2, 2.5GbE PoE++ x4, 1GbE PoE+x12

PB Tech price
PB Tech price
NZD $ 808 .12
$ 808 .12
$808.12  +GST
$808.12

Ubiquiti UniFi USW-Pro-Max-16-PoE 18-Port 10G L3 Managed Etherlighting PoE Switch (180W) - SFP+ x2, 2.5GbE PoE++ x4, 1GbE PoE+x12

  • Brand: Ubiquiti
  • MPN: USW-Pro-Max-16-PoE
  • Part #: SWHUBI2403266
  • UPC: 810084694633
PB Tech price
NZD $ 808 .12 $ 808 .12
In stock
Delivery: Order now and it ships tomorrow
Estimated Delivery Times
7 - 10 working days for international destinations

View all shipping info
$808.12  +GST
$808.12
Add To Compare
Stock Alerts
+ 3 More
Click or hover over image to enlarge
  • Brand: Ubiquiti
  • MPN: USW-Pro-Max-16-PoE
  • Part #: SWHUBI2403266
  • UPC: 810084694633

10 Gigabit

No

10 Gigabit Ports

N/A

Form Factor

1U Rackmount

Management Level

Managed L3

Number of Ports

16 Ports

PoE

Yes

PoE Ports

16 Ports

PoE Budget

180 Watts

View full specs
Returns & Warranty Bulk Quote Print Page

COMBO DEALS: Buy Together and SAVE!

Save even more by creating your own combo deal with any of the items below and the Ubiquiti UniFi USW-Pro-Max-16-PoE 18-Port 10G L3 Managed Etherlighting...
Ubiquiti UniFi USW-Pro-Max-16-PoE 18-Port 10G L3 Managed Etherlighting PoE Switch (180W) - SFP+ x2, 2.5GbE PoE++ x4, 1GbE PoE+x12
Ubiquiti UniFi U7-PRO (BE11000) Tri-Band 6-Stream Wi-Fi 7 Access Point with 2.5GbE x1 (PoE+ 21W)
Ubiquiti UACC-OM-MM-10G-D Multi-mode, duplex fiber transceiver module, 2-Pack, 10Gbps SFP+, LC, 850nm, 300m
Ubiquiti 10Gbps SFP+ Direct Attach Copper (DAC) Cable - 1m Passive - Copper
Total:
NZD $ 1,269 .04
NZD $ 1,269 .04
Buy together and save $18.62 $18.62
Ubiquiti UniFi U7-PRO (BE11000) Tri-Band 6-Stream Wi-Fi 7 Access Point with 2.5GbE x1 (PoE+ 21W)
Ubiquiti UniFi U7-PRO (BE11000) Tri-Band 6-Stream Wi-Fi 7 Access Point with 2.5GbE x1 (PoE+ 21W)

Ubiquiti UniFi U7-PRO (BE11000) Tri-Band 6-Stream Wi-Fi 7 Access Point with 2.5GbE x1 (PoE+ 21W)

Ships today
$360.73 $360.73
NZD

$345.58

$345.58

You save $15 You save $15
Ubiquiti UACC-OM-MM-10G-D Multi-mode, duplex fiber transceiver module, 2-Pack, 10Gbps SFP+, LC, 850nm, 300m
Ubiquiti UACC-OM-MM-10G-D Multi-mode, duplex fiber transceiver module, 2-Pack, 10Gbps SFP+, LC, 850nm, 300m

Ubiquiti UACC-OM-MM-10G-D Multi-mode, duplex fiber transceiver module, 2-Pack, 10Gbps SFP+, LC,...

Ships tomorrow
$84.81 $84.81
NZD

$83.28

$83.28

Ubiquiti 10Gbps SFP+ Direct Attach Copper (DAC) Cable - 1m Passive - Copper
Ubiquiti 10Gbps SFP+ Direct Attach Copper (DAC) Cable - 1m Passive - Copper

Ubiquiti 10Gbps SFP+ Direct Attach Copper (DAC) Cable - 1m Passive - Copper

Ships tomorrow
$34.00 $34.00
NZD

$32.06

$32.06

You save 5% You save 5%

Features

Ubiquiti UniFi USW Pro Max 16 PoE

Specifications

Mechanical

Dimensions

325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7")

Weight

2.1 kg (4.6 lb)

Enclosure material

SGCC steel

Hardware

Management interface

Ethernet In-Band

Networking interface

(12) GbE RJ45 ports
(4) 1/2.5 GbE RJ45 ports
(2) 10G SFP+ ports

PoE interface

(12) PoE/PoE+ (Pins 1, 2+; 3, 6-)
(4) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)

Total non-blocking throughput

42 Gbps

Switching capacity

84 Gbps

Forwarding rate

62.496 Mpps

Power method

DC adapter

Power supply

54V, 210W

Max. power consumption

30W (Excluding PoE output)

Total available PoE

180W

Max. PoE wattage per port by PSE

PoE: 15.4W
PoE+: 30W
PoE++: 60W

Voltage range PoE mode

PoE: 44-57V
PoE+/PoE++: 50-57V

LCM display

(1) 1.3" touchscreen

Button

Factory reset

Ambient operating temperature

-5 to 40° C (23 to 104° F)

Ambient operating humidity

10 to 90% noncondensing

Certifications

CE, FCC, IC

Switching Features

Layer 2 features

IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs

Layer 3 features

DHCP for locally-managed networks
DHCP relay
Inter-VLAN routing between networks on same switch
Static routing between local networks
Network isolation with ACLs

Etherlighting™

Ethernet

Locating
Speed/link
Native VLAN/network

SFP+

Locating
Speed/link
Native VLAN/network

Application Requirements

UniFi Network

Version 8.1.127 and later

Manufacturer Part No:
USW-Pro-Max-16-PoE
Brand:
Ubiquiti
Product Type:
-
UPC
810084694633
Product Family:
UniFi
Shipping Weight:
2 kg
PB Part No:
SWHUBI2403266
Product Model:
USW-Pro-Max-16-PoE
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
